Tx Switch Matrix Status Register - Analog Devices ADuCM355 Hardware Reference Manual

UG-1262
Bits Bit Name
7 N8STA
6 N7STA
5 N6STA
4 N5STA
3 N4STA
2 N3STA
1 N2STA
0 N1STA

Tx SWITCH MATRIX STATUS REGISTER

Address: 0x400C21BC, Reset: 0x00000000, Name: TSWSTA
This register gives the status of the Tx switches shown in Figure 27.
Table 152. Bit Descriptions for TSWSTA
Bits Bit Name
[31:12] Reserved
11 TR1STA
10 T11STA
9 T10STA
8 T9STA
7 T8STA
6 T7STA
5 T6STA
Settings Description
Status of N8 Switch.
0 Switch open.
1 Switch closed.
Status of N7 Switch.
0 Switch open.
1 Switch closed.
Status of N6 Switch.
0 Switch open.
1 Switch closed.
Status of N5 Switch.
0 Switch open.
1 Switch closed.
Status of N4 Switch.
0 Switch open.
1 Switch closed.
Status of N3 Switch.
0 Switch open.
1 Switch closed.
Status of N2 Switch.
0 Switch open.
1 Switch closed.
Status of N1 Switch.
0 Switch open.
1 Switch closed.
Settings Description
Reserved.
Status of TR1 Switch.
0 Switch open.
1 Switch closed.
Status of T11 Switch.
0 Switch open.
1 Switch closed.
Status of T10 Switch.
0 Switch open.
1 Switch closed.
Status of T9 Switch.
0 Switch open.
1 Switch closed.
Status of T8 Switch.
0 Switch open.
1 Switch closed.
Status of T7 Switch.
0 Switch open.
1 Switch closed.
Status of T6 Switch.
0 Switch open.
1 Switch closed.
Rev. B | Page 128 of 312
ADuCM355 Hardware Reference Manual
Reset Access
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
Reset Access
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
0x0 R
