980 HDMI Protocol Analyzer User Guide
2. Select an EDID to assign to the 980 HDMI Protocol Analyzer's Rx port. Click Ok after selecting the EDID.
Note that there are two checkbox options on the dialog box. The following is a description of each:
 Permanently set the 980 HDMI Protocol Analyzer's EDID – This means that the EDID that you provision
will persist through a reboot of the 980. Otherwise the default 980 EDID will be reprovisioned when a
reboot occurs.
 Issue Hot Plug – This means that the 980 HDMI Protocol Analyzer will issue a hot plug when you click the
OK activation button on this dialog box.
