980 HDMI Protocol Analyzer User Guide
Rev. A1
When configuring the HEAC functions, you click on the activation buttons within the panel. The status of each
selection is indicated on the simulated LED indicators to the left of the activation button. Green indicates that the
function associated with the activation button is active.
Page 258
December 19, 2012
