980 HDMI Protocol Analyzer User Guide
Note: You may have to refresh the view using the global refresh button on the upper right or the local refresh
button on the lower right.
4. Select the file you wish to playback and click on the Play button as indicated above.
Monitor your sink device for the proper response.
5. Stop the playback at anytime by pressing the Stop button.

15.2 Using the Playback Function through the Command Line

The procedures below describe how to use the 980 HDMI Protocol Playback function through the command line.
The table below lists the commands related to the playback function.
List of Commands Related to Playback
Note: Commands are lower case.
Command Description
pcap size Defines the capture buffer
size in percent of total
(2GB).
Page 286
Syntax
pcap size < size >
Where <size> can be 0 to 100 percent.
Command Example
To set the capture buffer size to 30%
of the total buffer capacity:
>pcap size 30
Captures data up to 30% of the
capacity of the buffer.
