980 HDMI Protocol Analyzer User Guide
To transfer Playback files from the 980 to your PC using the Data Transfer utility:
1. Through the external 980 GUI Manager, access the Generator/Port Control panel either through the View
pull-down menu or the Generator button located on the top of the interface. Refer to the screen shots below.
Note: This procedures shows examples of transferring ACA traces, capture files and Playback files but you
can transfer EDIDs, ImageLists, or any other type of data type under the Navigator tab.
2. Access the Data Transfer utility by double clicking on the Transfer Data icon
the Navigator window.
Page 250
Rev. A1
on one of the data sets in
December 19, 2012
