In the example shown below there are not errors.
7.5

Running the Pseudo-Random Noise Test through the command line

You can run the Pseudo-Random Noise test through the command line. Refer to the Chapter
Interface for Capturing Data
Commands for Pseudo-Random Noise Test
Note: Commands are not case sensitive.
Command Description
PRNG:NFRS Set number of frames to analyze in
pseudo-random noise test
Page 163
for information on how to establish a command line session with the 980.
Syntax
PRNG:NFRS < frames >
Where <frames> is the number of
frames to capture and compare during
the test. Enter 0 to run the test in
continuous mode which requires user
intervention to stop.
Rev. A1
Command Line
Command Example
To set number of frames to
analyze in pseudo-random noise
test:
> PRNG:NFRS 50
December 19, 2012
