Running the Pixel Error Test through the command line

You can run the Pixel Error test through the command line. Refer to the Chapter
Capturing Data for information on how to establish a command line session with the 980.
Commands for Pixel Error Test
Note: Commands are not case sensitive.
Command Description
PDAX:NFRS Set number of frames to analyze in
pixel data analysis test or sets test to
continuous mode requiring user
intervention to terminate.
PDAX:CAPF Capture a reference frame for pixel
data analysis test
PDAX:GFCA Saves a captured frame to a file. This
is used as a reference frame ("golden"
frame) for comparison with subsequent
captured frames.
PDAX:GFCL Load a captured reference frame from
a file.
PDAX:MXER Set maximum number of detailed
errors to record in pixel data analysis
test.
Page 154
Syntax
PDAX:NFRS < frames >
Where <frames> is the number of
frames to capture and compare
during the test. Set to 0 for
continuous mode which requires
user interaction to stop test.
PDAX:CAPF
PDAX:GFCA <path>
Where <path> is the directory path
and file name of the stored
reference frame. If the path is
omitted the default path is used.
PDAX:GFCL <path>
Where <path> is the directory path
and file name of the reference frame
to load. If the path is omitted the
default path is used.
PDAX:MXER <errors>
Where <errors> is maximum
number of errors to provide a
detailed report for up to 256 errors.
Command Line Interface for
Command Example
To set number of frames to analyze in
pixel data analysis test to 50:
>PDAX:NFRS 50
To capture a reference frame for pixel
data analysis test:
>PDAX:CAPF
To save a captured frame to a file to
use as a reference frame:
>PDAX:GFCA /user/cap1
or:
>PDAX:GFCA cap1
To load a captured reference frame
from a file:
>PDAX:GFCL /user/cap1
or:
>PDAX:GFCL cap1
To set maximum number of detailed
errors to record in pixel data analysis
test to 100:
>PDAX:MXER 100
