Quantum Data Gen 2 980 User Manual page 40

980 HDMI Protocol Analyzer User Guide
Top Level Menu Items
Page 40
Selection
Disconnect
Information
Edit [the Instrument
Entry]
Configure
[Instrument Network]
Upgrade GUI
Application
Upgrade Firmware/
Gateware
Upgrade System
Components
Set 980 License Key
Function
980.
Clicking on this item will initiate a disconnection
from the 980 that is selected in the list that you
are currently connected to. This item will not be
highlighted if you have not selected a 980.
Provides information about the 980 that the 980
Manager is currently selected. This information
includes:
o
980 Name
o
IP address of the 980
o
Netmask
o
Gateway IP address
o
Hardware revisions of the 980 circuit
boards
o
Firmware/Gateware version of the release
applied to the 980
o
Serial number of the 980
o
OS version
o
Licensed options applied to the 980
Enables you to edit certain information about
the 980 that you have selected. You can edit
the name and IP address.
Allows you to view and set the network
information such as the 980 IP address,
netmask and gateway IP address.
Upgrade GUI Application - Enables you to apply
an upgrade of the 980 built-in GUI. You can
download new GUI release from the Quantum
Data website on the downloads page.
Upgrade Firmware/Gateware - Enables you to
apply an upgrade to the 980. You can download
new releases from the Quantum Data website
on the downloads page.
Upgrade System Components - Enables you to
apply an upgrade to the 980 HDMI Source
Compliance Test application or any other
optional application. You can download new
releases from the Quantum Data website on the
downloads page.
This enables you to activate a license for an
Rev. A1
December 19, 2012
