Mount the Kinetix 5700 Drive System
This chapter provides installation procedures for mounting your Kinetix® 5700
drive system to the system panel and installing DC-bus links and 24V shared-
bus connector kits to the drive modules.
Topic
Determine Mounting Order
Mount Accessory Modules
Zero-stack Tab and Cutout
Install Shared-bus Connection Systems
Drill-hole Patterns
Mount Your Kinetix 5700 Drive Modules
This procedure assumes that you have prepared your panel and understand
how to bond your system. For installation instructions regarding equipment
and accessories not included here, refer to the instructions that came with those
products.
SHOCK HAZARD: To avoid the hazard of electrical shock, perform all
mounting and wiring of the Kinetix 5700 drive system before applying
power. Once power is applied, connector terminals can have voltage present
even when not in use.
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful to
keep metal debris from falling into it. Metal debris or other foreign matter
can become lodged in the circuitry and result in damage to the components.
Rockwell Automation Publication 2198-UM002G-EN-P - February 2019
3
Chapter
Page
80
83
84
84
87
90
79
