Allen-Bradley Kinetix 5700 User Manual page 55

DC-bus Power Supply Cat. No.
20%
2198-P031 97
2198-P070 108
2198-P141 249
2198-P208 265
Regenerative Bus Supply Cat. No.
2198-RP088 253
2198-RP200 532
2198-RP263 850
2198-RP312 1037
Dual-axis Inverter Cat. No.
2198-D006-ERSx 17
2198-D012-ERSx 34
2198-D020-ERSx 52
2198-D032-ERSx 100
2198-D057-ERSx 252
Single-axis Inverter Cat. No.
2198-S086-ERSx 190
2198-S130-ERSx 225
2198-S160-ERSx 270
2198-S263-ERSx 556
2198-S312-ERSx 610
iTRAK Power Supply Cat. No.
2198T-W25K-ER 206
Capacitor Module Cat. No.
2198-CAPMOD-2240 28
2198-CAPMOD-DCBUS-IO 1.1
DC-bus Conditioner Module Cat. No.
2198-DCBUSCOND-RP312 1.4
Table 18 - Power Dissipation Specifications
Usage as % of Rated Power Output
40%
101
119
267
294
399
832
1261
1576
29
58
84
155
354
255
340
420
759
883
272
34
1.4
2.1
