Avaya DEFINITY Server CSI Maintenance Manual page 972

Table 177. TEST #111 Data Channel Local Loop Back Test — Continued
Error Test
Code Result
1000 ABORT For this test, an Error Code of 1000 can have one of several different
meanings:
Determine if the target DATA-CHL is in use for some other function (that is,
CDR Link, System Printer Link, Journal Printer Link, PMS Link, or
secondary administration terminal connection) as described previously in
the
that is using the DATA-CHL. If there are no errors, there is a high probability
that the DATA-CHL is not defective.
Proceed with the remaining steps only if it is necessary to completely
test the target DATA-CHL:
1006 ABORT For this test, an Error Code of 1006 can have one of several different
meanings:
1016 ABORT Resources for the test are not available.
1018 ABORT Test disabled via software patch.
2000 ABORT Internal system error
2003 ABORT Internal system error
972
Issue 5 October 2002
Description/Recommendation
a. The target DATA-CHL is busy and, therefore, not available for use.
b. System resources required to run this test are not available.
c. Internal system error
''Status of Data Channels''
1. If the target DATA-CHL is in use for some other function, busyout the
function (PRI-CDR/SEC-CDR, SYS-PRNT, PMS-PRNT/JNL-PRNT,
PMS-LINK) or the DATA-CHL (secondary administration terminal
connection only).
2. Retry the command at 1-minute intervals a maximum of 5 times.
3. Restore any busied out PRI-CDR/SEC-CDR, SYS-PRNT,
PMS-PRNT/JNL-PRNT, PMS-LINK MOs to service before moving on to
another activity.
a. System resources required to run this test are not available.
b. Internal system error. Retry the command at 1-minute intervals a
maximum of 5 times.
1. Retry the command at 1-minute intervals a maximum of 5 times.
1. Retry the command at 1-minute intervals a maximum of 5 times.
section. If so, check for errors on the function
Continued on next page
555-233-119
