Diod-Trk (Diod Trunk), Diod-Bd (Diod Circuit Pack); Diod-Trk (Diod Trunk) - Avaya DEFINITY Server CSI Maintenance Manual

DIOD-TRK (DIOD Trunk), DIOD-BD
(DIOD Circuit Pack)
MO Name (in
Alarm Log)
2
DIOD-BD
1. Where P is the port network number (1 for PPN); C is the carrier designation (for
example, A, B, or C); and SS is the address of the slot in the carrier where the circuit
pack is located (for example, 01, 02, etc.)
2. Where l is long, s is short, and r is repeat. Refer to the XXX-BD (Common Port Board)
Maintenance documentation.

DIOD-TRK (DIOD Trunk)

MO Name (in
Alarm Log)
DIOD-TRK
DIOD-TRK
DIOD-TRK
1. Where P is the port network number (1 for PPN); C is the carrier designation (for
example, A, B, or C); and SS is the address of the slot in the carrier where the circuit
pack is located (for example, 01, 02, etc.).
2. A MAJOR alarm on a trunk indicates that alarms on these trunks are not downgraded
by the set options command and that at least 75 percent of the trunks in this trunk
group are alarmed.
Direct Inward and Outward Dial (TN429 DIOD) trunks are 2-wire analog lines to
the CO which support the following services:
both incoming and outgoing CO calls
DID trunk
DID Trunk and 1-way Outgoing DIOD
The DIOD Trunk circuit pack provides eight ports for loop-start CO. The circuit
pack is an interface between the 2-wire analog line from the CO and the system's
(4-wire) TDM Bus.
1056
Issue 5 October 2002
Alarm Initial Command to
Level
MINOR test port PCSS s
Alarm Level Initial Command to Run
2
MAJOR test port PCSSpp l
MINOR test port PCSSpp l
WARNING test port PCSSpp l
1
Run Full Name of MO
DIOD Circuit Pack
1
Full Name of MO
DIOD Trunk
DIOD Trunk
DIOD Trunk
555-233-119
