EXT-DEV ADMIN? Y (External Device Alarm)
Table 267. TEST #120 External Device Alarm Test
Error Test
Code Result
1000 ABORT
1035 ABORT
2000 ABORT
2029 ABORT
2100
2319
2320
2500
ANY FAIL
PASS
555-233-119
Description/ Recommendation
System resources required to run this test are not available.
1. Retry the command at 1-minute intervals a maximum of 5 time.
The Expansion Port Network containing this equipment is not available
Look for and resolve all Expansion Port Network problems with this cabinet.
Response to the test request was not received within the allowable time
period.
1. Retry the command at 1-minute intervals a maximum of 5 time.
2. (Maintenance Board) If the test continues to ABORT with error code
2000, check for system powering problems with the A carrier. Then,
repeat the test.
3. (Maintenance Board) If the test continues to ABORT with a 2000 error
code, check for and resolve all maintenance circuit pack errors. Then,
repeat the test.
Internal system error
1. Retry the command at 1-minute intervals a maximum of 5 times.
The External Device Alarm has been activated by the external device.
1. Clear the major alarm on the external device, and rerun the test.
2. If the test still fails, then disconnect the External Device Alarm Leads
from the Maintenance circuit pack and rerun the test.
3. If the test still fails, then there is a problem with the analog external
device alarm port or the Maintenance circuit pack that is reporting the
alarm. This circuit pack should be replaced. There are failures that can
occur on the Maintenance circuit pack that will not be detected by their
respective maintenance, but which will cause many environment tests
to fail. If many environment tests are failing, the suspect circuit pack
should be replaced and the test rerun.
If there is a problem with the external device, but the administered analog
line external device alarm, or the administered Maintenance circuit pack
connected to the device reports no alarm, then the External Device may not
be properly reporting the problems or the External Device may not be
properly connected to the External Device Alarm Lead.
Continued on next page
