Avaya DEFINITY Server CSI Maintenance Manual page 1011

DID-TRK (DID Trunk)
Table 191. TEST #35 Port Diagnostic Test — Continued
Error Test
Code Result
61446 FAIL
61456 FAIL
61472 FAIL
PASS
0 NO
BOARD
555-233-119
Description/ Recommendation
Battery feed test failed. A loop current fault was detected. This is most
probably an incoming CO-line problem. This failure code is only reported by
the TN2139 Italian DID circuit pack.
1. Check the incoming CO-line for loop current. If none is detected refer
the problem to the CO.
2. If the CO-line checks out OK, the failure must be on the DID port.
Replace the circuit pack.
Battery feed test failed. An on-board problem was detected. This port is
out-of-service.
1. Replace circuit pack.
Battery feed test failed. A problem with the incoming CO-line was detected.
1. Check the incoming CO-line for proper operation. If warranted, refer
the problem to the CO.
2. If the CO-line checks out OK, the failure must be on the DID port.
Replace the circuit pack.
Current flow was detected for this port.
1. User-reported troubles on this port should be investigated using other
port tests and by examining connections.
2. Refer problem to the CO.
The test could not relate the internal ID to the port (no board).
1. Check to ensure that the board translations are correct. Translate the
board, if necessary.
2. Issue the busyout board command.
3. Issue the reset board command.
4. Issue the release busy board command.
5. Issue the test board command. This should re-establish the linkage
between the internal ID and the port.
Continued on next page
Issue 5 October 2002
1011
