Avaya DEFINITY Server CSI Maintenance Manual page 1114

Table 234. TEST #145 Misframe Alarm Inquiry Test — Continued
Error
Code Test Result
ANY FAIL
PASS
0 NO BOARD
1114
Issue 5 October 2002
Description/ Recommendation
The test failed because the DS1 interface circuit pack detected errors in
the received framing bits pattern. The error code equals the number of
misframes detected by the DS1 interface circuit pack since the last
misframe alarm inquiry test. Major bit and minor bit error rate (error types
2561 and 2817) error logs often accompany misframe alarms. Clearing the
cause of these error logs may clear the misframes which are occurring.
1. Retry the command at 1-minute intervals a maximum of 5 times.
2. If the DS1 interface circuit pack is a TN767, enter the list
measurement ds1-log UUCSS command to read the error seconds
measurement.
3. Verify that both endpoints and all intermediate equipment of the DS1
link are administered using the same signaling mode, framing mode,
and line coding.
4. If the DS1 interface circuit pack connects to a T1 facility, call the
vendor of the T1 carrier to diagnose the remote DS1 endpoint. If the
DS1 interface circuit pack connects directly to a switch, call the system
technician of the remote switch to diagnose the DS1 endpoint.
5. Check the active alarm and error logs for recent alarms and errors
against the synchronization (SYNC). Follow the suggested repair
procedure for these errors.
6. Check the physical connection of the DS1 pack and of the cable.
7. If this continues to fail, escalate this problem.
No Misframe alarm is detected on the DS1 Interface circuit pack.
The test could not relate the internal ID to the port (no board).
This could be due to incorrect translations, no board is inserted, an
incorrect board is inserted, or an insane board is inserted.
1. Check to ensure that the board translations are correct. Use the add
ds1 UUCSS command to administer the DS1 interface if it is not
already administered.
2. If board was already administered correctly, check the error log to
determine if the board is hyperactive. If this is the case, the board is
shut down. Reseating the board will re-initialize the board.
3. If the board was found to be correctly inserted in step 1, issue the
busyout board command.
4. Issue the reset board command.
5. Issue the release busy board command.
6. Issue the test board long command.
This should re-establish the link between the internal ID and the port.
Continued on next page
555-233-119
