Avaya DEFINITY Server CSI Maintenance Manual page 1268

d. Error Type 125 - No Aux Data: The wrong circuit pack is inserted in the
slot where this circuit pack is logically administered.
1. Remove the wrong circuit pack and insert the logically administered
2. Re-administer this slot to match the circuit pack inserted (change
e. Error Type 257 - is associated with a failure of the Control Channel Test
#52. Refer to Control Channel Test #52 Maintenance documentation for
details.
f. Error Type 513 - indicates different hardware device problems on the
board. They include an external RAM failure, and internal RAM failure, a
ROM checksum failure, message corruption, and a program logic
inconsistency. The counter can be alarmed if it goes over threshold. There
are no associated tests for these inline errors; if they continue to happen,
an alarm will occur, otherwise the counter will be decremented via the leaky
bucket.
g. Error Type 1025 - indicates FPGA failure, associated with a problem on
the FPGA device located on the TN2302. The last byte of the inline error
gives a hint as to the problem with the FPGA. The diagnostic strategy for
this inline error is to take the switch resources associated with all of the
DSPs out of service, and then to reset the FPGA. The reset of the FPGA
will cause an uplink response as to whether the reset passed or not. There
are several error conditions that can be sent up in the error message for
the FPGA; they will all be treated as the same failure by switch software.
For the repair procedure, see Associated Test #1406.
h. Error Type 1281 - indicates TSI failures. There are potentially 2 different
TSI failures that can occur: one is a TSI DSP failure, and the other is a TSI
FPGA failure. Both of these failures will be looked for by switch software,
but they will both cause the same response by software. The diagnostic
strategy for this inline error is to take the switch resources associated with
all of the DSPs out of service, and then reset the TSI (the reset downlink is
slightly different depending on whether the TSI DSP or the TSI FPGA is to
be reset). The reset of the TSI will cause an uplink response as to whether
the reset passed or not. There are several error conditions that can be sent
up in the error message for the TSI; they will all be treated as the same
failure by switch software. For the repair procedure, see Associated Test
#1406.
i. Error Type 1538 - is used to indicate hyperactivity on the board.
Hyperactivity on a circuit pack is when the angel is sending too many
CCMS messages uplink, 400 per ten seconds for the TN2302, to switch
software. The circuit pack will be taken out of service. See error Type 3999.
1268
Issue 5 October 2002
circuit pack
OR
circuit-pack).
555-233-119
