Avaya DEFINITY Server CSI Maintenance Manual page 716

Maintenance Objects
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the table below when inspecting
errors in the system. By clearing error codes associated with the Channel
Administration Memory Array (CAMA) Test, for example, you may also clear
errors generated from other tests in the testing sequence.
Order of Investigation
Channel Administration Memory Array (CAMA) Test (#205)
Playback Speech Memory Array (PSMA) Test (#206)
140AY Channel Sanity Inquiry Test (#222)
1. D = Destructive; ND = Nondestructive
Channel Administration Memory Array (CAMA)
Test (#205)
This test is a memory device that stores information used to control the 140AY
device. The Angel asynchronously feeds the CAMA with the control information.
During the CAMA test, the Angel writes patterns into the CAMA, reads them back,
and verifies that they match. If the patterns do not match, the test fails. This test is
run periodically by the switch maintenance and by the Announcement circuit pack
in the background.
Table 64. TEST #205 Channel Administration Memory Array (CAMA) Test
Error Test
Code Result
1000 ABORT
2000 ABORT
2100 ABORT
ABORT
716
Issue 5 October 2002
Description/ Recommendation
System resources required to run this test are not available. The port may
be in use on a valid call.
1. Retry the command at 1-minute intervals a maximum of 5 times.
Response to the test request was not received within the allowable time
period. See Note (a) at end of table for more information.
Could not allocate the necessary system resources to run this test.
Internal system error.
1. Retry the command at 1-minute intervals a maximum of 5 times.
Short Test Long Test
Sequence Sequence
X
X X
X X
Continued on next page
1
D/ND
ND
ND
ND
555-233-119
