Fax Machines

Console Display/Instructions
3 Specify the first extension (odd numbered) of the pair.
Voice Signal Pair:
Enter voice signal pairs
Delete
Backspace
Enter
Exit
4
Specify whether or not the telephone is paired for Voice Announce to Busy.
—
Select Enter or
Delete.
5 Return to the System Programming menu.
Select Exit two times.
Analog Multiline Telephones in Data Stations
See "Data Features. "
Fax Machines
Use this procedure to add a fax machine by assigning the extension jack used
to connect the fax machine. To remove a fax machine and free the extension
jack for another use, you must remove the extension jack assignment.
In addition, you can specify the extensions to receive a message-waiting
indication (MWI) when a fax transmission is received, and specify the length of
time before the system registers that a fax has arrived and sends the message-
waiting indication.
3–76
Common Administrative Procedures
Additional Information
The other extension in the pair is
automatically assigned: Press the Inspct
button to view the pair.
If DSS is attached:
Toggle the red LED on or
off as required. Go to Step 5.
On = assigns pairing for Voice Announce
to busy.
Off = removes pairing for Voice Announce
to busy.
The red LED goes on automatically for the
other extension in the pair.
You may continue to assign or remove
the Voice Announce to Busy feature to
additional extensions by repeating
Steps 3 and 4.
PC
.
[ F10 ]
[ F8 ]
[ F5 ] [ F5 ]
