DS1 Facilities
Console Display/Instructions
3 Enter the slot number in the control unit that contains the 100D module
( nn = 1 to 17 ).
Loop/Ground/DSl:
Enter slot number(l-17)
Backspace
Enter
Exit
4 Save your entry.
Select Enter.
5 Select Suppression.
D.Q Slot xx:
Make a selection
Type Line Comp
FrameFormat Clock Sync
Suppression ChannelUnit
Signaling
Exit
6 Select AMI zero code suppression or bipolar 8 zero substitution.
DS1 Slot xx:
Select one
AMI-ZCS
B8ZS
Enter
Exit
7 Save your entry.
Select Enter.
Return to the System Programming menu.
8
Select Exit two times.
Signaling Mode
Use this procedure to specify the signaling for the 100D module as robbed-bit
or common-channel signaling.
NOTE:
This procedure is needed only for T1 facilities; common-channel signaling is set
automatically for PRI facilities.
Additional Information
Dial or type [ nn ].
xx = slot number entered in Step 3
xx= slot number entered in Step 3
Select AMI-ZCS or
Programming Procedures
PC
←
[ F10 ]
[ F3 ]
[ F1 ]
[ F2 ]
[ F10 ]
[ F5 ] [ F5 ]
4–67
