Tie Trunks
Console Display/Instructions
4 Enter a tie trunk number.
E&M Signal:
Enter trunk for assignmt
Backspace
Exit Enter
5 Save your entry.
Select Enter.
6 Specify the type of signaling for the trunk.
Trunk xxx:
Select E&M Trk Signaling
– TypelS
– TypelC
–
Type5
7 Continue to assign E&M signaling to another trunk or go to Step 8.
Select Next.
8 Save your entry.
Select Enter.
9 Return to the System Programming menu.
Select Exit two times.
Dial Mode
Use this procedure to specify whether an incoming or outgoing tie trunk is
touch-tone or rotary.
Touch-tone cannot be programmed for incoming immediate signaling tie trunks.
Users of touch-tone single-line telephone users cannot make calls by using
individual trunks programmed for rotary operation. The touch-tone signals
generated from the telephone while dialing are transmitted to the central office
at the same time the rotary signals are sent to the system. The central office
receives both signals and cannot process the call.
Additional Information
Dial or type:
Trunk number [ nnn ]
Slot and port number * [ sspp ]
Logical ID number # [ nnn ].
xxx = trunk entered in Step 4
Select Type1S,
Type1C, or
Type5.
Return to Step 6. The next trunk will be
displayed on Line 1.
Programming Procedures
PC
←
[ F10 ]
[ F1 ]
[ F2 ]
[ F3 ]
[ F9 ]
[ F10 ]
[ F5 ] [ F5 ]
4-83
