AT&T MERLIN LEGEND Release 3.0 System Programming Manual page 81

Accessing SPM
If you installed SPM on the hard disk of the PC, go to Step 5.
2
If the PC does not have a hard disk, insert the SPM diskette into Drive A.
3
[ Enter ↵ ].
4 Type and press (
a:
A:> appears on the screen.
5 Type and press
spm
Welcome to SPM
The MERLIN LEGEND
System Programming
& Maintenance Utility
Please press any key
to continue
Version X,XX
6 Press any key to display the SPM Main Menu shown below.
SPM Main Menu
Menu: Select Function
Sys Program Maintenance
[ F1 ]
Backup Restore
[ F2 ]
Pass-Thru
Boards
[ F3 ]
Password
Print Opts
[ F4 ]
Monitor Language
[ F5 ]
If the SPM Main Menu does not appear or if the information on the screen
is garbled, press any key again.
If the COM Port (communications port) screen appears instead of the
SPM Main Menu, it indicates that the SPM software has not been
initialized. See "Initializing the SPM Software.
NOTE:
The function keys shown on either side of the display are included here for
quick reference. See "SPM Screens" for details on using the PC keys in SPM.
7 To select an option, press the function key that corresponds to the option you
want. For example, to select Language press
With a Local or Remote Modem Connection
The method you use to access SPM by modem depends on whether you are
programming on site (locally) or from a remote location.
If you are on site, the modem must be connected to an 012 module on
the control unit. To establish a connection to the control unit's internal
modem, dial
[ Enter ↵ ]
to display the SPM Welcome screen shown below.
X.XX current version of SPM
[ F6 ]
[ F7 ]
[ F8 ]
[ F9 ]
[ F10 ]
10.
[ F10 ].
Programming with SPM
i
2-13
