System Renumbering
If two DSSs are attached, each Page button assignment sets the console for a
range of 100 extension numbers. If two DSSs are attached to the console,
change the factory setting so that the difference between extension numbers
assigned to the range is at least 100. For example, assign Page 1 to begin with
extension 10, Page 2 to begin with extension 110, and Page 3 to begin with
extension 210.
Operator Park Zone codes must be included in the extension number range
specified for one of the Page buttons.
CAUTION:
Select Exit on the console or [ F5 ] on the PC when you have finished this
procedure If you press Home, extensions may remain in the forced idle
condition (the LED next to each DSS button is on), and the system may
have to be restarted.
Summary: Assign Direct Station Selector Page
Buttons
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
All
Not required
Form 6a, Optional Operator Features
Page 1 =0; Page 2=50; Page 3=100
1,2,3
Yes
No
SysRenumber → Single → More → DSS Buttons → Dial page
no. → Enter → Dial first ext. no. → Enter → Exit → Exit
[ F2 ] → [ F2 ] → [ PgUp ] → [ F1 ] → Type page no. → [ F10 ] → Type first
ext. no. → [ F10 ] → [ F5 ] → [ F5 ]
