AT&T MERLIN LEGEND Release 3.0 System Programming Manual page 489

PRI Facilities
Console Display/Instructions
8 Enter the new identification number ( n = 0 to 63).
9 Continue to assign the identification number to another slot or go to Step 10.
Select Next.
10
Save your entry.
Select Enter.
11 Return to the System Programming menu.
Select Exit three times.
Dial Plan Routing
Dial plan routing provides a way to route incoming calls on a "per B-channel
group" basis. An incoming call is routed by matching the incoming number (by
service, number of digits, and pattern) and then optionally deleting and/or
adding digits to direct the call to a specific endpoint. A service must be
specified; the number of digits and pattern are optional. For example, you can
specify that calls received from a particular area code should be routed to the
specific individual or group responsible for accounts in that area.
Dial plan routing is available in Hybrid/PBX mode only. Key systems route
incoming calls on a per-line basis.
NOTE:
You can enter a service not shown on the Network Service screen by using the
five-digit binary code that represents the service in the Network Facilities
Information Element of ISDN PRI layer three signaling protocol. ( Contact your
service provider for more information about the codes. ) See "Miscellaneous
Procedures. "
IMPORTANT:
You must program a service before you program any other Dial Plan Routing
function. If you have not programmed a service, complete the procedure below
for the Service option and then repeat the procedure for each optional function
that you want to program.
Additional Information
Dial or type [ nn ].
Return to Step 7. The next slot will be
displayed on Line 1.
Programming Procedures
PC
←
[ F9 ]
[ F10 ]
[ F5 ] [ F5 ] [ F5 ]
4–139
