AT&T MERLIN LEGEND Release 3.0 System Programming Manual page 413

DS1 Facilities
Console Display/Instructions
10 Enter the channel number (
**** slot xx:
Enter channel num (1 to
24)
Delete
Next
Backspace
Enter
Exit
11 Specify the emulated trunks as TIE-PBX or Toll.
**** Type slot xx:
Select one
TIE-PBX
Exit Enter
12 Save your entry.
Select Enter.
13 Enter the channel number ( nn = 1 to 24 ).
TIE Lines Slot xx:
Enter channel num (1-24)
Delete
Next
Backspace
Enter
Exit
14 Assign or remove the channel.
Select Enter or
Delete.
Continue to assign the channel to another slot or go to Step 16.
15
Select Next.
16 Save your entry.
Select Enter.
Return to the System Programming menu.
17
Select Exit four times.
Additional Information
= 1 to 24).
nn
**** = option name selected in Step 8
xx = slot entered in Step 3
Dial or type [ nn ]
and go to Step 14.
**** = option selected in Step 8
xx = slot entered in Step 3
TIE-PBX: Transmit-receive loss set to 0/4.
Toll: Channels used for network services
transmit receive loss set to 0/6.
Select TIE-PBX or
Toll.
xx = slot number entered in Step 3
Dial or type [ nn ].
You may continue to assign or remove
additional channels by repeating the last
two steps.
Return to Step 13. The next slot will be
displayed on Line 1.
[ F10 ]
←
[ F10 ]
[ F10 ]
[ F5 ] [ F5 ] [ F5 ] [ F5 ]
Programming Procedures
PC
←
[ F1 ]
[ F2 ]
[ F8 ]
[ F9 ]
4–63
