DS1 Facilities
Summary: Type of DS1 Facility
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
4-60
Programming Procedures
System manager
All
100D module idle
Form 2c, System Numbering: Line/Trunk Jacks
Form 3b, Incoming Trunks: DS1 Connectivity
(100D module)
T1
T1, PRI
Yes
No
To select PRI:
LinesTrunks → LS/GS/DSl → Dial slot no. → Enter → Type →
PRI → Enter → Exit → Exit → Exit → Exit
To select T1: All Ground, All Loop, All DID, All Unequip:
LinesTrunks → LS/GS/DSl → Dial slot no. → Enter → Type →
T1 → Enter → More → Select type of emulation → Enter →
Exit → Exit → Exit → Exit
To select T1- Tie:
LinesTrunks → LS/GS/DSl → Dial slot no. → Enter → Type →
T1 → Enter → TIE-PBX or Toll → Enter → Dial channel no.
→ Enter → Exit → Exit → Exit → Exit
To select T1: Ground-Start, Loop-Start, All Tie, DID, or
Unequip:
LinesTrunks → LS/GS/DSl → Dial slot no. → Enter → Type →
T1 → Enter → More → Select type of emulation → Enter →
Dial channel no. → Enter → Exit → Exit → Exit → Exit
To select PRI:
[ F4 ] → [ F1 ] → Type slot no. → [ F10 ] → [ F1 ] → [ F2 ] → [ F10 ] → [ F5 ] → [ F5 ]
→ [ F5 ] → [ F5 ]
To select T1: All Ground, All Loop, All DID, All Unequip:
[ F4 ] → [ F1 ] → Type slot no. → [ F10 ] → [ F1 ] → [ F1 ] → [ F10 ] → [ PgUp ] →
Select type of emulation → [ F10 ] → [ F5 ] → [ F5 ] → [ F5 ] → [ F5 ]
To select T1- Tie:
[ F4 ] → [ F1 ] → Type slot no. → [ F10 ] → [ F1 ] → [ F1 ] → [ F10 ] → Select
facility → [ F10 ] → Type chanel no. → [ F10 ] → [ F5 ] → [ F5 ] → [ F5 ] →
[ F5 ]
To select T1: Ground-Start, Loop-Start, All Tie, DID, or
Unequip:
[ F4 ] → [ F10 ] → Type slot no. → [ F10 ] → [ F1 ]→ [ F1 ] → [ F10 ] → [ PgUp ] →
Select type of emulation → [ F10 ] → Type channel no. → [ F10 ] →
[ F5 ] → [ F5 ] → [ F5 ] → [ F5 ]
