AT&T MERLIN LEGEND Release 3.0 System Programming Manual page 230

Optional Group Features
Console Display/Instructions
6 Specify the extension.
Group Page xxxx:
Enter extensions
Delete
Backspace Next
Exit Enter
7 or remove the extension from the paging group.
Assign
Select Enter or
Delete.
8 Continue to assign the extension to another paging group or go to Step 9.
Select Next
Return to the System Programming menu.
9
Select Exit two times.
Group Coverage Member Assignments
Use this procedure to assign or remove an extension from a coverage group. A
coverage group is a group of senders. Coverage is an arrangement in which
calls from a group of senders are redirected to one or more receivers.
NOTE:
This procedure assigns senders. Before you begin, make certain that the
receivers for the coverage group are also programmed. Receivers can be
assigned through individual or centralized telephone programming. You can
also use the Integrated Solution 11/111 feature, Integrated Administration, to
assign coverage receivers. See Chapter 5, "Centralized Telephone
Programming, " for information about the appropriate centralized programming
procedure.
A maximum of 30 coverage groups are allowed, each with an unlimited number
of members. Up to eight receivers can be assigned per coverage group.
3–108
Common Administrative Procedures
Additional Information
= number entered in Step 4
xxxx
If no DSS is attached:
SP: "Entering an Extension"
If DSS is attached:
Toggle the red LED on or
off as required. Go to Step 9.
On = extension is included in paging
group.
Off = extension is not included in paging
group.
You may continue to assign or remove
extensions from the paging group by
repeating Steps 5 and 6.
Return to Step 6 to continue programming. The
next paging group will be displayed on Line 1.
PC
←
[ F10 ]
[ F8 ]
[ F9 ]
[ F5 [ F5 ]
