AT&T 555-630-140 August 1994 AT&T ® MERLIN LEGEND Communications System Release 3.0 Installation...
Page 2: Security Of Your System Preventing Toll Fraud
Copyright © 1994, AT&T AT&T 555-630-140 All Rights Reserved August 1994 Printed in U.S.A. Notice Every effort was made to ensure that the information in this book was complete and accurate at the time of printing. However, information is subject to change. See Appendix A, “Customer Support Information,”...
Page 3: Table Of Contents
Contents About This Book Intended Audience How to Use This Book Terms and Conventions Used Product Safety Labels xxii Security xxiii Related Documents xxiv How to Comment on This Document Introduction Installation Sequence System Forms Programming the System Upgrading the System Installing the Control Unit Overview AC Power and Grounding...
Page 4 Contents Installing the Control Unit, Continued 2-27 Installing Expansion Carriers 2-29 Installing the Processor 2-32 Installing the Modules 2-40 Replacing a Module 2-43 Connecting the Control Unit to an AC Outlet 2-44 Powering Up the System 2-45 Powering Down the System Installing Telephones and Adjuncts Installing Multi-Function Modules 3-22...
Page 5 Contents Installing the PC, CAT, or Printer Connecting a PC to the Control Unit Connecting a CAT to the Control Unit Connecting a Printer to the Control Unit Connecting Data Equipment Data Stations Analog Voice and Modem Data Stations Modem Data-Only Stations MLX Voice and Modem Data Stations 6-10 MLX Voice and 7500B Data Stations...
Page 6 Contents Installing Applications Voice Messaging Systems and Touch-Tone Receivers Automated Document Delivery System Call Accounting System Call Accounting Terminal Call Management System 8-12 CONVERSANT 8-13 Integrated Solution Ill 8-16 AT&T Attendant 8-17 MERLIN MAIL 8-20 MERLIN PFC 8-22 PassageWay Direct Connect Solution 8-24 System Programming and Maintenance (SPM) Upgrading the System...
Page 7 Contents System Numbering Forms Form 2a, System Numbering: Extension Jacks Form 2b, System Numbering: Digital Adjuncts Form 2c, System Numbering: Line/Trunk Jacks Form 2d, System Numbering: Special Renumbers Unit Load Calculation Worksheet Unit Load Worksheet Index Installation vii...
Page 8 Figures Installing the Control Unit 2-1. AC Grounding Requirements 2-2. Measuring the AC Outlet Voltages 2-11 2-3. Central Office and AC Grounds 2-15 Installing 146A and 147A Protectors 2-4. 2-18 Marking the Basic Carrier Screw Holes 2-5. 2-22 Installing a Copper Shield in the Power Supply 2-6.
Page 9 Figures Installing Telephones and Adjuncts, Continued Installing an MFM Module 3-9. 3-11 3-10. Setting and Adjusting the MFM Jumpers 3-12 3-11. Removing the Jack Guard 3-13 3-12. Placing the Module Cover into the Locating Slot 3-14 3-13. Lowering and Locking the Module Cover 3-15 3-14.
Page 10 Figures Installing Telephones and Adjuncts, Continued 3-52 3-33. Labeling the Extension 3-53 3-34. Removing the Handset Holder 3-53 3-35. Rotating the Handset Holder 3-54 3-36. Replacing the Extension Label 3-55 Mounting the Backplate 3-37. 3-56 Routing the Cord Through the Backplate 3-38.
Page 11 Figures Installing the PC, CAT, or Printer 5-1. Connecting a PC Within 50 ft. (15.2 m) 5-2. Connecting a PC More Than 50 ft. (15.2 m) Away 5-3. Connecting a CAT and Printer on the Same AC Outlet 5-10 5-4. Connecting a CAT and Printer on Different AC Outlets: Control Unit Connections 5-13...
Page 12 Figures Initializing and Testing the System 7-18 7–1. Ground-Start Button 7-21 7–2. Installing the Control Unit Top Cover 7-22 7–3. Installing the Control Unit Front Cover Upgrading the System 9–1. Removing the Control Unit Housing 9-2. Powering Down the System 9-3.
Page 13 Tables Installing the Control Unit 2-1. Environmental Requirements 2-2. AC Power Requirements 2–3. Heavy Lightning Protection 2-14 2-4. Setting the 400EM (Tie Trunk) Module DIP Switches 2-35 2-5. Signaling Formats for the 400EM (Tie Trunk) Module 2-36 Installing Telephones and Adjuncts 3-1.
Page 14 Tables Installing the PC, CAT, or Printer 5-1. AT&T 572 Printer Options 5-22 AT&T 5-2. 5-24 475/476 Printer DIP Switch Settings 5-3. AT&T 5-25 CAT Printer DIP Switch Settings Connecting Data Equipment 6–1. Data Station Configurations 6–2. 7500B Data Module Settings 6-20 Installing Applications 8-1.
Page 15 Safety The exclamation point in an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. IMPORTANT SAFETY INSTRUCTIONS When installing telephone equipment, always follow basic safety precautions to reduce the risk of fire, electrical shock, and injury to persons, including: Read and understand all instructions.
Page 16 Safety Do not install this product near water, for example, in a wet basement location. Do not overload wall outlets, as this can result in the risk of fire or electrical shock. The MERLIN LEGEND Communications System is equipped with a 3-wire grounding-type plug with a third (grounding) pin.
Page 17: Save These Instructions
Safety WARNING: For your personal safety, DO NOT install an MFM yourself. ONLY an authorized technician or dealer representative shall install, set options, or repair an MFM. To eliminate the risk of personal injury due to electrical shock, DO NOT attempt to install or remove an MFM from your MLX telephone. Opening or removing the module cover of your telephone may expose you to dangerous voltages.
Page 18 Safety Installation xviii...
Page 19: About This Book
About This Book The MERLIN LEGEND Communications System is an advanced digital switching system that integrates voice and data communications features. Voice features include traditional telephone features, such as Transfer and Hold, and advanced features, such as Group Coverage and Park. Data features allow both voice and data to be transmitted over the same system wiring.
Page 20 How to Use This Book Refer to the following documentation for additional information: Equipment and Operations Reference provides detailed information on system hardware, telephones, and other equipment. Feature Reference provides details on the features of the communications system. System Planning provides procedures and forms for planning a system for installation.
Page 21: Terms And Conventions Used
Terms and Conventions Used Terms and Conventions Used In this document, the terms in the following list are used in preference to other, equally acceptable terms for describing communications systems. Lines, Trunks and Facilities Facility is a general term that designates a communications path between a telephone system and the telephone company central office.
Page 22: Product Safety Labels
Product Safety Labels Typographical Conventions Certain type fonts and styles act as visual cues to help you rapidly understand the information presented: Purpose Example Italics indicate emphasis. It is very important that you follow these steps. You must attach the wristband before touching the connection.
Page 23: Security
Security CAUTION: Caution indicates the presence of a hazard that could cause minor personal injury or property damage if the hazard is not avoided. Security Certain features of the system can be protected by passwords to prevent unauthorized users from abusing the system. You should assign passwords wherever you can and limit knowledge of such passwords to three or fewer people.
Page 24: Related Documents
Related Documents Related Documents In addition to this book, the documents listed below are part of the documentation set. Within the continental United States, these documents can be ordered from the AT&T Customer Information Center by calling 1-800-432-6600. Title Document No. System Documents Introduction 555-630-117...
Page 25: How To Comment On This Document
How to Comment on This Document How to Comment on This Document We welcome your comments, both good and bad. Please use the feedback form on the next page to let us know how we can continue to serve you. If the feedback form is missing, write directly to: Documentation Manager AT&T...
Page 26 How to Comment on This Document xxvi Installation...
Page 27 FEEDBACK FORM MERLIN LEGEND Communications System Release 3.0 Installation, Programming, & Maintenance Title: Order No.: 555-630-140 Date: August 1994 Please rate the effectiveness of this book in the following areas: Poor Excellent Good F a i r Applicable Ease of Use Clarity Completeness Accuracy...
Page 28: Introduction
Introduction Installation of the MERLIN LEGEND Communications System involves the following: Installing the control unit Installing the telephones Connecting system wiring Installing optional equipment This chapter provides an overview of the installation process, which varies from customer to customer. Installation Sequence The following is a list of the components that the system can include and shows the order in which you should install them.
Page 29: System Forms
System Forms Connect the control unit to the network interface (required). Connect the channel service unit (CSU) to the 100D module on the control unit (required only with the 100D module). Connect the printer and PC to the control unit (optional). Connect data equipment to the control unit (optional).
Page 30: Line/Trunk Jacks
System Forms Installling the Control Unit Form 1, System Planning. Some procedures in Chapter 2, “Installing the Control Unit,” refer to the Control Unit Diagram, which is printed on the reverse side of this form. Form 3c, Incoming Trunks: Tie. If you install a 400EM module in the control unit, use this form to determine the appropriate switch settings prior to installation.
Page 31: Programming The System
Programming the System Form 3a, Incoming Trunks: Remote Access Form 3b, Incoming Trunks: DS1 Connectivity (100D Module) Form 3d, Incoming Trunks: DID Connecting Data Equipment The following forms indicate the data equipment you will need to set up data stations. Data Form 1a, Modem Data Station Data Form 1b, 75006 Data Station Data Form 2, Data Hunt Groups...
Page 32: Installing The Control Unit
Installing the Control Unit If you have not read Chapter 1, “Introduction,” do so before continuing with this chapter. Overview Installing the control unit involves the following procedures: Preparation requirements Installing the backboard Meeting the power and grounding requirements Checking the total unit load Installing the basic carrier Installing any expansion carriers Installing the power supply...
Page 33: Environmental Requirements
Overview The following sections provide detailed instructions for these installation procedures. Follow the procedures in the order in which they are presented. Environment The control unit must be installed on a backboard. The placement of the backboard, and the control unit on it, requires careful consideration. Make sure you install the backboard in an area that meets all of the environmental requirements listed in Table 2–1.
Page 34: Control Unit Requirements
Overview Electrical Noise/Radio-Frequency Interference In most cases, electrical noise is introduced to the system through trunk or telephone cables. However, electromagnetic fields near the control unit can also cause noise in the system. Therefore, you should not place the control unit and cable runs in areas where a high electromagnetic field strength exists.
Page 35 Overview — Basic carrier and two expansion carriers: 37 in. wide by 23 in. high by 12 in. deep Location — Within 5 ft. (152 cm) of an AC power outlet that is not switch- controlled — Within 25 ft. (762 cm) of the network interface, or use an Off- Premises Range Extender (OPRE) —...
Page 36: Ac Power And Grounding
AC Power and Grounding — Make sure that the material meets local building codes. Dimensions ® — With Systimax wiring: 7 ft. wide by ft. high — Without Systimax wiring: 6 ft. wide by 3 ft. high Installing the Backboard When you are certain that the backboard meets the requirements indicated above, or is the new lightweight plastic material backboard with preassembled equipment in place, attach the backboard to the wall.
Page 37 AC Power and Grounding Verify that all of the following power and grounding requirements are met: The load center of appropriate current rating must be equipped with circuit breaker(s) labeled 120 VAC, 15 amps. Each breaker must protect one dedicated quad AC outlet or two dedicated duplex AC outlets.
Page 38: Installing The Control Unit
AC Power and Grounding From AC Load Center (2 separately Ground Wire fused 15A circuits) #14 AWG 4" Box (RACO or equivalent) HUBBELL Receptacles (5262 15A or equivalent) 4“ Cover S i n g l e - P o i n t (RACO 807 Ground or equivalent)
Page 39: Ac Power Requirements
AC Power and Grounding Table 2-2. AC Power Requirements Parameter Value Nominal voltage 117VAC Voltage range 110-125 V AC Frequency 60 Hz +/– 5% Maximum current 3 amps per power supply Power consumption 225 watts per power supply AC Outlet Tests If the AC outlet tests indicate that any of the power requirements in Table 2-2 are not met, your customer must contact a licensed electrician.
Page 40 AC Power and Grounding If the circuit is properly grounded, the ye low and white lights on the tester turn on. 2 Unplug circuit tester. Using a Volt-Ohm Milliammeter (VOM) Set the VOM to the lowest scale on which you can read 130 V AC. 2 Measure the AC outlet voltages.
Page 41: Grounding Requirements
AC Power and Grounding Grounding Requirements Proper grounding of the installation site safeguards the system by protecting it from the following: Lightning Power surges Power crosses on central office trunks Electrostatic discharge (ESD) When installing the control unit, make sure you meet the following grounding requirements: The control unit, the central office trunk protector, and the AC power service panel should be as close to each other as possible.
Page 42: Central Office And Ac Grounds
AC Power and Grounding DIW or To Central Lines Network 25-Pair Cable Office or Wiring Line Interface Serving Field Protector Facility Coupled Bonding Conductor (optional) Cords (Power) (Supply ) Commercial Power #12 or #14 Plug Outlet Ground Power Wire Single - Service Point #6 AWG...
Page 43 AC Power and Grounding WARNING: Improper ground can cause equipment failures, service outages, and electrical shock. Verify that the AC power uses an approved ground for its primary ground, that all voltage-limiting devices are grounded to an approved ground, and that the ground is one of the approved grounds listed below.
Page 44 AC Power and Grounding Concrete-Encased Ground. Must be an electrode, consisting of one of the following: At least 20 ft. (6.1 m) of one or more steel reinforcing rods, each at least ½ in. (1.27 cm) in diameter 20 ft. (6.1 m) of bare copper conductor not smaller than AWG, encased in 2 in, (5 cm) of concrete This electrode must be located within and near the bottom of a...
Page 45: Heavy Lightning Protection
AC Power and Grounding Heavy Lightning Protection For most surges, adequate protection is provided by meeting the previously listed requirements. Additional protection is required when the customer is located in a heavy lightning area. Connect a 147A protector to the system to limit surges from the AC lines and up to four CO trunks.
Page 46: Installing 146A And 147A Protectors
AC Power and Grounding 146A 147A Protector Status Protector Indicator Light Ground Strap Ground Connection Strap AC Surge/Suppressor Protector CONTROL UNIT TEL CO LINE CONTROL UNIT TEL CO LINE CONTROL UNIT TEL CO LINE O u t l e t CONTROL UNIT TEL CO LINE Control Unit...
Page 47: Unit Loads
Unit Loads Unit Loads A unit load is a measure of power (1.9 watts) that you use to determine the electrical load that the components listed below place on the control unit’s power supply. Telephones and adjuncts 800 DID modules analog and digital Only the telephones and adjuncts that connect to the load calculation, When...
Page 48: Installing The Basic Carrier
Installing the Basic Carrier Unit Loads for Key or Behind Switch Mode In a Key or Behind Switch system with four or fewer modules, no calculation is needed. The power supply (model 391A1) generally supports four modules of any type. Auxiliary Power Units The power supply provides 54 unit loads to each carrier.
Page 49: Marking The Basic Carrier Screw Holes
Installing the Basic Carrier To install the basic carrier, follow the steps below: Mark the screw-hole locations on the backboard, using the basic carrier or the template supplied with the plastic preassembled backboard as a guide. See Figure 2-5. Make sure the carrier is level before marking the holes. Drill a pilot hole in the center of each of the four screw-hole marks.
Page 50: Installing The Power Supply
Installing the Power Supply Installing the Power Supply WARNING: Do not attach any cab/es or power cords to the power supply until it is installed in the carrier. Do not power up the control unit until all of the modules and power equipment are installed.
Page 51 Installing the Power Supply NOTE: It is not necessary to install ring generators in a new system with new012 (apparatus code 517G13 or later letter) modules or new 008 (apparatus code 5171328 or later letter). If you are upgrading or using older modules, see Maintenance and Troubleshooting.
Page 52 Installing the Power Supply Peel the backing paper from the larger copper-foil shield to expose its adhesive. 7 Position the foil on the lower part of the module. a The shields must meet. b They should not overlap or have any space between them. Installing the Control Unit 2-21...
Page 53: Installing A Copper Shield In The Power Supply
Installing the Power Supply Upper Copper Foil Shield Lower Copper Foil Shield Power Unit Information Label UL Label CSA Label Figure 2-6. Installing a Copper Shield in the Power Supply Tuck the foil shield tightly along the ledge (or crease) of the housing and place.
Page 54 Installing the Power Supply Installing the Power Supply Module in the Carrier 1 Lower the power supply module hook onto the rod on top of the carrier. 2 Make sure the connector on the module mates properly with the connector on the carrier. 3 Push the module into the carrier until it locks into place.
Page 55: Installing The Ferrite Cores
Installing the Power Supply CAUTION: Do not connect the power cord until the entire control unit is assembled. POWER SUPPLY MODULE AC Power Cord On/Off Power Indicator (Green LED) Ground Wire -48 VDC Auxiliary Power Input Jack On/Off Switch AC Power Input Attach Grounding Screw Ferrite Cores...
Page 56: Installing The Auxiliary Power Unit
Installing the Auxiliary Power Unit Installing the Auxiliary Power Unit The Control Unit Diagram on the back of Form 1, System Planning, indicates whether an auxiliary power unit is required for the carrier that you are installing. NOTE: Use the 9024 auxiliary power unit for new installations. You can continue to use a previously installed 335A auxiliary power unit, as long as no new telephones or modules are added to the carrier.
Page 57 Installing the Auxiliary Power Unit -48 VDC Auxiliary Power Auxiliary lnput Power Unit Input -48 VDC Power Cord Ferrite Ground Cores Wire AUX Power Unit Outlet AC Power Cord Control Unit AC Power Cord Figure 2-8. Installing an Auxiliary Power Unit 2-26 Installing the Control Unit...
Page 58: Installing Expansion Carriers
Installing Expansion Carriers Installing Expansion Carriers If you are adding an expansion carrier to an existing system, see “Upgrading the Control Unit” in Chapter 9 before continuing. If you are to install one or more expansion carriers, follow the steps below to mount each one.
Page 59: Connecting The Carriers
Installing Expansion Carriers BASIC CARRIER EXPANSION CARRIER CONNECTOR CARD EXTENDER (under the breakaway tab) BACKBOARD BASIC CARRIER EXPANSION CARRIER BACKBOARD Figure 2-9. Connecting the Carriers 2-28 Installing the Control Unit...
Page 60: Installing The Processor
Installing the Processor Installing the Processor Installing the processor includes the following procedures: If both of the following conditions are true, follow the procedures in Chapter 9, “Modifying the Processor for Key Mode.” — Form 1, System Planning, indicates Permanent Key mode. —...
Page 61 Installing the Processor CAUTION: Before touching leads, connectors, pins, and other components when handling the circuit board, use a properly grounded wrist strap to prevent damage from electrostatic discharge (ESD). Installing the Processor in the Carrier To install the processor in the carrier, follow the steps below, Refer to Figure 2-10.
Page 62: Installing The Processor Into The Carrier
Installing the Processor Figure 2-10. Installing the Processor into the Carrier Installing the Control Unit 2-31...
Page 63: Installing The Modules
Installing the Modules Installing the Modules CAUTION: Use a properly grounded wrist strap to prevent damage from electrostatic discharge (ESD) when installing the modules, and avoid touching leads, connectors pins, and other components. Guidelines Follow these guidelines when you install modules, as indicated on the Control Unit Diagram of Form 1, System Planning: Do not leave empty slots between modules.
Page 64 Installing the Modules Installing Modules To install modules starting from slot 1 (the first open slot next to the processor), follow the steps below: For each 400EM tie line/trunk module, for jacks numbered 1 through 4 in Figure 2-11, check Form 3c, incoming Trunks: Tie, for E&M signaling type.
Page 65 Installing the Modules Tie Trunks Tie trunks connect two separate PBX communications systems either directly or through one or more central offices, as if they were one system at the same location, In the MERLIN LEGEND Communications System, the 400EM module is the originating and terminating unit for tie trunk operation.
Page 66: Setting The 400Em (Tie Trunk) Module Dip Switches
Installing the Modules E&M Mode —Type 1 Standard (default factory setting). This setting is used to connect two systems through telephone company facilities. —Type 1 Compatible. This setting connects two systems directly (without using telephone company facilities). Simplex Mode —Type 5. This setting is used on 4-wire (2-pair) circuits. 400EM (Tie Trunk) Module DIP Switches During installation of 400EM (Tie Trunk) modules, refer to Table 2-4 and Table 2-5, and to Figure 2-11 for the correct DIP switch settings for varying...
Page 67: Signaling Formats For The 400Em (Tie Trunk) Module
Installing the Modules NOTE: DIP switches 1, 2, 6 and 7 determine whether the tie trunks are protected or unprotected. DIP switches 3, 4, 5, 8, 9, and 10 determine the mode. Simplex mode is always protected. Therefore the Protected/Unprotected settings for DIP switches 1, 2, 6 and 7 have no effect.
Page 68: 400Em Module Sample Dip Switch Settings For Signaling Types 1C And
Installing the Modules 400 EM Module Switches 1 through 5 control Port 4 (1C. E&M unprotected) Switches 6 through 10 control Port 3 (1C. E&M protected) Switches 1 through 5 control Port 2 (5 simplex) Switches 6 through 10 control Port 1 (1C.
Page 69 Installing the Modules Labeling After all modules have been installed, label all jacks with the numbered labels provided with the feature module. Line/trunk labels have green numbers on off-white background. labels have blue numbers on off-white background. Telephone See Figure 2-12 for the locations of line/trunk jacks and telephone jacks on each module, and label them as described next.
Page 70: Line/Trunk And Telephone Jack Locations On Each Module
Installing the Modules PFT Jack Line/Trunk or Off-Premise Telephone Jacks on 008 OPT Module Extension Telephone Jacks (Analog or Digital) * These four jacks are used for extension telephones on the 012 Module. Figure 2-12. Line/Trunk and Telephone Jack Locations on Each Module Installing the Control Unit 2-39...
Page 71: Replacing A Module
Replacing a Module Replacing a Module CAUTION: This section does not apply to the processor or power supply. Although the system allows you to remove and replace modules without affecting call processing, partially inserting and removing a module can cause a cold start. To add a 100D module or change any of its DS1 parameters, the system must be idle.
Page 72 Replacing a Module To remove and replace a module, follow the steps below, Refer to Figure 2- Busy-out or reset the module. (Busy-out is recommended.) Label all cords (if they are not labeled already) and then unplug them from the module. For information about labeling trunk and extension cords, see Chapter 3, “Installing Telephones and Adjuncts”...
Page 73: Removing Modules From The Carrier
Replacing a Module Figure 2-13. Removing Modules from the Carrier 2-42 Installing the Control Unit...
Page 74: Connecting The Control Unit To An Ac Outlet
Connecting the Control Unit to an AC Outlet Connecting the Control Unit to an AC Outlet CAUTION: Make sure the AC outlet has been tested for proper grounding. The outlet should be 117-V AC, 60-Hz, 3-wire (phase, neutral, ground). See “AC Outlet Tests,”...
Page 75: Powering Up The System
Powering Up the System Powering Up the System CAUTION: Follow the procedure below to power up the system only if the system is completely installed, failure to comply with this procedure can result in shock hazard or damage to the equipment. 1 Turn on the power switch for each expansion carrier: start with the power supply in the rightmost carrier.
Page 76: Powering Down The System
Powering Down the System Powering Down the System You may need to power down the system for troubleshooting during installation, or to add new equipment to the carrier. CAUTION: Follow these steps in the exact sequence. To power the system, follow the steps below. down Turn off the power supply on the basic carrier.
Page 77 Powering Down the System 2-46 Installing the Control Unit...
Page 78: Installing Telephones And Adjuncts
Installing Telephones and Adjuncts The control unit supports the MLX-10, MLX-10D, MLX-10DP, MLX-20L, and MLX-28D telephones, with or without Direct Station Selectors (DSSs), as well as analog multiline and single-line telephones. It also supports various adjuncts, which may require Multi-Function Modules (MFMs) or other adapters for installation.
Page 79 Installing Multi-Function Modules Tip/ring (T/R) devices such as single-line telephones, fax machines, modems, and credit card verification terminals. Once connected, the MLX telephone and adjunct work independently of each other. This means they can send and receive calls at the same time. The MFM is the only T/R adapter you can use with MLX telephones.
Page 80: Multi-Function Module Packing List
Installing Multi-Function Modules 400B Adapter or 400B2 Adapter Power Supply (KS22911) D6AP Cord (7 feet long) Multi-Function Module Figure 3-1. Multi-Function Module Packing List RISK OF ELECTRICAL SHOCK: Follow all warnings and cautions. WARNING: a qualified technician should install, repair, or set options for an Only MFM.
Page 81: 3-4 Installing Telephones And Adjuncts
Installing Multi-Function Modules Before installing an MFM, disconnect all trunk and/or power cords that are attached to the MLX telephone. This is to ensure that no hazardous voltages are present during installation. Ringing voltage from the MFM attached to the MLX telephone can cause electrical shock if adjustments are made while the cords are connected.
Page 82: Installing Telephones And Adjuncts
Installing Multi-Function Modules Pull Up Away Press Center Tab Figure 3-3. Releasing the Deskstand 2 Release and remove the deskstand from the telephone, See Figure 3-3 and Figure 3-4. a Press on the top rear center of the deskstand to release the tab. b Pull the deskstand up toward you and swing away from the telephone.
Page 83: Removing The Deskstand
Installing Multi-Function Modules Lift out of Center Slot Figure 3-4. Removing the Deskstand Lift the deskstand out of the locating slot in the telephone base and place to one side. 3-6 Installing Telephones and Adjuncts...
Page 84: Releasing The Module Cover
Installing Multi-Function Modules Figure 3–5. Releasing the Module Cover Screw 3 Release and remove the module cover. See Figure 3-5, Figure 3-6, and Figure 3-7. a Use a screwdriver to remove the screw in the lower righthand corner of the module cover.
Page 85 Installing Multi-Function Modules Pull Up and Away Press Center Tab to Release M F M Module Cover L o c a t i n g Slot Figure 3-6. Releasing the Module Cover b Press the center of the right side of the module cover with one hand to release the locking tab.
Page 86: Removing The Module Cover
Installing Multi-Function Modules L i f t Out of locating Slot Figure 3–7. Removing the Module Cover d Lift module cover out of locating slot and place to one side. Installing Telephones and Adjuncts 3–9...
Page 87: Removing An Mfm Module
Installing Multi-Function Modules Locking Tab Line Jack Handset Jack Locking Tab Socket — Connector Pins Locking Tab Figure 3-8. Removing an MFM Module 4 To install a new MFM, go to Step 5. To reset jumpers on an existing MFM, go to Step 6.
Page 88: Installing An Mfm Module
Installing Multi-Function Modules Locking Tab Socket Connector Pins Locking Tab Line Jack Handset Jack L o c k i n g T a b Figure 3-9. Installing an MFM Module 5 Install the new MFM. See Figure 3-9. a Hold the MFM circuit board by the edges with the long connector pins facing the socket.
Page 89: Setting And Adjusting The Mfm Jumpers
Installing Multi-Function Modules Multi-Function Module Pins Jumper Placement SAA Setting T/R Operation Setting A, C, X and Z A, B, W and Y Figure 3–10. Setting and Adjusting the MFM Jumpers Set or adjust the MFM jumpers for either a T/R device or a supplemental alert device.
Page 90: Removing The Jack Guard
Installing Multi-Function Modules MFM Jack Guard Cover Figure 3-11. Removing the Jack Guard 7 To remove the jack guard, see Figure 3-11. a If the module cover has a square jack guard that protects the TEL/OTHER jack area, grasp and twist the guard to remove it. Save the jack guard if you are wall-mounting an MLX-10 or MLX-10D telephone.
Page 91: Placing The Module Cover Into The Locating Slot
Installing Multi-Function Modules Lower C o v e r Into Locating Slot Figure 3–12. Placing the Module Cover into the Locating Slot 8 To replace the module cover, see Figure 3-12, Figure 3-13, and Figure 3-14. a Place the locking tab on themodule cover into the slot on the left side of the telephone.
Page 92: Lowering And Locking The Module Cover
Installing Multi-Function Modules Lower and Press Into Center Slot to Secure Figure 3-13. Lowering and Locking the Module Cover Lower the cover to the right and press firmly into the center slot to lock the tab in place. The tab must be secure. Installing Telephones and Adjuncts 3-15...
Page 93 Installing Multi-Function Modules Figure 3-14. Replacing and Tightening the Module Cover Screw c Replace and tighten the module cover screw that you removed in Step 3. 3–16 Installing Telephones and Adjuncts...
Page 94: Replacing The Deskstand
Installing Multi-Function Modules Lower Into Inner Center Slot Figure 3-15. Replacing the Deskstand Replace the deskstand. See Figure 3-15. If you are wall-mounting an MLX-10, MLX 10D, or MLX-10DP telephone, go to Step 11; otherwise, continue with Step 9a. Place the tab on the narrow edge of the deskstand, into the locating slot on the telephone base.
Page 95: Lowering The Deskstand And Locking Into Place
Installing Multi-Function Modules Lower Press Into Center slot Figure 3–16. Lowering the DeskStand and Locking into Place b Lower the deskstand and lock into place. 3-18 Installing Telephones and Adjuncts...
Page 96: Replacing The User Card Tray And Line Cable
Installing Multi-Function Modules Deskstand Telephonet C a r d B a s e Tray L i n e C a b l e Figure 3–17. Replacing the User Card Tray and Line Cable Replace the user card tray and line cable. See Figure 3-17. a Insert the user card tray at an angle, then lower and slide into the deskstand.
Page 97: Adjusting The Deskstand Height
Installing Multi-Function Modules Pull Up Press Center Tab Card Tray Deskstand Telephone B a s e Line Cable Figure 3-18. Adjusting the Deskstand Height 11 Adjust the deskstand height. See Figure 3-18. a To change the deskstand’s height from low to high, press the top rear center of the deskstand to release the tab.
Page 98: Powering Up The Telephone After Installing The Mfm
Installing Multi-Function Modules AC Power Outlet Wall Jack D6AP Power Supply 400B2 Adapter D 8 W Figure 3–19. Powering Up the Telephone after Installing the MFM b Connect one end of the D6AP cord to the 2-conductor (small) modular jack on the 40013 or 40092 adapter, and plug the other end into the modular jack of the 406943837 power supply.
Page 99: Installing Adjuncts
Installing Adjuncts c Plug the power supply into a 117-V AC outlet that is not controlled by a wall switch. d Insert the plug end of the 400B or 400B2 adapter into the wall jack. Test the MFM for T/R operation. See “Testing MLX Telephones with MFMs”...
Page 100: Routing The Cord(S) Through The Cord Channel
Installing Adjuncts Adjunct D 8 W Cord Channel D4BU Connects to TEL/OTHER J a c k 400B L i n e MLX-10™ Desk Telephone D 8 W Line M L X - 1 0 ™ Wall-Mounted Telephone Figure 3–20. Routing the Cord(s) Through the Cord Channel 4 To connect an adjunct to a single-line telephone: a Connect a 26A2 bridging adapter to the telephone.
Page 101 Installing Adjuncts 5 To connect an adjunct to an analog multiline telephone: a Connect a 4-pair cord to the OTHER jack on the telephone. b Connect the other end to the VT jack on a General Purpose Adapter (GPA). c Connect the cord from the adjunct to the TEL/EQUIP jack on the GPA. d Go to Step 7.
Page 102: Dial Dictation Devices
Installing Adjuncts Slide the switch on the back of the GPA to the setting that provides the required service. Basic. This setting is used to dial and answer calls from an analog multiline telephone or to attach a T/R adjunct such as a single-line telephone or answering machine.
Page 103 Installing Adjuncts Fax Machines You can connect a fax machine to one of the following, as described earlier in this chapter: 012 module MLX telephone with an MFM The fax machine can send and receive fax calls independently of the telephone.
Page 104 Installing Adjuncts If you connect a credit card verification terminal to an MFM, the terminal can place and receive calls independently of the MLX telephone. Do not use a GPA to connect a credit card verification terminal to the system, because the terminal cannot dial out through the GPA.
Page 105 Installing Adjuncts Manual Operation (Analog Multiline Telephones Only) Manual operation is appropriate when a headset is used occasionally. You pick up the handset to answer a call and replace it to hang up. The headset consists of the headpiece, and a modular base unit. The headpiece plugs into the modular base unit, and the modular base unit connects to the telephone through the HANDSET jack on the side of the telephone.
Page 106: Manual And One-Touch Headset Operation
Installing Adjuncts OTHER Jack (underside) Headpiece Headpiece Modular Modular Base Base U n i t 502C Adapter Unit Plug Prong Base Unit Headpiece H a n d s e t Jack Handset Jack Manual Operation One-Touch Operation One-Touch Operation (Analog Multiline (Analog Multiline Telephones) (MLX Multiline Telephones only)
Page 107 Installing Adjuncts Dual-Tone Multifrequency (DTMF) Signaling You can connect external paging systems that use dual-tone multifrequency ® (DTMF) signaling, such as PagePac Plus with Zone Expansion Unit paging systems, to an LS or GS line/trunk jack programmed for paging operation, including bidirectional paging operation (talk-back).
Page 108: Single-Zone Paging With Pagepac Plus
Installing Adjuncts PAGEPAC PLUS OUTPUTS Speaker PAGING INPUT MUSIC D4BU Cord Control Unit Figure 3-22. Single-Zone Paging with PagePac Plus Installing Telephones and Adjuncts 3-31...
Page 109: Single-Zone Paging With Customer-Supplied Amplifier
Installing Adjuncts CUSTOMER-SUPPLIED AMPLIFIER OUTPUTS voice coil Speaker PAGE INPUT D4BU Cord 117VAC HARRIS/DRAC0N Model Loop-Start Trunk 22050-900 Adapter D4BU Cord +24V POWER C A B L E * 117VAC WHEELOCK Control Unit POWER SUPPLY MODEL EPS-2401 WARNING! The black wire from the LS trunk adapter power cable must be connected to the + (positive) input of the Wheelock PS.
Page 110: Single-Zone Paging With Upam
Installing Adjuncts PAGEPAC 20 OUTPUTS Speaker PAGING INPUT Connection D4BU Block MUSIC Cord 103A 12345678 Universal Paging Access 103A Module 4 PT 12345678 5 PR BOGEN Model PAM CC405258013 ACCESS MODE Set the AUTO-MANUAL Access Mode switch to 29 R MANUAL 30 T POWER...
Page 111 Installing Adjuncts MERLIN Identifier MERLIN Identifier™ allows the use of local telephone company caller identification services to receive, store and use calling party number information. Before installation, verify that this service provided by the Central Office is available on the lines to be connected. Each MERLIN Identifier consists of the following: A control unit, which must be located near the MERLIN LEGEND control unit...
Page 112 Installing Adjuncts NOTE: When a modem is connected to the TEL/OTHER jack on the MLX telephone equipped with an MFM, data calls can be made from the modem independently of the MLX telephone. Users dial data calls from the data terminal keyboard.
Page 113: Single-Zone Paging With Background Music And Magic On Hold
Installing Adjuncts PAGEPAC 20 OUTPUTS PAGING Speaker INPUT Connection D4BU MUSIC Block V A C Cord 103A Control 12345678 Unit 13 UNIVERSAL PAGING ACCESS MODULE 103 A 4 PT MUSIC 12345678 5 PR PORT BOGEN Connection Model PAM Block CC405258013 ACCESS MODE Set the AUOT-MANUAL...
Page 114: Multizone Paging With Background Music, Magic On Hold, And Bidirectional Paging (Talk-Back)
Installing Adjuncts PAGEPAC PLUS MUSIC IN AmpIiCenter PAGE INPUT 117VAC D4BU Cord Controller SWITCH PAGE INPUT J101 Zone Expansion Unit ‘ ( D4BU MUSIC Cord PORT Mic/Speaker Mic/Speaker Control Unit Standard Phono Mic/Speaker Patch Cord BKGD Music Source Music In Music Coupler MAGIC ON HOLD CC405476452...
Page 115: Supplemental Alerts
Installing Adjuncts Supplemental Alerts Alerting devices notify people working in noisy areas of outside, transferred, and intercom calls. Connect an alert to one of the following: Single-line telephone MLX telephone with an MFM Supplemental Alert Adapter (SAA) and analog multiline telephone Alerts compatible with the SAA include horns, bells, chimes, and strobes.
Page 116: Installing The Supplemental Alert Adapter
Installing Adjuncts Supplemental Alert Adapter CONTROL TELEPHONE UNIT ALERTER ON OFF Telephone Wall Jack Alerter Figure 3-27. Installing the Supplemental Alert Adapter Unsupported Telephones, Adjuncts, and Adapters Do not connect the following analog telephone adjuncts and adapters to the system. Doing so may cause damage to the device or the system. Basic Telephone and Modem Interface (BTMI) Basic Telephone and Modem Interface 2 (BTMI-2)
Page 117: Unsupported Telephones And Adjuncts
Installing Adjuncts MTR Interface (MTRI) Off-Premises Extension Unit (OPX) System 25 Direct Extension Selector (DXS) See Table 3-1 for additional notes on unsupported telephones and adjuncts. Table 3–1. Unsupported Telephones and Adjuncts Model Notes Digital Communications Protocol (DCP) 51013 Personal Terminals DCP telephones 7400 telephones and adjuncts (asynchronous data units and multiple asynchronous data units) that use DCP...
Page 118 Installing Adjuncts Table 3-2. Single-Line Telephones Model Description 2500MMGB Basic desk telephone Basic wall telephone 2554MMGJ 2500YMGK* Basic desk telephone with Message light and button; Recall Recall button used instead of switchhook for features that require a switchhook flash. 2500SM Basic desk telephone used with 4A speakerphone 2514BMW Basic desk telephone with built-in headset jack...
Page 119: Single-Line Telephones Supported By Release
Installing Adjuncts Single-Line Telephones in Release 3.0 and Later In Release 3.0 and later, only single-line telephones with positive disconnect are fully supported as system telephones (any single-line telephones, equipped with a ground-start button if necessary, can be used as PFT telephones).
Page 120: Installing Direct Station Selectors
Installing Direct Station Selectors Installing Direct Station Selectors The Direct Station Selector (DSS) is an optional piece of telephone equipment. You can connect up to two DSSs to an MLX-28D or MLX-20L telephone that is programmed as an operator console. Considerations Review the following items before you begin the installation procedure.
Page 121 Installing Direct Station Selectors To connect a DSS, follow the steps below. If you are connecting two DSSs to the telephone, unpack the second DSS before you start. 1 Adjust the angle of the DSS. The DSS is packed fully assembled with the deskstand in the low position.
Page 122: Connecting One Or More Dsss
Installing Direct Station Selectors D8AC DSS 1 DSS 2 MLX Telephone D8AC DSS 1 Telephone Dss 2 Figure 3–28. Connecting One or More DSSs 4 Wire the telephone to the DSS unit(s). See Figure 3-28. Remove the handset from the telephone, then place the telephone face down on a flat surface to the right of the upside-down DSS unit(s).
Page 123: Wiring For Auxiliary Power
Installing Direct Station Selectors AC Power O u t l e t Wall Jack I* I D 6 A P Power Supply 400B2 Adapter D 8 W Figure 3–29. Wiring for Auxiliary Power Turn the telephone and the DDS unit(s) faceup with the telephone now to the left of the DDS unit(s).
Page 124 Installing Direct Station Selectors b Connect one end of the D6AP cord to the 2-conductor (small) modular jack on the 400B or 400B2 adapter, and plug the other end of the cord D6AP into the modular jack of the 406943837 or 406743419 power supply. CAUTION: Do not plug the D6AP cord into the 8-conductor (large) modular jack of the 400B or 40052 adapter.
Page 125: Assembling Mlx Telephones
Assembling MLX Telephones Assembling MLX Telephones You will need to assemble an MLX telephone before connecting it to the control unit. For all other telephones, skip to “Connecting Telephones to the Control Unit.” Considerations Review the following items before you begin the procedure: MLX telephones are packed with the deskstand in the low position.
Page 126: Adjusting Or Removing The Deskstand
Assembling MLX Telephones Pull Up a n d Away Press Center Tab Figure 3-30. Adjusting or Removing the Deskstand To assemble an MLX telephone, follow the steps below. 1 Remove or adjust the deskstand. See Figure 3-30. If you want to leave the deskstand in the low position, go to Step 2. If you want to adjust the angle of the deskstand, or remove it in order to wall-mount the telephone: a Place the telephone face down on a flat surface.
Page 127: Connecting The Line Cords
Assembling MLX Telephones A d j u n c t D 8 W Cord Channel D4BU Connects to TEL/OTHER 400B J a c k Line Line — Ii’ M L X - 1 0 MLX-10™ Desk Telephone Wall-Mounted Telephone Figure 3-31. Connecting the Line Cords 2 Connect the line cords.
Page 128: Removing The Extension Label
Assembling MLX Telephones Paper Clip Figure 3–32. Removing the Extension Label 3 Connect the handset. Insert end of the coiled H4DU handset cord into the handset. 4 Label extension identification card. a Insert a straightened paper clip into the hole on the side of the plastic cover while holding your finger on the opposite edge;...
Page 129: Labeling The Extension
Assembling MLX Telephones MLX-10 555-1234 Figure 3-33. Labeling the Extension b Type or write the assigned extension number on the card. See Figure 3-33. If you are wall-mounting an MLX-10, MLX-10D, or MLX-10DP telephone, go to Step 5. If you are assembling a desk telephone, go to Step 6. 3–52 Installing Telephones and Adjuncts...
Page 130: Removing The Handset Holder
Assembling MLX Telephones Figure 3-34. Removing the Handset Holder MLX-10 Figure 3-35. Rotating the Handset Holder 5 Prepare the handset holder for wall-mounting. a Remove the handset holder by pushing up and pulling it out. See Figure 3-34. b Rotate the handset holder 180 degrees and replace it in its slot. See Figure 3-35.
Page 131: Replacing The Extension Label
Assembling MLX Telephones Figure 3–36. Replacing the Extension Label plastic cover. Replace the extension label and Figure end into place. a Insert one end into the slot and snap the other 3-36. If you are mounting an MLX-10, MLX-10D, or MLX-10DP wall telephone, go to Step 7.
Page 132: Mounting The Backplate
Assembling MLX Telephones Jack Plug Jack Guard Mounting Plate 630B Phone Mount Figure 3–37. Mounting the Backplate d Attach the backplate to the wall; see the instructions provided with the 6306 Phonemount. e Insert the two short screws provided with the Phonemount into the mounting plate.
Page 133: Routing The Cord Through The Backplate
Assembling MLX Telephones Mounting Plate 6306 Figure 3-38. Routing the Cord Through the Backplate Plug the free end of the cord into the LINE jack on the back of the telephone. Route the cord through the cord channel above the jack. See Figure 3-38.
Page 134: Installing Cordless Or Cordless/Wireless Telephones
Installing Cordless or Cordless/Wireless Telephones b Type or write the button assignments on the card. Insert the card and replace the plastic cover. Be sure the textured side of the cover is facing you. 9 Adjust the contrast on the telephone% display. For an MLX-20L telephone, slide the lever on of the telephone.
Page 135: Connecting Telephones To The Control Unit
Connecting Telephones to the Control Unit The charging base station requires only a three-prong AC outlet that is not connected to a wall switch. The telephone handset must be within range of the radio base. The indoor range is 400 through 600 ft. and the outdoor range is up to 1000 ft.
Page 136 Connecting Telephones to the Control Unit MLX telephone or analog multiline telephone is in a different building from the control unit, and is within 1000 ft. (305 m) of the control unit, connect the telephone to the control unit, using two ln- Range Out-of-Building (lROB) protectors.
Page 137 Connecting Telephones to the Control Unit WARNING: National and local building codes specify the type of cable required for telecommunication wiring. For example, indoor wiring (DIW cable) cannot be used inside or on top of air plenums or ducts, along hot pipes, or across walkways.
Page 138: Connecting Two Voice Pairs To A Telephone Using A Bridging Adapter (Br-241-B1)
Connecting Telephones to the Control Unit Central Office Lines Bridging Adapter (BR-241-B1) EVEN Station ODD # L i n e Telephone Figure 3-39. Connecting Two Voice Pairs to a Telephone Using a Bridging Adapter (BR-241-B1) Installing Telephones and Adjuncts 3-61...
Page 139: Removing Damaged Connecting Blocks
Connecting Telephones to the Control Unit Removing Damaged Connecting Blocks In some cases, a connecting block becomes damaged and must removed. To remove a damaged connecting block, follow the steps below: Remove the wires or the patch cord from the connecting block. If you have Interconnect Wiring, use long-nosed pliers to remove the telephone wires, and tag the wires with tape to identify their positions.
Page 140: Removing The Connecting Block
Connecting Telephones to the Control Unit Pliers 788 K1 Retainer Tool Figure 3-40. Removing the Connecting Block Installing Telephones and Adjuncts 3–63...
Page 141 Connecting Telephones to the Control Unit 3-64 Installing Telephones and Adjuncts...
Page 142: Connecting The Control Unit To The Network Interface
Connecting the Control Unit to the Network Interface The way you connect the control unit to the network interface depends on the type of network interface that is installed. While there are many ways you can do this, the methods discussed in this chapter are usually best. CAUTION: The telephone company is responsible for providing appropriate protection for central office trunks, Do not connect the central office...
Page 143: Wiring
Wiring Wiring The local telephone company should have installed the network interface (the central office trunks) already. Before you install the system, verify that the network interface is the proper type and that it is within 25 ft. (7.6 m) of the control unit.
Page 144: Connecting The Control Unit To The Network Interface
Wiring NOTE: you need to connect the trunk cords differently from the instructions on the system forms, record each change on Form 2c, System Numbering: Line/Trunk Jacks. See Appendix A, “System Numbering Forms. ” Also, you may need to know the interface codes for network facilities, These codes are shown in Table 4–2, by trunk type and adapter type.
Page 145: Rj21X Interface
Wiring RJ21X Interface The RJ21X network interface has a female 50-pin (25-pair) amphenol connector, as shown in Figure 4–1. the RJ21X interface to the control unit, you must build a wiring connect field between the RJ21X interface and the control unit using a 66-type block (RJ21).
Page 146: Connecting The Control Unit To The Network Interface
Wiring 66-Type Block (RJ21-type) 25-Line Interface Line Tip Ring Phone Number 555-3827 Line 1 555-3828 Line 2 555-3829 Line 3 555-3851 Line 4 Line 5 USOC Line 6 CUSTOMER JACJ NO. 4 Jacks 1 pr. RJ21X Amphonol To/From 1 pr. Plug Control U n i t...
Page 147: Rj21X Wiring Field Hardware
Wiring Building the Wiring Field Build the wiring field between the network interface and the control unit using 110AB1-100JP12 termination blocks with modular jacks and associated hardware. Figure 4-2 shows the hardware you need, including 110AB1- 100JP12 termination blocks with modular jacks, 110A1 wire troughs, D-rings, and D2R cords.
Page 148: Rj21X Wiring Field Tools
Wiring AT-8762D lmpact Tool 110 Impact Tool 788J1 788 K1 Retainer T o o l Spudger Modular Plug Pressers Figure 4-3. RJ21X Wiring Field Tools To connect the RJ21 X network interface to the control unit, follow the steps below. Figure 4–3 shows the tools you need. 1 For each piece of hardware, drill two diagonally opposite holes into the backboard, allowing for a 1/16-inch (1.6 mm) space between each piece of hardware.
Page 149: Using The D-Impact Tool To Seat The Conductors
Wiring If necessary, repeat Steps 1 and 2 for a second column. Run the 25-pair amphenol cable on the RJ21X interface to the termination blocks. If more length is needed, use an A25D male-connector, single-ended, 25-pair, nonplenum cable. Mount the D-rings to properly dress the wires, as needed. Cutoff the amphenol connector nearest to the cross-connect field and strip the wires for each of the 25 pairs.
Page 150 Wiring Test the central office trunks for proper connection. See “Testing Trunks,” later in this chapter, for instructions. Label the network interface jacks, control unit module jacks, termination blocks, and D2R cords. See “Labeling Trunks,” later in this chapter, for instructions. For each trunk, plug one end of a D2R cord into the designated jack on the termination block and the other end into the line/trunk jack on the proper control unit module.
Page 151: Rj11 And Rj14 Interfaces
Wiring RJ11 and RJ14 Interfaces RJ11 and RJ14 However, interfaces are connected to the control unit similarly. note the following differences: one central office trunk per jack. RJ11 connects two trunks per jack. RJ14 connects Plug a 267C-type adapter into each RJ14 jack. You need D2R cords for RJ11 jacks.
Page 152 Wiring CAUTION: Incorrect wiring can damage the ports and cause them to stop functioning. Make sure you use the proper cords. For all GS/LS modules, do the following: Use a D2R cable from an RJ11. Do not use the Brand-Rex Quad cable from an E66 block. If you cannot avoid using the Brand-Rex Quad cable, reverse the tip and ring leads at the E66 block to correct the mismatch.
Page 153: Testing Trunks
Testing Trunks CAUTION: Be careful not to connect tie trunks to GS, LS or DID ports. Since all the jacks on the termination block are 8-wire jacks, it is possible to interchange tie trunk wires with GS, LS, or DID wires accidentally. RJ48C/X Interface The RJ48C/X interface terminates a DS1 trunk at the customer’s premises.
Page 154 Testing Trunks 2 If you find a central office trunk that does not have dial tone, check for a bad adapter or loose connection. If adapters and wiring are in working order but you still do not hear a dial tone, notify the AT&T Service Center acting as the customer’s agent.
Page 155: Labeling Trunks
Labeling Trunks If you find a central office trunk that does not have dial tone, check for a bad adapter or loose connection. adapters and wiring are in working order but you still do not hear dial tone, notify the AT&T Service Center acting as the customer’s agent. If you cannot dial out on any of the trunks, notify the AT&T Service Center acting as the customer’s agent.
Page 156 Installing the Channel Service Unit only the ACCULINK CSUs are available for installation. For more information about the ESF T1 CSU and the 551 T1 CSU, see Maintenance and Troubleshooting. The operator’s guides shipped with the ACCULINK CSUs provide detailed installation, set-up and operation, and maintenance and troubleshooting information.
Page 157 Installing the Channel Service Unit There are no DIP switch options. All options are set via software commands. Access the options in the following ways: — Locally, from the front panel — 2400-bps modem. The front panel of a Remotely, using the integral local ACCULINK, in Passthrough mode, can access and option a remote —...
Page 158: Front Panel
Installing the Channel Service Unit AT&T Paradyne ACCULINK < > NET EQPT NET OK FAIL TEST, SIG 00F ALRM EEr SIG 00F ALRM PDV BPV OUT OUT EQPT 3150 N E T W O R K Figure 4-6.3150 Front Panel NETWORK POWER AUX PORT COM PORT MODEM...
Page 159 Installing the Channel Service Unit 4-18 Connecting the Control Unit to the Network Interface...
Page 160: Installing The Pc, Cat, Or Printer
Installing the PC, CAT, or Printer Once you complete the installation procedures presented in the previous chapters, you can connect a Station Message Detail Recording (SMDR) or Call Accounting Terminal (CAT) printer and a personal computer (PC), or a CAT and CAT printer, to the system. Connecting a PC to the Control Unit You can use a PC with MS-DOS 3.3 or higher and SPM 3.XX for SMDR, system programming, or maintenance.
Page 161 Connecting a PC to the Control Unit Connecting a PC Within 50 Feet Use this procedure to connect a PC to the control unit when the PC is within 50 ft. (15.2 m) of the control unit. You need the following hardware for this procedure: 355AF adapter D8W cord EIA-232-D cable (optional)
Page 162: Installing The Pc, Cat, Or Printer
Connecting a PC to the Control Unit Processor Module SMDR Jack ADMIN Jack EIA-232-D 355AF Control Unit Adapter Figure 5-1. Connecting a PC Within 50 ft. (15.2 m) Installing the PC, CAT, or Printer 5-3...
Page 163 Connecting a PC to the Control Unit Connecting a PC More Than 50 Feet (15.2 m) Away Use this procedure to connect a PC to the control unit when the distance is 50 ft. (15.2 m) or more. NOTE: If you are installing the PC in a different room than the control unit, make sure that both locations have working wall outlets and wall jacks.
Page 164 Connecting a PC to the Control Unit To connect a PC 50 ft. (15.2m) or more distant, follow the steps below. See Figure 5-2. Plug one end of a D8W cord into the ADMIN jack on the control unit. Plug the other end of the D8W cord into a 355AF adapter. Connect an EIA crossover cable to the 355AF adapter.
Page 165: Connecting A Pc More Than 50 Ft. (15.2 M) Away
Connecting a PC to the Control Unit Processor Module SMDR Jack ADMIN Jack 355AF Adapter Crossover Cable EIA-232-D Z3A2ADU ADU Crossover Cable Control Unit 400B2 D6AP — 2012D-50M Adapter 4 Pair Plug Transformer AC Outlet Ended Cable Direct Connection Wall BR1A-4P Adapter Jack 102 Connecting Block...
Page 166: Connecting A Cat To The Control Unit
Connecting a CAT to the Control Unit Connecting a CAT to the Control Unit The Call Accounting Terminal (CAT) is a stand-alone unit that provides call accounting information. It connects to the SMDR jack on the control unit and links the control unit to the CAT printer. The connection of the CAT to the control unit depends on the distance and whether the CAT and control unit share the same AC outlet.
Page 167 Connecting a Printer to the Control Unit AT&T Call Accounting Terminal (CAT) Printer AT&T Call Accounting System Printer AT&T Applications Printer NOTE: The AT&T 570 printer is not compatible with the system. Printer connection varies depending on the printer model, whether the printer is grounded on the same AC outlet as the control unit, and whether the printer is within 50 ft.
Page 168 Connecting a Printer to the Control Unit Connecting a CAT and Printer on the Same AC Outlet Use this procedure to connect a CAT and CAT serial printer into the same AC outlet as the control unit, provided the CAT is fewer than 14 ft. (4.27 m) and the printer is fewer than 50 ft.
Page 169: Connecting A Cat And Printer On The Same Ac
Connecting a Printer to the Control Unit CAT PLUS Connections Using Same AC Outlet D8W-87 CAT PLUS Terminal SMDR Port Long Cord Z200A EM I Filter Short Cord CAT Printer Figure 5-3. Connecting a CAT and Printer on the Same AC Outlet Connecting a CAT and Printer on a Different AC Outlet If the printer is not grounded to the same AC outlet as the control unit or CAT...
Page 170 Connecting a Printer to the Control Unit NOTE: If you are installing the printer in a different room than the control unit, make sure that both locations have working wall outlets and wall jacks, and that the building wiring has been connected so that the wall jacks in each location connect with each other.
Page 171 Connecting a Printer to the Control Unit Follow the steps below to make the connections at the control unit. Refer to Figure 5–4 throughout the procedure. Plug the short end of a Z200A EMI cord into the SMDR jack on the control unit.
Page 172: Outlet
Connecting a Printer to the Control Unit CAT PLUS Connections Using Z 3 A 2 A D U W i t h D i f f e r e n t A C O u t l e t s M8AJ-87 Equivalent Z 3 A 4 A D U...
Page 173: Printer
Connecting a Printer to the Control Unit To make the connections at the printer, follow the steps below. See Figure 5-4. At the printer location, plug one end of a D6AP cord into a 2012D-50M transformer, or follow the instructions in Step 9 above. Plug the other end of the D6AP cord into the lower jack on a 400B2 power adapter.
Page 174 Connecting a Printer to the Control Unit Connecting a Printer Within 50 Feet (15.2 m) If the printer is within 50 ft. (15.2 m) of the control unit and is connected to the same 117-V AC branch as the control unit, use this procedure to connect a printer to the control unit.
Page 175: Connecting A Printer Within 50 Ft. (15.2 M)
Connecting a Printer to the Control Unit S M D R J a c k Z200A E M I F i l t e r 3 5 5 A F Adapter Control Unit EIA-232-D SMDR Printer Figure 5-5. Connecting a Printer Within 50 ft. (15.2 m) To connect a printer within 50 ft.
Page 176 Connecting a Printer to the Control Unit Connecting a Printer 50 Feet (15.2 m) or More Away Use this procedure to connect a printer to the control unit if the following conditions apply: The printer is not a CAT printer connected to a CAT. The printer is 50 ft.
Page 177 Connecting a Printer to the Control Unit 248B adapter D8W cords D6AP power cord EIA-232-D cable 4-pair plug-ended cable To connect a printer 50 ft. (15.2 m) or more away from the control unit, follow the steps below. See Figure 5-6. 1 Plug the short end of a Z200A EMI cord into the SMDR jack on the control unit.
Page 178: Connecting A Printer More Than 50 Ft. (15.2 M)
Connecting a Printer to the Control Unit Processor Module Z200A EMI Filter 355AF Adapter EIA Crossover Cable M8AJ-87 Z3A2 ADU Adapter Control Unit ADU Crossover Cable D6AP 400B2 SMDR Power 2012D-50M Jack Adapter Transformer BRIA-4P Adapter 102 Connecting Block Outlet 103 Connecting Block 102 or 103 Connecting Block...
Page 179: Transformer
Connecting a Printer to the Control Unit 248B Adapter 2012D Transformer T r a n s f o r m e r with 248B Adapter D6AP Cord Figure 5-7. Connecting the 24813 Adapter and the 201213 Transformer Plug the other end of the D6AP cord into the 2012D-50M transformer. If you are working with a 248B adapter and 2012D transformer instead of a 2012D-50M transformer, plug the D6AP cord into the jack on the 248B adapter, and then connect the spade-tip wires on the 248B adapter to the...
Page 180 Connecting a Printer to the Control Unit If the 400B2 is plugged into a wall jack, make sure that building wiring has been set up so that the wall jack for the control unit can communicate with the wall jack for the printer. If the 400B2 is plugged into a BRIA-4P adapter, 102 connecting block, or 103 connecting block, use 4-pair plug-ended cable to connect the BRIA-4P adapter (or connecting block) to the wall jack for...
Page 181: At&T 572 Printer Options
Connecting a Printer to the Control Unit Table 5–1. AT&T 572 Printer Options Menu Status Function FORM LENGTH LQ or NLQ BUZZER BUILT-’’IN” FONT RESOLUTION ON-"LINE" BUFFER ON-"LINE" PW ON MODE DIRECTION BI-DIR.1 LF + CR BUFFER FULL ACTIVE P. E. CR + LF AUTO CR ZERO...
Page 182 Connecting a Printer to the Control Unit Table 5-1, Continued Function Menu Status CHAR. SET (GO,GL) CHAR. SET (G1 , GR) CHAR. SET (G2) CHAR. SET (G3) “LINE” DRAWING OFF-’’LINE” STATE ALL RECEIVE RTS TIMING OVER RUN DATA BIT PROTOCOL XON/XOFF* STOP BIT PARITY...
Page 183: At&T 475/476 Printer Dip Switch Settings
Connecting a Printer to the Control Unit Table 5–2. AT&T 475/476 Printer DIP Switch Settings* Switch Switch 2 Switch 21 DIP 1-Open DIP 1-Open DIP 1-Open DIP 2-Closed DIP 2-open DIP 2-Open DIP 3-Open DIP 3-Open DIP 3-Open DIP 4-Open DIP 4-Open DIP 4-Closed DIP 5-Closed...
Page 184: At&T Cat Printer Dip Switch Settings
Connecting a Printer to the Control Unit Table 5–3. AT&T CAT Printer DIP Switch Settings* Switch 1 Switch 2 Control Switch DIP 1-On DIP 1-On DIP 1-Off DIP 2-On DIP 2-On DIP 2-CM DIP 3-On DIP 3-Off DIP 3-Off DIP 4-On DIP 4-Off DIP 4-Off DIP 5-On...
Page 185 Connecting a Printer to the Control Unit 5-26 Installing the PC, CAT, or Printer...
Page 186: Connecting Data Equipment
Connecting Data Equipment This chapter explains how to set up data stations. A data station sends and/or receives data. If the data station includes a telephone, the station can also send and receive voice. If the system includes both modem and 7500B data stations that need to communicate with each other, then you need to set up a modem pool for those data stations.
Page 187: Data Station Configurations
Data Stations Table 6-1. Data Station Configurations Telephone GPA or Type Station (for voice) Analog voice Analog multiline Modem Terminal, PC, fax (cannot dial), optical scanner, or and modem telephone and BR-241-B1 data host computer bridging adapter Modem None None Modem Terminal, PC, fax, credit data-only*...
Page 188 Data Stations NOTES: The analog voice and modem data station requires a bridging adapter to connect the telephone to the two adjacent analog extension jacks. The 7500B data-only station requires a terminating resistor adapter to connect the 75006 data module to the MLX extension jack. See “Video Conferencing Data Stations,”...
Page 189 Data Stations 7500B Data Stations A 7500B data station uses a 7500B data module to convert MLX voice signals and DTE digital signals to the digital transmission signaling standard, so that it can send and receive digital signals. This type of station requires PRI facilities to send and receive data to and from digital data stations that are outside the system.
Page 190: Analog Voice And Modem Data Stations
Analog Voice and Modem Data Stations Analog Voice and Modem Data Stations Figure 6-1 shows the equipment configuration for an analog voice and modem data station. GPA Settings The switch on the back of the General Purpose Adapter (GPA) used in Step 4, provides two settings, Automatic and Basic (Join is not used).
Page 191: 6-6 Connecting Data Equipment
Analog Voice and Modem Data Stations Make sure that the modem has settings for speed and parity that are compatible with those of the data terminal. If you are not sure, see the customer’s system manager or the documentation packaged with the modem, data communications software, and data terminal. Connect the modem to the GPA.
Page 192: Analog Voice And Modem Data Equipment Configuration
Analog Voice and Modem Data Stations 408,408 GS/LS, or 008 Module Two adjacent Analog Extension jacks D8W cord B R - 2 4 1 - B 1 Bridging Adapter D8W cord LINE Jack D8AC cord TEL/OTHER jack VT jack AC Outlet G P A Data Terminal Analog Multiline TEL/EQUIP jack...
Page 193: Modem Data-Only Stations
Modem Data-Only Stations Modem Data-Only Stations Figure 6–2 shows the equipment configuration for a modem data-only station. To setup a modem data-only station, follow the steps below: If using an external modem, use an EIA-232-D cable to connect the modem to the serial port on the data terminal. If using an internal modem, it should already be connected.
Page 194: Modem Data-Only Equipment Configuration
Modem Data-Only Stations 008 OPT Module 012 Module Tip Ring Extension jack AC Outlet D4BU cord LINE jack EIA-232-D Cable Modem SERIAL connector AC Outlet Figure 6-2. Modem Data-Only Equipment Configuration Connecting Data Equipment 6-9...
Page 195: Mlx Voice And Modem Data Stations
MLX Voice and Modem Data Stations MLX Voice and Modem Data Stations Figure 6-3 shows the equipment configuration for an MLX voice and modem data station. 008 MLX or 408 GS/LS-MLX Module Extension jack D8W cord , LINE jack TEL/OTHER D4BU jack cord...
Page 196 MLX Voice and Modem Data Stations To set up a modem data and MLX voice station, follow the steps below: Use an EIA-232-D cable to connect the serial port on the data terminal to the modem. For a data terminal that has both COM1 and COM2 jacks, make sure you use the one designated for data transmission.
Page 197: Mlx Voice And 7500B Data Stations
MLX Voice and 7500B Data Stations MLX Voice and 7500B Data Stations Figure 6-4 shows the equipment configuration for MLX voice and 7500B data station. The configuration shown in Figure 6-4 is for asynchronous 7500B data transmission. For information on setting up synchronous 7500B data stations, see “Video Conferencing Data Stations, ”...
Page 198: Mlx Voice And 7500B Data Equipment Configuration
MLX Voice and 7500B Data Stations 0 0 8 M L X o r 408 GS/LS-MLX M o d u l e Extension jack D8W cord LINE jack PHONE jack PORT 1 Data Module EIA-232-D Data c o r d POWER Cable Terminal...
Page 199: 7500B Data-Only Stations
7500B Data-Only Stations 7500B Data-Only Stations Figure 6-5 shows an equipment configuration for a 7500B data-only station. To set up a 7500B data-only station, follow the steps below: Use an EIA-232-D cable to connect the SERIAL port on the data terminal to the 7500B data module.
Page 200: B Data-Only Equipment Configuration
7500B Data-Only Stations 008 MLX or 408 GS/LS-MLX Module Extension jack D8W cord 440A4 (100W) Terminating Resistor Adapter LINE jack PORT 1 Data Module [ EIA-232-D Data Terminal POWER Cable SERIAL connector WP90110-L7 Power Supply AC Outlet AC Outlet Figure 6-5. 7500B Data-Only Equipment Configuration Connecting Data Equipment 6-15...
Page 201: Video Conferencing Data Stations
Video Conferencing Data Stations Video Conferencing Data Stations You can use the 7500B data module with a Multipurpose Enhancement Board for synchronous data communication. This type of station allows data transmission at speeds of 56 or 64 kbps. This section is only a guideline for connecting video conferencing equipment to the system.
Page 202 Video Conferencing Data Stations Cables: — Two male/male EIA-232-D cables, 8 ft. (24 m), to connect the PORT 1 connectors on the 7500B data modules to the EIA-232/V.35 converters — Two male/male V.35 DB-37 cables, 8 ft. (24 m), to connect the V-35 communication ports on the video codec to the EIA-232/V.35 converters —...
Page 203: 6-18 Connecting Data Equipment
Video Conferencing Data Stations 008 MLX o r 408 GS/LS-MLX Module 10OD Module D8W cord Two MLX extension jacks B 8 Z 2 DS1 line/trunk j a c k A M I LINE jack c o r d Setting D8W cord 4 0 4 A 4 4 0 A 4 Terminating...
Page 204 Video Conferencing Data Stations To set up the video conferencing configuration, follow the steps below. See Figure 6-6. Plug one end of a D8W cord into the LINE jack on each of the 7500B data modules. Connect the other end of each D8W cord. If Data Form 1 b indicates that you are to install MLX telephones, plug the D8W cords into the MLX extension jacks specified on Data Form 1b, then go to Step 4.
Page 205: 7500B Data Module Settings
Video Conferencing Data Stations If it is not already connected, connect the CSU to the 100D module on the control unit and to the 5ESS or 4ESS exchange switch, See “lnstalling the Channel Service Unit” in Chapter 4. When you are ready to power up the system, plug the power supplies, CSU, video conferencing equipment, and control unit into the AC outlets.
Page 206: Initializing And Testing The System
Initializing and Testing the System When you have finished installation, you are ready to initialize the system as described in this chapter. Initializing the System To initialize a Release 3.0 system, use one of the following methods: Restore from a 3.0 system programming disk or Translation memory card.
Page 207 Initializing the System Programming Guides The following guides are available to assist you: Programming Summary for quick-reference procedures (document number 555-630-111) System Programming for detailed procedures (document number 555- 630-140, in the binder accompanying this one) System Programming and Maintenance (SPM) for detailed SPM procedures (document number 555-630-140, in the binder accompanying this one) Restoring from the Translation Memory Card...
Page 208: Setting The Time And Date
Setting the Time and Date 2 Use SPM and the system programming disk to perform the Restore procedure. See System Programming and Maintenance (SPM) for instructions. NOTE: You must restore the system using the system programming (or backup) disk or memory card whenever a frigid start (System Erase) occurs. Setting the Time and Date If the Control Unit Diagram indicates that you should set the time and date, do so before you test the system.
Page 209 Testing the System If you hang up during any of these procedures, test mode ends automatically. Keep the following in mind when using the speakerphone: Mute Speaker If the button is pressed before the button, the Mute LED cannot be turned off; it winks. The Mute and Speaker LEDs remain steady during test mode.
Page 210 Testing the System To test the red Message light, press a fixed-feature button without an LED (such as Transfer, Conf, or Drop) or any dialpad button. The Message light should turn off. Hang up the handset to leave test mode. Testing MLX Display Telephones While the MLX display telephone is in test mode, follow the steps below to test the display buttons:...
Page 211 Testing the System 5 Hang up. The control unit should send a ring burst, and the Message light on the 2500 telephone should turn on. 6 Turn off the Message light. Dial the appropriate feature code. Testing Telephones for Dial Tone To test for dial tone, follow the steps below: Press an ICOM or SA button (depending on the mode of operation).
Page 212: Single-Line Telephones
Testing the System Testing Analog Multiline and Single-Line Telephones To test the basic operation of analog multiline and single-line telephones, follow the steps below: If you are testing a multiline telephone, press an lCOM or SA button. Pick up the handset and wait for dial tone. Dial the extension number of another working telephone.
Page 213 Testing the System Testing Ground-Start and Loop-Start Trunks (Hybrid/PBX Systems Only) To test the GS and LS outgoing and incoming trunks at a telephone, follow the steps below: Dial followed by the trunk ID number (01 through 80). You should hear dial tone for a working trunk, a reorder tone for a DID trunk or an invalid trunk number, or a busy tone if the trunk is in use.
Page 214 Testing the System Testing Tie Trunks Before you test tie trunks, make sure that the tie trunks for the system are connected and properly programmed. Have someone at the far end ready to place and receive calls throughout the testing procedures listed below. The tie trunk testing procedures in this section areas follows: Automatic-start two-way (both incoming and outgoing) Automatic-start incoming only...
Page 215 Testing the System To test incoming automatic-start tie-trunks, follow the steps below: At the far-end tie-trunk site, have someone pickup the handset and dial a tie trunk assigned to a button on your telephone. Your telephone should ring, and the LEDs next to the tie-trunk button should respond as follows: the red LED should turn on, and the green LED should flash.
Page 216 Testing the System Testing Two-Way Dial-Repeating Tie Trunks For two-way dial-repeating tie trunks, perform both the incoming and outgoing dial-repeating tie trunk tests. Testing Incoming Dial-Repeating Tie Trunks Perform this test for dial-repeating tie trunks that are two-way or incoming only.
Page 217 Testing the System Pick up the handset. (In Hybrid/PBX systems with pooled tie trunks, press an SA button and dial the pool dial-out code.) The green LED next to the selected button lights. Dial the tie-trunk number of the extension where someone is waiting for your call.
Page 218 Testing the System ARS and SMDR Tests If ARS patterns have been programmed, you can test routing by placing toll calls and checking the trunk indicated on the SMDR printout. Check the report to see which line/trunk the system selected for an outgoing call. The length of each toll call must be equal to or greater than the minimum SMDR recording time.
Page 219 Testing the System At any telephone, pickup the handset and dial the group extension number. Test the calling group delay announcement (if provided) for each group. a Make the group busy or have all members log out of the group (by dialing at each group extension).
Page 220 Testing the System Testing the DSS At each Direct Station Selector (DSS), check that all lights are operational. Page Then use the DSS to call a telephone in the system. Test the buttons on the DSS. Testing Night Service To test the Night Service feature on the system operator console, follow the steps below: At the system operator console, press the Night Service button.
Page 221 Testing the System c Hang up the handset. Recall d Press the button and dial the password. (On an MLX telephone Feature without a programmed Recall button, press the button and dial and the password before picking up the handset.) e Pick up the handset and make an outside call.
Page 222 Testing the System 2 Make an announcement into the handset. You should hear the announcement over the loudspeaker(s). 3 Hang up. 4 Repeat Steps 1 through 3 for all paging zones. Testing Music On Hold To verify that music is provided to outside callers placed on hold, follow the steps below.
Page 223: Ground-Start Button
Testing the System Testing the Power Failure Transfer Jacks To test a power failure transfer (PFT) jack for proper operation, the outside line numbers to the module’s line/trunk jacks must be assigned and the trunks must be operational. A PFT telephone on a GS line must have a GS button attached to the telephone.
Page 224 Testing the System If the telephone is connected to a GS trunk, push the GS button attached to the telephone again. Dial an outside number—make sure someone can answer the call. After the call is answered and you have verified that you have good two- way communication, tell the person the telephone number assigned to the outside line bridged by the PFT jack to which you are connected.
Page 225: Installing The Control Unit's Housing
Installing the Control Unit’s Housing If you hear dial tone after one to three seconds of silence, proceed with this test. 4 Dial 12345678*0#. You should hear a dual-tone multifrequency (DTMF) signal as each button is pressed. When you finish dialing, you should hear a 3-beep confirmation tone. 5 Repeat the test for each TTR.
Page 226 Installing the Control Unit’s Housing Top Cover Empty module Figure 7-2. Installing the Control Unit Top Cover Initializing and Testing the System 7–21...
Page 227: Installing The Control Unit Front Cover
Installing the Control Unit’s Housing Installing the Front Cover To install the front cover, see Figure 7-3 and follow these steps: Hook the top of the front cover onto the top cover. Push down on the bottom of the front cover until it locks securely on the base of the wire manager on the modules.
Page 228: Installing Applications
Installing Applications This chapter provides installation guidelines and documentation references for the applications that the system supports. You can install the following software and hardware products on the system. See the documentation packaged with each application for detailed installation instructions. Stand-alone products —...
Page 229: Voice Messaging Systems And Touch-Tone Receivers
Voice Messaging Systems and Touch-Tone Receivers Call Management System (CMS) — PassageWay Direct Connect Solution for Microsoft® Windows System Programming and Maintenance (SPM) Integrated Solution Ill (IS Ill) UNIX System-based products — AUDIX Voice Power™ IS Ill — Call Accounting System (IS CAS) —...
Page 230: Automated Document Delivery System
Automated Document Delivery System — Table TTRs Required by 8-1. of TTRs No. of 400 or No. of Required 400 GS-LS/TTR VMS Ports 012 Modules Modules 1 o r 2 0or1 1 o r 2 0or1 0 o r 1 2 o r 3 Automated Document Delivery System...
Page 231: Call Accounting System
Call Accounting System Considerations Using one line for fax transmission limits ADDS to approximately 100 calls per day. Businesses anticipating more than 100 calls per day may need more than one system to handle the call volume efficiently. Use ADDS in a two-line configuration to maximize performance and minimize busy signals.
Page 232 Call Accounting System NOTE: CAS is also available as part of the UNIX System-based Integrated Solution H (IS II) and Integrated Solution Ill (IS Ill) software applications. CAS runs on an approved DOS PC. Two versions of the product are offered: CAS for Windows and CAS Plus V3.
Page 233 Call Accounting System CAS software To use CAS for Windows with the system, the following components are recommended: For a single-site system, an NCR 3315 PC (20-MHz 386) with 6 MB of RAM and a 120-MB hard disk For a multi-site system, an NCR 3332 PC (66-MHz 486) with 16 MB of RAM and a 340-MB hard disk MS-DOS 5.0 or higher —...
Page 234: Call Accounting Terminal
Call Accounting Terminal A summary of the installation procedure is provided below: Connect the hardware. See “Connecting a PC to the Control Unit” in Chapter 5. Complete the CAS worksheets. Make sure that they show all information you need on telephone lines and extensions, calling patterns and processing options, and departments and personnel.
Page 235 Call Accounting Terminal Considerations You can connect only one CAT to the system. You must use a serial printer such as the CAT printer. You must locate the CAT Plus within the distances noted below: Control unit — 14 ft. (4.27 m) direct connection —...
Page 236: Call Management System
Call Management System CAT Documentation Call Accounting Terminal, CAT Plus V3 for Business Installation and Use Call Accounting Terminal, CAT Plus V3 for Hospitality Installation and Use Call Management System Call Management System (CMS) is a DOS-based software application that simulates the actions of a system operator by answering calls and distributing them to individual telephones.
Page 237: Hardware And Software Requirements
Call Management System The two CMS interface card ports on the PC must be connected to two analog multiline telephone jacks on the same analog multiline telephone module; these jacks must be operator positions. If two operator position jacks are not available on the same module, another analog multiline telephone module must be installed in the control unit to provide these jacks.
Page 238 Call Management System CMS software Digital Announcement Unit for CMS Parallel printer and cable to connect the printer to the PC Supervisor console (MERLIN II System Display Console) Agent telephones (any MLX or analog multiline telephones supported by the system) Two analog multiline modules (008 or 408);...
Page 239: Conversant
CONVERSANT CONVERSANT CONVERSANT is an entry-level voice response system that enables you to run integrated voice response (IVR) applications. CONVERSANT can automatically answer and route calls and execute telephone transactions. CONVERSANT consists of the hardware and software that supports transaction processing, data retrieval, and data entry using a touch-tone telephone connected to a public telephone network.
Page 240: Integrated Solution Ill
Integrated Solution Ill CONVERSANT Intro Documentation CONVERSANT Intro Application Support Software lnstallation Guide CONVERSANT Intro Application Support Software User’s Guide Integrated Solution III Integrated Solution Ill (IS Ill) is a complete package of UNIX System-based voice processing and call analysis software that helps to manage telephone usage and costs.
Page 241: Hardware Requirements
Integrated Solution Ill If IS Ill includes AUDIX Voice Power (or Fax Attendant) when users receive voice mail (or fax mail) messages, the Message LEDs on their telephones light (as long as a mailbox or fax mailbox has been assigned to each of those telephones).
Page 242 Integrated Solution Ill The following hardware is also required: A 355AF adapter for connecting the Master Controller to the serial port on the control unit if they are within 50 ft. (15.2 m) of each other and are on the same AC branch circuit ADUs for connecting the Master Controller to the serial port on the control unit, if they are not within 50 ft.
Page 243: At&T Attendant
AT&T Attendant AT&T Attendant AT&T Attendant is a stand-alone application that provides operator-like services through the use of prerecorded messages and electronic switching. Considerations You cannot connect AT&T Attendant to a system that operates in Behind Switch mode. You cannot connect AT&T Attendant to a system that has an AUDIX application or a voice mail system installed.
Page 244: Merlin Mail
MERLIN MAIL The following hardware is also required: AT&T Attendant unit and cords Some AC power strips may be needed, since the Attendant is powered by wall-mounted transformers (10 V AC). Powering and grounding procedures must follow those established for T/R telephones that require auxiliary power.
Page 245 MERLIN MAIL Considerations You cannot connect MERLIN MAIL Voice Messaging System to a system operating in Behind Switch mode. MERLIN MAIL Voice Messaging System is available in 2-port and 4-port configurations. Both models have four hours of message storage capacity. You can use up to eight jacks on a 012 basic telephone module for MERLIN MAIL.
Page 246 MERLIN MAIL MERLIN MAIL has an EIA-232-D serial port and an external modem to support remote diagnostics. You cannot use the first four logical IDs on a 008 OPT module to physically connect telephone equipment; however, you can use the extension numbers of these logical IDs for phantom extensions.
Page 247: Merlin Pfc
MERLIN PFC MERLIN PFC The MERLIN PFC (Phone-Fax-Copier) telephone is a 34-button display telephone with a built-in fax and personal copier that provides the convenience of a fax machine and personal copier in one compact unit. The MERLIN PFC allows the user to make and receive inside and outside calls using the built-in speakerphone, and to send and receive faxes or make quick copies while using the telephone.
Page 248: Installing Applications
MERLIN PFC Hybrid/PBX and Key Modes The dedicated fax line for incoming fax calls from the central office must be connected to a line jack on the control unit, and the line cannot be assigned to a pool. If DID is used, a DID number must be assigned to the fax extension. If a dedicated private line is used, assign a fax line to the voice extension.
Page 249: Passageway Direct Connect Solution
PassageWay Direct Connect Solution PassageWay Direct Connect Solution PassageWay Direct Connect Solution is a collection of five software applications that provide an interface between an approved DOS PC and the system through an MLX-28D, MLX-20L, or MLX-10DP telephone: AT&TCall. A card file application that enables a user to maintain names, addresses, telephone numbers and other information.
Page 250 PassageWay Direct Connect Solution The Automatic Line Selection on the MLX telephone should be programmed so that Idle Line Preference is on an ICOM button (in Key and Behind Switch modes) or an SA button (Hybrid/PBX mode). Hardware Requirements The following hardware is required: An approved DOS PC with the following —...
Page 251: System Programming And Maintenance (Spm)
System Programming and Maintenance (SPM) System Programming and Maintenance (SPM) System Programming and Maintenance (SPM) is a DOS-based software application that allows you to use a PC to program and maintain the system. SPM performs the same functions as an MLX-20L telephone used as a system programming console and has some additional features, such as the ability to back up and restore files and print reports.
Page 252 System Programming and Maintenance (SPM) Hardware Requirements The following hardware is required: An approved PC or other DOS-compatible PC with: — At least 512K of RAM — A double-sided floppy disk drive (either 5.25-inch or 3.5-inch) — A serial port assigned to COM1 or COM2. The serial port can use either a DB-9 or DB-25 connector.
Page 253 System Programming and Maintenance (SPM) 8-26 Installing Applications...
Page 254: Upgrading The System
Upgrading the System To upgrade the control unit, follow the steps below: Remove the control unit housing. “Removing the Control Unit Housing,” next in this chapter. If the current system programming is to be used in the upgraded system, back up system programming. “Completing the Upgrade,”...
Page 255: Removing The Control Unit Housing
Removing the Control Unit Housing Removing the Control Unit Housing Remove the control unit housing as described below. See Figure 9-1. For a MERLIN II or a MERLIN LEGEND (Release 2.1 or later) Communications System: 1. Remove the front housing from each carrier by pulling the bottom- front towards you, and lifting it up as shown in Figure 9-1.
Page 256 Removing the Control Unit Housing MERLIN II and MERLIN LEGEND 2.1 and later Communications System MERLIN LEGEND 2.0 and earlier Communications System Housing Clip Housing Figure 9–1. Removing the Control Unit Housing Upgrading the System 9–3...
Page 257: Powering Down The System
Powering Down the System Powering Down the System You may need to power down the system to add upgraded equipment to the carrier. CAUTION: Follow these steps in the exact sequence. and see Figure 9–2: To power down the system, follow the steps below Turn off the power supply on the basic carrier.
Page 258: Powering Down The System
Powering Down the System -48 VDC Auxiliary Power Auxiliary Input Power Unit INPUT POWER -48 VDC Power Cord Ferrite Ground ‘ Cores Wire AUX Power Unit Outlet AC Power Cord Control Unit AC Power Cord Figure 9–2. Powering Down the System Upgrading the System 9–5...
Page 259: Upgrading The Control Unit
Upgrading the Control Unit Upgrading the Control Unit Do not remove any of the existing carriers. Refer to the Control Unit Diagram on the flip side of System Planning Form 1. If you are installing an expansion carrier, remove the rightmost module from the control unit and put it aside.
Page 260: Removing A Module From The Carrier
Upgrading the Control Unit Figure 9-3. Removing a Module from the Carrier Replacing the Housing Clips 1 Remove the housing clips from the right side of the module. Upgrading the System 9–7...
Page 261 Upgrading the Control Unit Remove the rightmost module from the control unit. See “Removing a Module” in Chapter 2 for instructions. Using a flat-blade screwdriver, unscrew the upper-right corner of the carrier only far enough to free the clip. Pull the top-right corner of the carrier toward you while grasping the housing clip and pushing it away from you (to free it from the carrier).
Page 262: Replacing A Module In The Carrier
Upgrading the Control Unit Figure 9-4. Replacing a Module in the Carrier Remove the clips from the left side of the control unit as you did in Step 1; however, make sure you replace the clips before securing the screws again. Reinstall the power supply module by hooking it onto the rod at the top of the carrier and then swinging it down into place.
Page 263: Modifying The Processor For Key Mode
Modifying the Processor for Key Mode Modifying the Processor for Key Mode To modify the processor for Key mode in Release 3.0, follow the steps below. For earlier releases, see Appendix E in Maintenance and Troubleshooting. Prepare a non-metallic surface, such as a table, on which to work. WARNING: Do not touch the gold connectors on the rear of the processor module.
Page 264: Removing The Processor Module Cover
Modifying the Processor for Key Mode Release Each Catch on Module Remove Cover PROCESSOR MODULE Figure 9–5. Removing the Processor Module Cover Upgrading the System 9–11...
Page 265: Removing The Processor Module Circuit Board
Modifying the Processor for Key Mode Lift Circuit board Up and Over PROCESSOR MODULE Removing the Processor Module Circuit Board Figure 9-6. Holding the processor circuit board at each end, lift it up and turn it over and away from you. See Figure 9-6. Place the processor circuit board on a flat non-metallic surface.
Page 266: Changing The Key Mode Switch Position To Closed
Modifying the Processor for Key Mode PROCESSOR CIRCUIT BOARD Front Rear OPEN CLOSED (KEY) (PBX) Figure 9–7. Changing the Key Mode Switch Position to Closed Upgrading the System 9-13...
Page 267: Completing The Upgrade
Completing the Upgrade Completing the Upgrade WARNING: The following procedures are for qualified technicians or service personnel only. installation or maintenance of this product by anyone other than qualified personnel may damage or impair the product—the limited warranty does not cover such damage. See the limited warranty for details.
Page 268 Completing the Upgrade To back up system programming from Release 2.1, you must use version 2.16 or higher of SPM. Install a Release 3.0 processor module. See Chapter 2, “installing the Processor.” Perform a frigid start (System Erase) to ensure that all system programming is returned to default values.
Page 269 Completing the Upgrade See “Installing the Control Unit” in Chapter 2 if you need instructions. Install the Release 3.0 processor module in the carrier. See “Installing the Processor” in Chapter 2. Perform a frigid start (System Erase) to ensure that system programming is returned to default values.
Page 270 Completing the Upgrade Connect the side panels to the front panel(s) in the same way. Pickup the housing and place it on the control unit. If the system has more than one carrier, make sure you hold the housing only from the basic carrier side;...
Page 271 Completing the Upgrade 9–18 Upgrading the System...
Page 272: Special Renumbers
System Numbering Forms When you change any existing trunk or extension wiring, record information about the wiring on the appropriate system numbering form. This appendix includes examples of all of the system numbering forms, and instructions for completing Form 2a, “System Numbering: Extension Jacks.”...
Page 273 System Numbering Forms Form 2a, System Numbering: Extension Jacks Renumber System* 2-Digit+ Selected Extension Numbers 3-Digit Set Up Space 2-Dig 3-Dig. AUDIX Mod. Log. Jack Type Set Up Renumber Ext. Wire Person, Location Ext. Voice Eqpt. Space Label Type ID D†...
Page 274 System Numbering Forms The following explains how to complete Form 2a. The number in the logical ID column refers to the number of the extension jack in the control unit. In the “Eqpt.” (Equipment) column, enter the type of device (such as an MLX-20L console) that is connected to the extension jack.
Page 275 System Numbering Forms Form 2b, System Numbering: Digital Adjuncts Maximum 127 Adjuncts Factory-Set Telephone Person, Location, Log, Set Up 2-digit 3-digit Space Renumber to SAA T/R 7500B Ext. No. Function, and Equipment Type 710 300 7300 7301 712 302 7302 713 303 7303 714 304 7304 715 305 7305...
Page 276 System Numbering Forms Form 2c, System Numbering: Line/Trunk Jacks Music-on-Hold, Line/Trunk No. Source Maintenance Alarm, Line/Trunk No. Loudspeaker Page, Line/Trunk No(s). Loop-Start Reliable Disconnect Incoming QCC Operator Line/Trunk Toll Type Module Jack Type Queue Pool Type (Main Telephone Hold Disc. Outmode Prefix Req’d Priority Receive Type...
Page 277 System Numbering Forms Form 2d, System Numbering: Special Renumbers Group Calling Pools* (Form 7d) Factory-Set Renumber Renumber (Forml 2c) Factory-Set Number Grow ID Number Description Label Group Paging Factory-Set Renumber (Form 7b) Number Group ID 7920 7921 Park Zone 7922 Renumber Factory-Set (Form 6a)
Page 278 Unit Load Calculation Worksheet If you determine that you need to recalculate the unit load for any carrier, use the instructions on the following worksheet. NOTE: You should have a separate copy of the worksheet for each carrier, See “Unit Loads” in Chapter 1 for information on recalculating unit loads.
Page 279: Unit Load Worksheet
Unit Load Calculation Worksheet Unit Load Worksheet 1. Number of modules in carrier (excluding power supply and processor: If fewer than five, auxiliary power is not required. If five or six, continue to Step 2. Square 2. Key or Behind Switch mode only: Modified Indicate configuration of lines;...
Page 280 Unit Load Calculation Worksheet 5. Calculate the estimated unit loads. Module Unit Load = Total Qty x 12.0 008 MLX 13.5 008 OPT 10OD 400 EM 400 GS/LS/TTR 12.0 408 GS/LS 12.0 408 GS/LS-MLX 13.5 800 GS/LS 800 GS/LS-lD 800 DID Total Estimated Unit Load If the total is less than or equal to 54, auxiliary power is not required.
Page 281 Unit Load Calculation Worksheet 6. Calculate the actual carrier unit load. = Total Unit Load Qty x Hybrid/PBX or Modified Square Equipment Network Access Lines* GS/LS Telephones MLX-10 MLX-10D MLX-28D MLX-20L BIS-10 BIS-22 BIS-22D BIS-34 BIS-34D MLC-5 MDC-9000 MDCW-9000 10-Button Basic 10-Button HFAI 34-Button Basic 34-Button DLX...
Page 282: Installation
Unit Load Calculation Worksheet Unit Load = Total Qty x Hybrid/PBX or Equipment M o d i f i e d Square Optional Equipment Direct Station Selector‡ General Purpose Adapter Hands-Free Unit Headset Adapter Total Actual Unit Load † The MFM has its own wall power unit located at the telephone and therefore is not added to the unit load calculation.
Page 283 Unit Load Calculation Worksheet 7. Try to exchange modules between carriers to reduce the unit loads to 54. (Remember that the 100D, 400,400 GS/LS/TTR, 800 GS/LS-ID, 800, and 800 GS/LS modules have unit loads of 0.0.) Repeat Steps 1 through 6 to recalculate unit loads for the new configuration.
Page 284 Unit Load Calculation Worksheet 8. Calculate the unit loads for slots 5 and 6 of the carrier. Unit Load = Total Hybrid/PBX or Equipment Modified Square Network Access Lines* GS/LS Telephones MLX-10 MLX-10D MLX-28D MLX-20L BIS-10 BIS-22 BIS-22D BIS-34 BIS-34D MLC-5 MDC-9000 MDW-9000...
Page 285 Unit Load Calculation Worksheet Qty x Unit Load Total Hybrid/PBX or Square Equipment Modified Optional Equipment Direct Station Selector* General Purpose Adapter Hands-Free Unit Headset Adapter Total Unit Load for Slots 5 and 6 † The MFM has its own individual wall power unit located at the telephone and therefore is not added to the unit load calculation.
Page 286 Unit Load Calculation Worksheet 9. Try to exchange modules between carriers to reduce the unit loads for slots five and six to 27. (Remember that the 100D, 400, 400 GS/LS/TTR, 800 GS/LS-lD, 800, and 800 GS/LS modules have unit loads of 0.0.) Repeat Steps 1 through 8 to recalculate unit loads for new configuration.
Page 287 Unit Load Calculation Worksheet B–10 Installation...
Page 288 Index ARS (Automatic Route Selection), see Automatic Route Selection (ARS) testing 146A protector, 2-14 - 2-15 AT&T Attendant, 8-16 - 8-17 147A protector, 2-14 - 2-15 Automated Document Delivery System 2012D transformer, 5-17 - 5-21 (ADDS), 8-3 - 8-4 248B adapter, 5-17 - 5-21 Automatic Route Selection (ARS) 400EM tie trunk module, 2-33 - 2-39 testing, 7-13...
Page 289 Index Control unit continued Call Accounting Terminal (CAT) interference, 2-3 documentation, 8-9 location, 2-4 hardware requirements, 8-8 mounting hardware, 2-5 on outlet with CAT, 5-9 - 5-10 power requirements, 2-5 - 2-8 on outlet with printer removing housing, 9-3 - 9-6 hardware required, 5-9 replacing housing clips, 9-7 - 9-10 procedure, 5-9 - 5-10...
Page 290 Index Data stations continued Dual-tone multifrequency (DTMF) configuration diagram, 6-13 signaling, 3-30 procedure, 6-12 MLX voice and modem data configuration diagram, 6-10 procedure, 6-11 Electrical noise, 2-3 modem-only Environmental requirements for control configuration diagram, 6-9 unit, 2-2 - 2-3 procedure, 6-8 - 6-9 Expansion carrier, 2-26 - 2-27, 2-28 overview, 6-1 - 6-4 video conferencing...
Page 291 Index Key mode Hardware supported, 8-1 - 8-2 Release 2.0 and earlier, 9-16 - 9-17 Headsets, 3-27 - 3-29 modifying processor for, 9-1 0 - 9-1 3 Housing installation, 9-17 - 9-18 removing, 9-3 - 9-6 replacing clips, 9-7 - 9-10 Lightning protection, 2-14 - 2-15 Line jack labeling, 2-38 Loop-start trunk testing, 7-8...
Page 292 Index MLX telephone Mounting hardware, 2-5 assembly procedure, 3-49 - 3-57 Multi-Function Module (MFM) backplate, 3-54 - 3-56 adjuncts supported by, 3-2 button assignment card, 3-56 - 3-57 and Voice Announce to Busy, 3-2 considerations, 3-48 connector pins, 3-10 - 3-12 deskstand, 3-49 definition, 3-1 display, 3-57, 7-5...
Page 293 Index PFT (power failure transfer) jack, see Overview Power failure transfer (PFT) jack installation sequence, 1-1 - 1 -2 Power programming, 1-4 turning off, 2-44, 9-4 adjuncts installation, 1-3 turning on, 2-43 control unit installation, 1-3 Power failure transfer (PFT) jack testing, data equipment connection, 1-4 7-18 - 7-19 network interface connection,...
Page 294 Index Processor System Programming and Maintenance installation, 2-28 - 2-29 , 2-30 (SPM) application, 8-24 - 8-25 modifying for Key mode, 9-10 - 9-13 System Speed Dial testing, 7-14 Programming disk, 7-2 - 7-3 guides, 7-2 overview, 1-4 T/R (tip/ring), see Tip/ring (T/R) device Protector Talk-back, 3-36 - 3-37 146A, 2-14 - 2-15...
Page 295 Index Testing the system Tie trunks 400EM, 2-33 - 2-39 analog telephones, 7-7 ARS, 7-13 testing incoming automatic-start, Coverage feature, 7-14 - 7-15 7-9 - 7-10 dictation system, 7-16 DID trunks, 7-8 - 7-9 incoming dial-repeating, 7-11 Direct Station Selector (DSS), 7-15 outgoing automatic-start, 7-10 ground-start trunks, 7-8 outgoing dial-repeating,...
Page 296 Index Unit load Video conferencing auxiliary power units, 2-17 configuration diagram, 6-18 checking, 2-16 - 2-17 data module settings, 6-20 Upgrading the system hardware required, 6-16 - 6-17 control unit, 9-1 - 9-8 procedure, 6-19 - 6-20 from MERLIN II system, 9-15 - 9-16 VMS (voice messaging system), 8-2 - 8-3 from previous release, 9-14 - 9-15 Voice Announce to Busy, 3-2, 3-60 - 3-61...
Page 297 Index IN–10 Installation...
Page 298 AT&T 555-630-140 AT&T August 1994 ® MERLIN LEGEND Communications System Release 3.0 Maintenance and Troubleshooting...
Page 299: Security Of Your System: Preventing Toll Fraud
AT&T 555-630-140 Copyright © 1994, AT&T All Rights Reserved Printed in U.S.A. August 1994 Notice to ensure that the information in this Every effort was made book was complete and accurate at the time of printing. However, information is subject to change. See Appendix A, “Customer Support Information,”...
Page 300 Contents About This Book Intended Audience How to Use This Book Terms and Conventions Used Product Safety Labels xviii Security xviii Related Documents How to Comment on This Document Introduction Equipment On-Site Programming Maintenance Remote Programming Maintenance Using SPM Preparation for Hardware Maintenance 1-15 Maintenance Strategy .
Page 301 Contents Error Logs, Access Logs, and System Inventory Error Logs 2-18 Access Log 2-20 System Inventory Telephone Problems Fixing Telephone Problems MLX Telephone Tests System Requirements for Touch-Tone Receivers Control Unit Problems Backing Up System Programming Power Supply Problems 4-12 Processor Problems 4-33 Module Problems...
Page 302 Contents Central Office Problems Trunk Errors Checking Ports Conclusion of Hardware Maintenance 5-30 Customer Support Information Support Telephone Number Federal Communications Commission (FCC) Electromagnetic Interference Information Canadian Department of Communications (DOC) Interference Information FCC Notification and Repair Information Installation and Operational Procedures DOC Notification and Repair Information Renseignements sur la notification du ministére des Communications du Canada et la reparation...
Page 303 Contents System Numbering Forms 2a, System Numbering: Extension Jacks Form B - 4 Form 2b, System Numbering: Digital Adjuncts Form 2c, System Numbering: Line/Trunk Jacks Form 2d, System Numbering: Special Renumbers Unit Load Calculation Worksheet Unit Load Worksheet Backing Up with a Memory Card Modifying a Release 2.1 or Earlier Processor for Key Mode GL Glossary...
Page 304: Removing The Control Unit Housing
Figures Introduction 1–1. Setting Up the MLX-20L Console 1-2. Setting Up the PC 1-3. External Modem Setup 1-4. The SPM Display 1-12 1–5. Removing the Control Unit Housing 1-17 1–6, Disconnecting AC Power 1-18 Maintenance Strategy 1-7. 1-19 Control Unit Problems 4–2.
Page 305: Installing The Control Unit Housing
Figures Central Office Problems Top Cover (Release 2.1 5-1. Installing the Control Unit 5-30 and Later) Front Cover (Release 2.1 5-2. Installing the Control Unit 5-31 and Later) 5-3. Assembling the Control Unit Housing (Release 2.0 5-33 and Earlier) 5-3. Installing the Control Unit Housing (Release 2.0 5-34 and Earlier) Forms...
Page 306: Ttrs Required By Vms
Tables Introduction 1-1. Function of PC Keys in SPM 1-13 Error Logs, Access Logs, and System Inventory 2-1. Transient/Permanent Error Thresholds 2-2. Error Codes Telephone Problems 3–1. Troubleshooting Telephone Problems 3-2. MLX Telephone Display Buttons 3-3. TTRs Required by VMS 3-4.
Page 307 Tables Central Office Problems 5-1. Troubleshooting Trunk Symptoms x Maintenance and Troubleshooting...
Page 308 Safety The exclamation point in an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. lMPORTANT SAFETY lNSTRUCTlONS When installing telephone equipment, always follow basic safety precautions to reduce the risk of fire, electrical shock, and injury to persons, including: Read and understand all instructions.
Page 309 Safety Do not install this product near water, for example, in a wet basement location. Do not overload wall outlets, as this can result in the risk of fire or electrical shock. The MERLIN LEGEND Communications System is equipped with a 3-wire grounding-type plug with a third (grounding) pin.
Page 310 Safety WARNING: For your personal safety, DO NOT install an MFM yourself. ONLY an authorized technician or dealer representative shall install, set options, or repair an MFM. To eliminate the risk of personal injury due to electrical shock, DO NOT attempt to install or remove an MFM from your MLX telephone. Opening or removing the module cover of your telephone may expose you to dangerous voltages.
Page 311 Safety Maintenance and Troubleshooting...
Page 312: About This Book
About This Book The MERLIN LEGEND Communications System is an advanced digital switching system that integrates voice and data communications features. Voice features include traditional telephone features, such as Transfer and Hold, and advanced features, such as Group Coverage and Park. Data features allow both voice and data to be transmitted over the same system wiring.
Page 313: Terms And Conventions Used
Terms and Conventions Used Equipment and Operations Reference provides detailed information on system hardware, telephones, and other equipment. Feature Reference provides details on the features of the communications system. System Programming gives procedural instructions for programming system features. Users’ Guides and Operators’ Guides give procedural instructions for programming and using telephone features.
Page 314 Terms and Conventions Used Some older terms have been replaced with newer terms. The following list shows the old term on the left and the new term on the right. line/trunk module trunk module line/trunk jack trunk jack extension station extension jack station jack modem data station...
Page 315: Product Safety Labels
Product Safety Labels Typographical Conventions Continued Purpose Example Plain constant-width type indicates Choose from the display Ext Prog text that appears on telephone screen. display or PC screen. Constant-width type in italics To activate Call Waiting, dial *11. indicates characters you dial at the telephone or type at the PC.
Page 316: Related Documents
Related Documents Nondisplaying authorization codes and telephone numbers provide another layer of security. For more information, see Appendix A, “Customer Support Information.” Related Documents In addition to this book, the following list of documents are part of the documentation set, Within the continental United States, these documents can be ordered from the AT&T Customer information Center by calling...
Page 317: How To Comment On This Document
How to Comment on This Document Document No. Title System Operator Support (Cont.) MDC 9000 and MDW 900 Telephones User’s Guide 555-630-138 Miscellaneous User Support 555-630-130 Calling Group Supervisor’s Guide 555-630-129 Data User’s Guide Documentation for Qualified Technicians Installation, Programming , & Maintenance (IP&M) Binder. 555-630-140 How to Comment on This Document We welcome your comments, both good and bad.
Page 318 FEEDBACK FORM ® MERLIN LEGEND Communications System Release 3.0 Title: Maintenance and Troubleshooting Order No.: 555-630-140 Date: August 1994 Please rate the effectiveness of this book in the following areas: Excellent Fair Good Poor Applicable Ease of Use Clarity Completeness Accuracy Organization Appearance...
Page 319: Introduction
Introduction The purpose of maintenance is to detect, report, and clear problems quickly with minimal disruption of service, The system attempts to isolate each problem to a single replaceable unit, whenever possible, by running automatic tests. Errors that it cannot automatically correct are usually recorded in error logs.
Page 320 Equipment Detailed information about system programming is included in System Programming and in System Programming and Maintenance (SPM). You can use either a DOS PC or a Master Controller (MCII or MCIII). To connect a PC to the control unit, you need a 355AF adapter and a D8W-87 cord. NOTE: On-site programming maintenance is preferred if it is feasible;...
Page 321: On-Site Programming Maintenance
On-Site Programming Maintenance On-Site Programming Maintenance You can perform on-site maintenance with an MLX-20L console or a PC with SPM software. This book provides maintenance instructions from the console. If you are using a PC, refer to System Programming and Maintenance (SPM) ®...
Page 322 On-Site Programming Maintenance A l t e r n a t e M L X - 2 0 L Default Jacks Default (the first five) “T I I Line Jack Line Jack 408 GS/LS-MLX 008 MLX Underneath the MLX-20L Console Figure l–l.
Page 323 On-Site Programming Maintenance Setting Up the PC Plug a PC into the ADMIN jack on the processor module as shown in Figure 1-2. If you are using a remote PC for system programming, see “Remote Programming Maintenance.” Processor Module ADMIN J a c k EIA-232-D Figure 1-2.
Page 324: Remote Programming Maintenance
Remote Programming Maintenance Remote Programming Maintenance Remote maintenance allows you to support the system from an off-premises location. You can check error logs and system status and restart the system remotely. To perform remote maintenance, you need a PC with SPM software, a tip/ring telephone, and a 1200-bps modem.
Page 325 Remote Programming Maintenance Setting Up Equipment for Remote Maintenance To setup equipment for remote maintenance, follow the steps below while referring to Figure 1–3 and to Installation. Connect the PC and modem. If you have an external modem, use an cable.
Page 326: Using Spm
\Using SPM Using SPM For more information on using SPM, see System Programming and Maintenance. Starting SPM The procedure for accessing SPM differs slightly, depending on whether your PC is connected directly or by modem to the control unit. With a Direct Local Connection To access SPM when your PC is connected directly to the control unit, follow the steps below.
Page 327 Using With a Local or Remote Modem Connection When the equipment is set up, you can perform remote maintenance by dialing the remote processor’s built-in 2400/1200-bps modem. You can dial the modem directly or call the system operator and request to be transferred to the modem.
Page 328 Using SPM Dialing the Modem Directly To dial the modem directly, follow the steps below. Start SPM. When the Welcome message appears, press any key. Enter the command to put the modem in originate mode (this command varies depending on the type of modem you are using). Pick up the handset on the T/R telephone and dial the remote access trunk number.
Page 329 Using SPM Console Display/Instructions Additional Information 7 Enter the password. Enter Password Type the remote access password. The password you enter does not appear as you type it. Select an option. SPM Main Menu Press one of the function keys. Menu: Select Function Maintenance (F6)
Page 330: The Spm Display
Using SPM The SPM Display SPM screens simulate the MLX-20L console (see Figure 1-4). D r o p Home MORE ALT-P QUIT Welcome to SPM P g U p MENU INSP P g D n The MERLIN LEGEND Flash System Programming ALT-F &...
Page 331 Using SPM A list of labels on the right side of the screen shows key combinations that correspond to buttons on the MLX-20L telephone. Table 1–1 describes the function of PC keys within SPM. Table 1-1. Function of PC Keys in SPM PC Key Console SPM Function...
Page 332 Using SPM Table 1–1 Continued (Ctrl) + (F1) Help. Display a help screen about SPM operations. To exit from Help, press (End) . (Ctrl) + (F5) Reset. Reset the communications port. For example, if the information on the screen is garbled, try exiting from and then recentering the screen.
Page 333: Preparation For Hardware Maintenance
Preparation for Hardware Maintenance Exiting SPM To exit SPM, follow these steps. 1 Return to the System Programming menu. If the display gives directions for returning to the main menu, follow the directions. If not, press (F10) (Exit) to return to the previous menu. Continue to press (F10) (Exit) until the main menu appears.
Page 334 Preparation for Hardware Maintenance If you have a MERLIN LEGEND Communications System (Release 2.0 or earlier): 1. Pry the clips from the housing on both sides of the control unit; use a screwdriver if they are difficult to remove. 2. Carefully pull the housing towards you. NOTE: If the MERLIN LEGEND (Release 2.0 or earlier) system has more than one carrier, make sure you hold the housing assembly on the basic carrier at the...
Page 335: Disconnecting Ac Power
Preparation for Hardware Maintenance Disconnecting AC Power To disconnect the AC power, see Figure 1-6, and follow the steps below. 1 Disconnect the AC power to each auxiliary power unit by unplugging the power cord from the wall outlet. 2 Disconnect the AC power to each carrier by unplugging the power cord from the wall outlet.
Page 336: Maintenance Strategy
Maintenance Strategy Maintenance Strategy The maintenance strategy presented in this section is only a guideline, not a fixed procedure. Refer to Figure 1-7 whenever you are uncertain as to how to proceed. As you become more experienced with maintaining and troubleshooting the system, you will most likely develop your own strategy.
Page 337 Maintenance Strategy Trouble Reports System trouble can be reported in two ways: By users By system alarms (permanent errors) Automatic Tests The system performs ongoing maintenance automatically by running tests t h a t : Monitor the status of equipment. Audit operations consistency.
Page 338: Clearing Alarms
Maintenance Strategy If a software installation or upgrade is taking place, a blinking character is displayed to indicate the status of the procedure. See "Forced Installation of System Software” in Chapter 4 for more information. The status display indicates an alarm (on an MLX-20L console or a PC running SPM), and can be viewed on the Error screen.
Page 339 Maintenance Strategy Warm Start A loss of power for less than 250 ms can cause a warm start. If this occurs, calls in progress are not dropped, but calls in the process of being connected may be dropped. Considerations Power interruptions of less than 100 ms usually do not affect the system.
Page 340 Maintenance Strategy Frigid Start (System Erase) CAUTION: All system programming is erased. When you perform a frigid start (System Erase), all calls are dropped, and the system configuration information is erased. All system memory must be reinitialized, including system programming. Then the entire system must be rebooted. To perform a frigid start, select as follows: System Erase...
Page 341 Maintenance Strategy Isolating the Trouble You can isolate any problem to one of the following areas: Telephone Control unit Central office NOTE: If you change the jack assignment of any telephone, be sure to record the extension jack change on Form 2a, System Numbering: Extension Jacks. See Appendix B, “System Numbering Forms,”...
Page 342 Maintenance Strategy Check the permanent errors. If errors still exist, check the transient errors. Check the last 10 errors whenever you want to review the 10 most recently recorded errors-either permanent or transient. Trouble Accessing the Error Logs If you cannot access the error logs, or if the system is inoperable, use the following steps as a guideline to troubleshoot the system.
Page 343 Maintenance Strategy Once you receive that information, use any maintenance or system programming feature that may lead to the root of the problem. See “Access Log for Maintenance and System Programming” in Chapter 2 for additional information. See System Programming for information about system programming and the Inspect function.
Page 344: Unit Loads
Unit Loads Check the Trunks Troubleshoot the trunks that are connected to the control unit. See Chapter 5, “Central Office Problems.” Check the Central Office If the error logs indicate the central office as the source of the problem, and you have resolved all other possible causes, notify the customer that they should call the central office and ask the central office to check the problem at their end (see Chapter 5, “Central Office Problems”):...
Page 345 Unit Loads Only the telephones and adjuncts that connect to the analog and digital ports on the control unit require unit load calculation. Do not include any equipment with its own power supply (for example, an answering machine) in the unit load calculation.
Page 346 Unit Loads Auxiliary Power Units The power supply provides 54 unit loads (102.6 watts) to each carrier. If the unit load requirement for a carrier exceeds 54 (102.6 watts), an auxiliary power unit is needed to allow that carrier to support an additional 27 unit loads (51.3 watts).
Page 347: Error Logs, Access Logs, And System Inventory
Error Logs, Access Logs, and System Inventory As described in “Maintenance Strategy” in Chapter 1, much of your troubleshooting relies on the error logs and the access log, for maintenance and system programming. Both of these maintenance features are described here in detail.
Page 348: Error Log
Error Logs Table 2-1. Transient/Permanent Error Thresholds Error Transient/Permanent Threshold Code Error Description 7402 LOOP BIT CONTROL NOT SET 7403 NO LOOP CURRENT 7404 STUCK RINGING 8403 NO EXTERNAL RELEASE 840B NO LOOP CURRENT STUCK RINGING 840C INCORRECT FIRMWARE STATE 840D Checking the Error Logs Once you have reviewed the error logs, you should print the error information.
Page 349 Error Logs To check the error logs, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the System option. Maintenance Make a selection System Slot Port Exit (F1) 2 Select Error Log. System: Make a selection Status Upgrd/Instll Error Log...
Page 350 Error Logs Checking Permanent Errors Follow Steps 1 through 3 above for “Checking the Error Logs. ” In Step 3, select Permanent. Additional Information Console Display/Instructions Permanent Errors: > xxxxxxxxxxxxxxxxxxxxxx Press the More button to page (PgUp) Slot xx Port xx count xxx through the permanent errors.
Page 351 Error Logs Checking the Last 10 Errors Follow Steps 1 through 3 above for “Checking the Error Logs.” In Step 3, select Last 10. Console Display/Instructions Additional Information Last 10 System Errors> xxxxxxxxxxxxxxxxxxxxxx Slot xx Port xx Last mm/dd/yy hh:mm Code xxxx Press the More button to page Exit...
Page 352 Error Logs Table 2-2. Error Codes Error Action Codes Description No action required; however, if problem 000l TIMEOUT COLD START: persists, troubleshoot the processor. System programming is okay. No action required; however, if problem POWER UP WARM START: 0002 persists, troubleshoot the processor. System programming is okay.
Page 353 Error Logs Table 2-2 Continued Error Action Codes Description 0009 FRIGID START: If the processor was removed while in System was restarted and initialized use, the system may perform a frigid start to default programming. due to loss of system programming. Restore system as described in System This error is also logged after a...
Page 354 Error Logs Table 2-2 Continued Error Codes Description Action 0012 INVALID RESET FLAG: Troubleshoot the processor. Processor problem. 0013 DUART STREAMING INT: Troubleshoot the processor. Processor problem. 0014 PROCESSOR ERR INTERRUPT: Troubleshoot the processor. Processor problem. 0015 MODULE MISMATCH: Change system programming to reflect Physical and logical type mismatch.
Page 355 Error Logs Table 2-2 Continued Error Codes Description Action 1C03 FW UPGRADE COMPLETE No action required. 3001 ALARM TABLE FULL: Correct indicated errors, and then The error logs are full, and no more remove entries from the transient system errors can be added to them. error log to free up space.
Page 356 Error Logs Table 2-2 Continued Error Action Codes Description DS1 YELLOW ALARM: Troubleshoot the T1 trunk. If problem 6C04 The far end of the network interface has persists, check the CSU and the DS1 lost frame synchronization. configuration (the framing format). If problem persists, escalate to your Service on the link has been lost.
Page 357 Error Logs Table 2-2 Continued Error Codes Description Action 6COA DS1 SLIP ALARM: Troubleshoot the T1 trunk. If problem Slip count reached 88. persists, escalate to your technical support organization. Maintenance Slot Error Events Current hr 6C0B DS1 HARDWARE INOPERATIVE: If problem persists, escalate to your DS1 hardware is not operating technical support organization.
Page 358 Error Logs Table 2-2 Continued Error Action Codes Description Troubleshoot the PRI trunk and report to 7005 PRI B-CH GROUP INCONSIST: service provider; otherwise, no action required. If problem persists, contact your technical support organization. 7401 TRK UPLINK MESSAGE ERROR: Test the trunk with a single-line telephone.
Page 359 Error Logs Table 2-2 Continued Error Action Codes Descrption 7404 STUCK RINGING: Test the trunk with a single-line Communication problems between telephone. If the problem is not in the the module and central office. trunk, replace the module with one that is If this error occurs twice known to be working.
Page 360 Error Logs Table 2-2 Continued Error Action Codes Description NOT IN STANDBY MODE: Reset the board. If problem persists, 7806 troubleshoot the module. Reported during cold start or background check. 7807 SELF TEST NOT COMPLETER Reset the board. If problem persists, troubleshoot the module.
Page 361 Error Logs Table 2-2 Continued Error Codes Description Action 8401 MISCELLANEOUS ERROR: action required. currently not reported. 8402 WINK TOO SHORT: Troubleshoot the far end of the network Outbound dialing problems on tie interface to see if it is working and translated properly.
Page 362: Continued On Next Page
Error Logs Table 2-2 Continued Error Action Codes Description 8405 ON HOOK BEFORE READY: Troubleshoot the far end of the network interface to see whether it is working and Outbound dialing problems on tie trunks. For a tie trunk with delay dial translated properly.
Page 363 Error Logs Table 2-2 Continued Error Action Codes Description 840B NO LOOP CURRENT: Replace the module with a similar module and test, If the problem is communication problems between the module and the central office. No resolved, replace the bad module. If the loop current.
Page 364: Access Log
Access Log Table 2-2 Continued Error Action Codes Description 840E UPLINK MESSAGE ERROR: Turn the processor off and then on. Repeat system programming procedure. Communication problems between If the problem persists, replace the the processor and the modules. The module. module received an unrecognized message from the processor.
Page 365 Access Log Scanning the Log The last 20 events are shown, beginning with the most recently accessed event. When you reach the end of the list, you hear a beep and all variable information is cleared from the screen. To return to the beginning of the list, select and then select again.
Page 366 System Inventory The screen below shows the access log. Additional Information Console Display/Instructions SysProg/MaintAccessLog > Time Sta Date SP/M mm/dd/yy hh:mm xxxx xx mm/dd/yy hh:mm xxxx xx mm/dd/yy hh:mm xxxx xx To page through the events, press mm/dd/yy hh:mm xxxx xx (PgUp) the More button.
Page 367: System Inventory
System Inventory Console Display/Instructions Additional Information 2 Select the Inventory option. System: Make a selection Upgrd/Instll Status Error Log Inventory Access Log Exit Enter (F3) When you access the System Inventory screen, Slot 00 information is displayed. Line 3 indicates that the processor occupies Slot 00. System Inventory Slot 00 Press the More button to review...
Page 368 System Inventory The screen below displays information for slots other than Slot 00. Console Display/Instructions Additional Information System Inventory: xx = slot number entered in Step 2 Slot xx Press the More button to review Board boardname information for each subsequent slot. Hardware Vintage: vv When you reach the display for the Firmware Vintage: vv...
Page 369: Telephone Problems
Telephone Problems Once you isolate a problem to the telephone (or a group of telephones), you can run various tests to check a telephone’s operation. Use the procedure below as a general guideline for troubleshooting telephones. 1 Replace the telephone (or adjunct) with one that works properly. If the problem persists, connect the telephone directly to the control unit, using a cord that works properly.
Page 370: Fixing Telephone Problems
Fixing Telephone Problems of any telephone, be sure to record the If you change the jack assignment on Form 2a, System Numbering: Extension Jacks. See extension jack change Appendix B, “System Numbering Forms,” for details. Fixing Telephone Problems If a reported telephone problem matches any symptom described in Table 3–1, refer to the proper section of this chapter.
Page 371 Fixing Telephone Problems NOTE: Refer to “Troubleshooting Trunk Problems” in Chapter 5 if the reported problem is echo during conversations on T1 trunks with GS emulation connected to a toll office. Check modular connections in the telephone for loose or broken connectors.
Page 372 Fixing Telephone Problems 12 Replace the wiring between the module jack field and the telephone to see if there is a wiring problem. Analog Multiline Telephone Problems If telephone LEDs and/or ringing tones do not work properly on analog multiline telephones, follow the steps below. 1 Move the T/P switch on the left-hand side to the T (test) position.
Page 373 Fixing Telephone Problems Single-Line Telephone Problems If more than one single-line telephone cannot dial correctly, even though they are receiving calls, use the steps below to test the touch-tone receivers (TTRs) for a single-line telephone. Pick up the handset; then dial and the 2-digit number of the TTR you want to test.
Page 374: Mlx Telephone Tests
MLX Telephone Tests Cancel the Call Forwarding feature (for the receiving telephone): Feature On multiline telephones, press the button and dial *34*. On single-line telephones, pick up the handset, dial and then #*34*, hang up. NOTE: You can cancel Call Forwarding from the receiving telephone or from the forwarding telephone, providing that you know the number.
Page 375 MLX Telephone Tests Press each fixed-feature button that does not have an LED (Transfer, Conf, Drop, and Hold) and each dialpad button. When you press each one of these buttons, the Message LED should toggle on and off. Press the fixed-feature buttons and the dialpad buttons in the order shown below to turn on all the LEDs.
Page 376: System Requirements For Touch-Tone Receivers
System Requirements for Touch-Tone Receivers 11 If these tests fail, replace the MFM. Table 3–2. MLX Telephone Display Buttons Button Display HOME Home Menu MENU MORE More Inspct INSPECT DISPLAY BUTTON nn; where nn is 1–10, depending Each unlabeled display button on which button you press.
Page 377 System Requirements for Touch-Tone Receivers Estimate the hourly call volume for calls originating from single-line telephones, incoming calls on remote access and Direct Inward Dial (DID) lines, and calls on tie lines. Use Table 3-4 to determine the number of TTRs required by the system. Use Column 2 if account codes are not being used.
Page 378 System Requirements for Touch-Tone Receivers Table 3-4 estimates the total number of TTRs required in the system, based on call volume and whether the system uses account codes. The call volume in this table includes all calls originating from single-line telephones, calls on tie lines, incoming remote access and Direct Inward Dial (DID) calls, and calls routed to the voice messaging system.
Page 379: Control Unit Problems
Control Unit Problems The next step after resolving problems with telephones, adjuncts, and related wiring, is to troubleshoot the control unit. Troubleshoot the control unit components in the following order: Power supply Processor Line/trunk and extension modules (hereafter referred to as modulles) Carrier WARNING: Beware of hazardous voltages.
Page 380: Power Supply Problems
Power Supply Problems Save the system programming to a memory card (beginning with Release 3.0). See Appendix D, “Backing up with a Memory Card, ” for detailed instructions. If automatic backups are performed, it may not be necessary to save system programming. NOTE: If the processor module is not functioning, it may not be possible to back up system programming.
Page 381 Power Supply Problems The green power LED should light on each power supply. The red LED on the processor should turn on for 15 to 45 seconds and then turn off. All indicators on the 100D and 400EM modules (if present) should turn on and then off.
Page 382 Power supply Problems Interlocking Post Figure 4-1. Power Supply Interlocking Post If the interlocking post is not broken, reinstall the power supply; follow Steps 5-8 in “Replacing the Power Supply” Iater in this chapter. Replacing the Ring Generator If tip/ring devices (such as single-line telephones, fax machines, and answering machines) do not ring, and an older 012 module is installed, try the procedure below.
Page 383 Power Supply Problems Current 012 modules contain built-in ring generators [apparatus code 517G13 (28) or higher letter]. If tip/ring devices connected to a newer module do not ring, see “Module Problems” later in this chapter. See Table 4–1 below to determine which 012 module is installed.
Page 384 Power Supply Problems 7 Remove the four screws from the ring generator, as shown in Figure 4-2. 8 Remove the ring generator. 9 Position the replacement ring generator, as shown in Figure 4-2. Align the screw holes. Make sure the PI header on the ring generator is on the same side of the power supply housing as the P101 header on the circuit board.
Page 385 Power Supply Problems Step 7: Remove the four screws (one in each comer of the ring generator) Steps 1 through 3: RING GENERATOR Open the power supply UNIT WIRE WIRE CLIP C L I P Step 4 Detach cable Step 4 from wire clip Detach cable from wire clip...
Page 386 Power Supply Problems Replacing Auxiliary Power Units Follow this procedure if any of the following symptoms occur: The LEDs on the multiline telephones that are connected to the last two modules in the carrier do not light. The last two slots in the carrier do not have power. The power supply LED is off.
Page 387 Power Supply Problems -48 VDC Auxiliary Power Auxiliary I n p u t Power U n i t POWER INPUT Input - 4 8 V D C Power Cord Ferrite Ground Cores Wire AUX Power Unit AC Power Cord Outlet Control Unit AC Power Cord Figure 4-3.
Page 388 Power Supply Problems Replacing the Power Supply WARNING: Beware of hazardous voltages; whenever the carrier connections are exposed, use extreme caution; do not touch them directly or with any type of tool. Follow ail procedures carefully. To remove the power supply module, follow the steps below. If possible, backup system programming on a memory card (Release 3.0 only) or floppy disk.
Page 389 Power Supply Problems To replace the power supply module, follow the steps below and refer to Figure 4-3. Insert a new power supply. a Reinstall the power supply module by hooking the top into the basic carrier and then swinging it down into place. Push the lower end firmly until the locking tab clicks.
Page 390: Processor Problems
Processor Problems Processor Problems If the error logs (or any aspect of troubleshooting) indicate that the processor is the problem, back up system programming if possible. See System Programming and Maintenance (SPM) for instructions on backing up to a floppy disk. See Appendix D, "Backing Up with a Memory Card," for instructions on backing up to a PCMCIA card.
Page 391 Processor Problems To perform Peek, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Slot option. Maintenance Make a selection System Slot Port Exit (F2) 2 Specify Slot 00. Slot: Dial or type then select Enter.
Page 392 Processor Problems Additional Information Console Display/Instructions 4 Select the Peek option. are not Poke System Erase Demand Test Slot 00: displayed, which prevents customers Make a selection from accidentally changing the Peek processor memory. [Poke] [System Erase] (F1) Exit 5 Dial a memory address. Slot 00 Enter Hex Dial [ nnnnnnnn ], then select Enter.
Page 393 Processor Problems Poke CAUTION: not perform Poke unless you are following instructions from your technical support organization. Summary Console Procedure: Menu Maintenance Slot Dial 00 Enter Dernand Test Poke (Line 4, left Poke (Line 4, left button) button) Continue (F6) (F2) Type 00 (F10)
Page 394 Processor Problems Additional Information Console Display/Instructions 3 Select the Demand Test. Slot 00: Make a selection Status Demand Test Exit (F2) 4 Select Poke two times. are not Demand Test Slot 00: Poke System Erase displayed, which prevents customers Make a selection from accidentally changing the Peek processor memory.
Page 395 Processor Problems Console Display/Instructions Additional Information Dxaaaaaaaa Enter data: Enter Backspace Exit System Erase (Frigid Start) CAUTION: Do not perform a System Erase unless you are installing a replacement processor or following instructions from your technical support organization. This procedure erases all system programming from the processor and resets the system to factory defaults.
Page 396 Processor Problems Additional Information Console Display/Instructions 1 From the Maintenance menu, select the Slot option. Maintenance Make a selection System Slot Port Exit (F2) 2 Specify Slot 00. Slot: Dial or type then select Enter. Enter Slot number (00-17) Backspace Exit Enter 3 Select the Demand Test.
Page 397 Processor Problems Console Display/Instructions Additional Information 5 Select Yes. Slot 00 System Erase: System will be down... Do you want to continue? Exit (F2) System Erase: Full-default Restarting Forced Installation of System Software CAUTION: Forced installation should only be performed under emergency situations in which on-board system software has been corrupted.
Page 398 Processor Problems Summary Maintenance System Console Procedure: Menu Upgrd/Instll Exit Exit PC Procedure (F6) (F1) (F5) (F2) Backup system programming. To back up system programming onto a floppy disk, see System Programming maintenance (SPM). To back up onto a memory card, see Appendix D, “Backing Up with a Memory Card.”...
Page 399 Processor Problems PROCESSOR MODULE Error/Status Code Display PCMCIA Interface Slot Push in to remove Memory Card Memory Card Alarm Status Figure 4-4. Inserting a Memory Card Control Unit Problems 4-21...
Page 400 Processor Problems Additional Information Console Display/Instructions 3 Initiate the software installation. Maintenance Make a selection System Slot Port Exit (F1) If the maintenance screens are functioning correctly, select System from the Maintenance menu. Continue with Step 4. If maintenance screens are unreliable or not available, power cycle the system by turning off the system and leaving it off for at least one second.
Page 401 Processor Problems Additional Information Console Display/Instructions Upgrade/Installation: Validation of Memory Card Successfully Completed. Exit (F5) When completed, select Exit to continue. 6 Verify that the memory card or release number is the required one, and select Exit to continue. Upgrade: MemCard Rel: 3.y Vnn.mm Current Rel:...
Page 402 Processor Problems Console Display/Instructions Additional Information If the release number is the one you want, select Yes. Upgrade/Installation: System will be down . . . Do you want to continue? Exit (F2) If the forced installation is attempted while a line/trunk or extension is busy, the following screen appears.
Page 403 Processor Problems 10 Remove the memory card from the interface slot. 11 Verify that system software has been correctly installed and that the default system programming is present. No error condition is displayed on the error/status display, 12 Restore system programming. After about 10 minutes, check to see if the red alarm status LED is lit, (RED).
Page 404 Processor Problems Table 4-2. Codes Displayed on the Error/Status Display During Forced Installation Action Code Meaning Upgrade is in progress. No action required Install is in progress. No action required Insert correct memory card and repeat Incorrect memory card forced installation procedure. type Memory card corrupted Insert new memory card and repeat forced installation procedure.
Page 405 Processor Problems Missing Card or Card Not Inserted Correctly Upgrade/Installation Verify that Memory Card has been installed correctly. Exit Insert the memory card correctly; then select and begin the forced Exit installation procedure again. Memory Card Is Wrong Type Upgrade/Installation Memory Card is not the correct type.
Page 406 Processor Problems System Busy If the forced installation is attempted while a line/trunk or extension is busy, the following screen appears. System Busy - Pls Wait Dial Code:xxxx S/P:ss/pp Exit When all lines/trunks or are freed, the installation continues. Select extensions to return to the System menu and cancel the installation.
Page 407 Processor Problems CAUTION: If releases are incompatible, pressing the hidden key will delete existing programming. Before pressing the hidden key, make a backup of the system programming. Use the SPM or PCMCIA translation card. Console Display/Instructions Additional Information If the releases are incompatible, the following screen appears. Upgrade: MemCard Rel: 3.y Vnn.mm Current Rel: 3.y Vnn.mm...
Page 408 Processor Problems Replacing the Processor Module A failed processor module must be replaced immediately. To replace the processor module, follow the steps below. If possible, save system programming. See Appendix D, “Backing Up with a Memory Card.” To back up onto a floppy disk, see System Programming and Maintenance (SPM).
Page 409 Processor Problems The backup floppy disk or original system programming disk. See System Programming and Maintenance for instructions. The backup memory card or original system programming memory card (Release 3.0 and later). See Appendix D, “Backing Up with a Memory Card,” for instructions. Reconnect the D8W cord(s) connecting the SMDR printer and/or system programming PC.
Page 410 Processor Problems CAUTION: Grasping only one of the rings may cause damage to components on the processor circuit board or feature module. Check the HDR4 header on the processor circuit board for proper mode operation. (For more information about modifying the mode, see Chapter 2 of Installation.) Figure 4-5.
Page 411: Module Problems
Module Problems 6 Align the connectors on the new feature module with the connectors in the processor (see Figure 4-5). 7 Firmly press the new feature module into the processor. 8 Insert the processor back into the carrier. (For more information about inserting the processor, see Chapter 2 of Installation.) Module Problems If you...
Page 412: Module Test Process
Module Problems Module Test Process Figure 4-6 shows the module test process. Refer to it and the text that follows for the recommended approach to testing modules. Check the equipment: maintenance terminal power supply (use the PC when testing processor MLX modules) (back up the system programming) 2 Check the error logs...
Page 413 Module Problems Considerations test procedure. Review the following items before you begin a module System Components system components Before running a module test, make sure the following are working: Power supply Processor. Save the system programming onto a floppy disk. See System Programming and Maintenance (SPM.) To back up onto a memory card, see Appendix D, “Backing Up with a Memory Card.
Page 414 Module Problems NOTE: If the system does not recognize a 408 GS/LS-MLX module during testing, check the release number of the system. The 408 GS/LS-MLX module does not work with Releases 1.0 or 1.1. An 008 MLX module must be used to provide extension jacks with Releases 1.0 or 1.1.
Page 415 Module Problems Restoring automatically undoes the Busy-out and Reset. For additional information on restoring a module, see “Restore,” later in this chapter. Persistent Module Problems If any of the module tests fail and replacing the module does not clear the trouble, then: Several modules may be faulty.
Page 416 Module Problems Busy-Out Summary Console Procedure Menu Maintenance Slot Dial the slot no. Enter Busy-Out Yes. PC Procedure (F6) (F2) Type the slot no. (F10) (F2) (F1) Any module that you are about to test Appropriate Modules Time Estimate Once all calls are terminated, the busy-out completes in less than 1 second.
Page 417 Module Problems Console DispIay/Instructions Additional Information 3 Select Busy-Out. Slot xx: xx = slot number entered in Step 2 Make a selection Status Demand Te For all MLX modules, BChLoopbck Busy-out Reset also displayed as an option on this Restore Upgrade screen.
Page 418 Module Problems The screen below appears when the busy-out fails again; be sure to specify the correct slot. Additional Information Console Display/Instructions Step xx = slot number entered in Busy-Out Slot xx: Busy-out FAILED Exit Reset Summary Maintenance Slot Procedure Menu Dial the slot no.
Page 419 Module Problems Console Display/Instructions Additional Information Specify the slot number (nn = 00 to 17). Slot: Dial or type [ nn ], then select Enter. Enter Slot number (00-17) Backspace Enter Exit Select Reset. Slot xx: xx = slot number entered in Step 2 Make a selection Status Demand Test...
Page 420 Module Problems The screen below appears while the module is discontinuing service to lines/trunks and extensions. All calls progress are being dropped. Console Display/Instructions Additional Information slot Reset Slot xx: xx = number entered in Step 2 Reset in Progress Exit The screen below appears when the module is successfully reset.
Page 421 Module Problems Summary Console Procedure Menu Maintenance Slot Dial the slot no. Enter Restore Yes. (F6) (F2) Type the slot no. (F10) (F3) (F1) PC Procedure Appropriate Modules Any module after testing it Time Estimate Less than 1 second. To restore the module, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Slot option.
Page 422 Module Problems Additional Information Console Display/Instructions 3 Select the Restore option. xx = slot number entered in Step 2 Slot xx: Make a selection Demand Test For all MLX modules, Status BchLoopback Reset Busy-out also displayed as an option on this Restore Upgrade screen.
Page 423: Internal Loopback Test
Module Problems The screen below appears when the Restore fails. Try again, and be sure to specify the correct slot. Console Display/Instructions Additional Information Restore Slot xx: xx = slot number entered in Step 2 Restore FAILED Board Mismatch Exit Internal Loopback Test This test checks communication between the processor and the module being tested.
Page 424 Module Problems Busy-Out or Reset Busy-out or reset the module being tested prior to beginning the test. Both Busy-Out and Reset are in the Slot menu, which you can access by doing the following from the console: Maintenance Slot Menu See “Busy-Out and Reset,”...
Page 425 Module Problems Console Display/Instructions Additional Information 2 Specify the slot number (nn = 00 to 17). Slot: Dial or type [ nn ], then press Enter. Enter Slot number (00-17) Backspace Exit Enter 3 Select Demand Test. Slot xx: xx = slot number entered in Step 2 Make a selection Status Demand Test...
Page 426 Module Problems The screen below appears while the test is running. At the same time, if the module has a green LED, it flashes. Additional Information Console Display/Instructions Demand Test Slot xx: xx = slot number entered in Step 2 aaaaaaaaaaaaaaaaaa Board Internal Loopback Test...
Page 427 Module Problems If the test fails, find the error message in Table 4-3 and proceed as indicated. Table 4-3. Internal Loopback Test Errors Error Messages Corrective Action Slot is not busied-out Exit the test, busy-out the slot, and try again. Slot empty or not valid Exit the test and try again;...
Page 428 Module Problems Board Controller Test This procedure tests the module’s internal functions, such as ROM, RAM, the timer, dual-port RAM, and so on. Summary Maintenance Slot Menu Dial the slot number. Console Procedure Enter Demand Test BoardCntrlr Test Once or Test Repetitive.
Page 429 Module Problems Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Slot option. Maintenance Make a selection System Slot Port Exit (F2) Specify the slot number (nn = 00 to 17). Slot: Dial or type [ nn ], then select Enter.
Page 430 Module Problems Additional Information Console Display/Instructions 5 Select Test Once or Repetitive. xx = slot number entered in Step 2 Demand Test Slot xx: aaaaaaaaaaaaaaaaa Board Board Controller: Test once Repetitive (F2) Exit (F3) while the test is running. At the same time, if the The screen below appears module has a green LED, it flashes.
Page 431 Module Problems Interpreting Test Results If the test completes successfully, the module’s board controller is functioning properly. Continue with the next module test or restore the module if you are finished testing. If the test fails, find the error message in Table 4-4 and proceed as indicated.
Page 432 Module Problems Summary Console Procedure Menu Maintenance Slot Dial the slot no. Enter BchLoopback PC Procedures (F6) (F2) Type the slot no. (F10) (F4) Appropriate Modules This test can be run only on MLX modules. Time Estimate Approximately 1.5 minutes. Busy-Out or Reset Before beginning the test, busy-out or reset the module being tested.
Page 433 Module Problems Console Display/Instructions Additional Information 1 From the main menu, select the Slot option. Maintenance Make a selection S y s t e m Slot (F2) Port Exit 2 Specify the MLX module’s 2-digit slot number (nn = 00 to 17). Slot: Dial or type [ nn ], then select Enter.
Page 434 Module Problems The screen below appears only if the module passes the test. Console Display/Instructions Additional Information BchLoopback Slot xx: xx = slot number entered in Step 2 BchLoopback Passed Exit The screen below appears only if the test fails. BchLoopback Slot xx: xx = slot number entered in Step 2 BchLoopback Failed...
Page 435: Replacing Modules
Module Problems Table 4-5. Channel Loopback Errors Error Messages Corrective Action Slot is not busied-out Exit the test, busy-out the slot, and try again. Slot empty or not valid Exit the test and try again; be sure to type the correct slot number.
Page 436 Module Problems CAUTION: This section does not apply to the processor or power supply. Although the system is designed so that you can remove and replace modules without affecting call processing, partially inserting and removing a module can cause a cold start. Adding a 100D module or changing any of its DS1 parameters requires that the system be idle.
Page 437 Module Problems 6 Restore the module. Lift up the module to disengage it from the rod at the top of the carrier. 7 Connect the trunk and extension cords. 8 Attach a tag, error printout, or any information that will help identify any visible problems, failure symptoms, and relevant error reports.
Page 438 Module Problems Go to the blue field on the cross-connect field and, starting at the top left corner, push the patch cord onto the first connecting block. Using the diagonal pliers or wire strippers, cutoff the other end of the patch cord and expose the pairs.
Page 439 Module Problems Firmware on this circuit module can be upgraded or reinstalled with an Upgrade memory card. An upgrade is performed when a new release of firmware enhances a module’s capabilities or corrects problems. Firmware can be reinstalled if the existing circuit module firmware has been corrupted. Summary Console Procedure Menu...
Page 440 Module Problems PROCESSOR MODULE Error/Status Code Display PCMCIA Interface Slot Push in to remove Memory Card Memory Card Alarm Status Figure 4-7. Inserting the Upgrade Memory Card To upgrade or reinstall circuit module firmware, follow the steps below. Insert an upgrade memory card containing the circuit module firmware into the PCMCIA interface slot on the processor board.
Page 441 Module Problems Console Display/Instructions Additional Information 2 From the Maintenance menu, select the Slot option. Maintenance: Make a selection System Slot Port Exit (F2) 3 Specify the slot number (nn =00 to 17). Slot: Dial or type [ nn ], then select Enter.
Page 442 Module Problems The screens below appear during the procedure. Additional Information Console Display/Instructions Module Upgrade: Validation of MemoryCard in Progress. Module Upgrade: Validation of MemoryCard Successfully Completed. (F5) Exit When completed, select Exit to continue. 5 Select the firmware to be programmed. xx = slot number entered in Step 3 Upgrade Slot xx: Line 2 displays the firmware version...
Page 443 Module Problems If the firmware selected provides functionality that is different from the circuit module’s current firmware, the Maintenance display indicates that a Board Renumber will be required once the installation is complete. Console Display/Instructions Additional Information Upgrade Slot xx: xx = slot number entered in Step 3 Slot will be Busied Out.
Page 444 Module Problems One of the following screens appears when the upgrade has successfully completed. If only a Restore is required to put the module back into service, the screen below appears. Additional Information Console Display/Instructions Upgrade Slot xx: Upgrade Successfully Completed.
Page 445 Module Problems Missing Card or Card Not Inserted Correctly Console Display/Instructions Additional Information Module Upgrade: Verify that Memory Card has been inserted correctly. Exit Insert the memory card correctly; then select and begin the upgrade Exit procedure again. Memory Card Is Corrupt Modulde Upgrade: Information on the Memory Card is corrupted.
Page 446 Module Problems This procedure can only be run on the 800 GS/LS-lD module or modules introduced after Release 3.0. Select and repeat the upgrade procedure, Exit being careful to select the correct slot. If upgrade canceled or upgrade appears on the error screen, circuit module may be unreliable incomplete or unusable until a successful upgrade is performed on it.
Page 447 Module Problems Memory Card File Error Console Display/Instructions Additional Information Upgrade Slot xx: xx = slot selected in Step 3. Memory Card file error. Exit Select then make sure that the memory card is properly inserted, and Exit, reinitiate the upgrade procedure. Upgrade Slot xx: xx = slot selected in Step Memory Card file error.
Page 448: D Module Problems
100D Module Problems Upgrade Attempted on an Empty Slot Additional Information Console Display/Instructions xx = slot selected in Step 3. Upgrade Slot xx: No module in slot. Exit Select and repeat the upgrade procedure, being careful to select the Exit correct slot.
Page 449 100D Module Problems Error Events In addition to checking the error logs, the 100D module requires that you check the error events specific to the 100D module. See "Error Events, ” later in this chapter, for details. CSU Loopback Test The Channel Service Unit (CSU) Loopback Test verifies that the communication path between the following CSUs, 551 T1, ESF T1, or the ®...
Page 450 100D Module Problems Interrupting the Test You can interrupt the test by selecting Exit. If the test fails, record the errors on the repair tag Test Failure and replace the module. Restore If the 100D module successfully completes the CSU Loopback Test, restore the module.
Page 451 100D Module Problems The ACCULINK 3160/3164 DSU/CSU is physically similar to the 3150 CSU with programming on the front panel and menus appearing on the LCD screen. For the preparation of specific tests, see the operator’s guide that comes with the unit. 551 T1 Channel Service Unit Figure 4-8.551 T1 CSU Loopback Connection Control Unit Problems 4-73...
Page 452 100D Module Problems SEND CODE DTE LOOPBACK ESF T1 CSU Eq SM SM U P / D N IN OUT MON MON IN OUT FRAME ALARM LOSS NEAR END LOOPED LOW DENS LOOPED CRC ERROR FRAME LOSS DIAGNOSTIC PULSES INTERFACE CRITICAL POWER LOCAL FAR END LOOPED...
Page 453 1000D Module Problems C S U E S F S t a t T e x t C n f i g > < Figure 4-11. ACCULINK 3150 CSU DTE Loopback Command 1 T e s t : R l p b k L p b k P t r n s <...
Page 454 Module Problems 100D L o o p b a c k : A b o r t L L B P L B > < Figure 4-13. ACCULINK 3150 CSU DTE Loopback Command 3 L o o p b a c k : >...
Page 455 100D Module Problems To run the CSU Loopback Test, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Slot option. Maintenance Make a selection System slot Port Exit (F2) Specify the 2-digit slot number (nn = 00 to 17). Slot: Dial or type [ nn ], then select Enter.
Page 456 100D Module Problems The screen below appears while the test is running. At the same time, the module’s green LED flashes. Additional Information Console Display/Instructions xx = slot number entered in Step 2 CSU-lpbk Slot xx: CSU-lpbk in Progress Exit The screen below appears only if the module passes the test.
Page 457 Module Problems 100D the error message in Table 4-6 and proceed as indicated. If the test fails, find Table 4-6. Internal Loopback Test Errors Error Messages Corrective Action Slot is not busied-out Exit the test, busy-out the slot, and try again. Slot empty or not valid Exit the test and try again;...
Page 458 100D Module Problems Restoring the Module After completing the CSU Loopback Test, follow the steps below to restore the module. If you are finished testing modules, restore the 100D module. Refer to “Restore,” earlier in this chapter, for instructions. 2 Reset the CSU. For the 551 T1 CSU, unplug the patch cord, first from the EQ IN jack and then from the EQ OUT jack.
Page 459 100D Module Problems Synchronization. The system maintains proper synchronization to the loop clock and switches to the local clock when the loop clock is not available (for example, during a loss of signal or a blue alarm). When the loop clock source is restored, the system switches back to the loop clocks.
Page 460 100D Module Problems Console Display/Instructions Additional Information Specify the 2-digit slot number (nn= 00 to 17). Dial or type [ nn ], then select Slot: Enter. Enter Slot number (00-17) Backspace Enter Exit Select Error Events. xx = slot number entered in Step 2 Slot xx: Make a selection Demand Test...
Page 461 100D Module Problems The screen below displays the errors that have accumulated during the current hour. Console Display/Instructions Additional Information Current hr Slot xx = slot number entered in Step 2 mm/dd/yy hh00-hh:mm CurAlm aaaa MaxAlm aaaa MIS SLP ES BS SEC FS xxx xxx xxx xxx xxx xxx Exit...
Page 462 100D Module Problems Additional Information Console Display/Instructions 1 From the Maintenance menu, select the Slot option. Maintenance Make a selection System Slot Port Exit (F2) (nn = 00 to 17). Specify the 2-digit slot number Slot: Dial or type [ nn ], then select Enter.
Page 463: Carrier Problems
Carrier Problems Console Display/Instructions Additional Information If you need assistance in interpreting the information displayed on the screen, contact your technical support. Clock Slot xx: mm/dd/yy hh:00-hh:mm Admin as: Active: synch source: PPM: xxx Exit Carrier Problems Typical carrier problems include power supply failure, sudden failure of one or more modules, or system problems that cannot be isolated to a specific module.
Page 464: Checking System And Slot Status
Checking System and Slot Status Remove the processor, the power supply, and all other modules from the faulty carrier. (If you prefer to remove the cords first, make sure they are labeled.) Put the modules aside, in order, so that you can reinstall them later in the replacement carrier.
Page 465 Checking System and Slot Status The System Status procedure allows you to check simulated LEDs for the processor and other modules. This is explained in detail in “Reading the System Status Screen, ” later in this chapter. Summary Maintenance System Status Menu Console Procedure...
Page 466 Checking System and Slot Status Interpreting the System Status Screen Console Display/Instructions Additional Information System Status: R aaa =status (On, Off, No) of red LED Slot00: R aaa Y aaa =status (On, Off, No) of yellow LED Slot01 R aaa Y aaa G aaa Slot02 R aaa Y aaa G aaa G aaa =status (On, Off, No) of green LED Slot03: R aaa Y aaa G aaa...
Page 467 Checking System and Slot Status If a slot is empty, appear without indicating a status. Slot 4 is R, Y, empty, according to the sample screen in the last procedure. Slot Status Slot Status provides the following information for a module in a particular slot: LED status Errors (yes or no)
Page 468 Checking System and Slot Status Additional Information Console Display/Instructions 2 Specify the 2-digit slot number (nn = 00 to 17). Slot: Dial or type [ nn ] and select Enter. Enter Slot number (00-17) Backspace (F10) Exit Enter 3 Select the Status option. xx=slot number entered in Step 2 Slot xx: Make a selection...
Page 469 Checking System and Slot Status If you selected Slot 00, the screen below appears. For detailed information about this status screen, see “Slot Status, ” earlier in this chapter. Status Slot 00: R aaa =status (On, Off, No) of red LED.
Page 470 Checking System and Slot Status 4-92 Control Unit Problems...
Page 471: Trunk Errors
Central Office Problems If you have tested the telephones and the modules in the control unit, you have isolated the trouble to the trunks or the CO. To isolate the trouble further, follow the instructions in this chapter to troubleshoot the trunks. If the trouble persists after following these instructions, the customer should contact the CO and ask a representative to troubleshoot from that end.
Page 472 Trunk Errors Table 5–1. Troubleshooting Trunk Symptoms Symptom Section Incoming calls not being received Incoming Trunk Problems Cannot make outgoing calls Outgoing Trunk Problems General trunk problems Manual Correction of Trunk Problems NOTE: If the customer reports ethos during conversations on T1 trunks with GS emulation to a toll office, check the system programming for T1 trunks.
Page 473 Trunk Errors Outgoing Trunk Problems If the system cannot sieze outgoing trunks, try the following procedure. NOTE: You cannot perform this procedure on a rotary telephone. Check for outside dial tone at the network interface. For GS trunks, apply ground to the ring lead to get dial tone. If dial tone is not present, notify the customer.
Page 474 Trunk Errors Incoming Trunk Problems If incoming trunks do not work properly, try the following procedure. Place an incoming call through the troubled trunk. For a loop-start (LS) trunk, connect a single-line telephone to the trunk at the network interface. For a ground-start (GS) trunk, connect a single-line telephone to the trunk at the network interface and press the GS button.
Page 475 Trunk Errors NOTE: Maintenance-busy does not apply to DID trunks, since DID trunks cannot be used to make outgoing calls. While the trunk is in a maintenance-busy state, the software periodically runs tests, attempting to seize the trunk: If the seizure is unsuccessful, the trunk stays in a maintenance-busy state.
Page 476 Trunk Errors Ground-Start (GS) Trunk The following events cause maintenance-busy on a ground-start trunk: A seizure of the trunk is attempted that results in incomplete handshaking (or no loop current) between the CO and the system. After four occurrences, the trunk is put into a maintenance-busy state and a permanent error is logged.
Page 477: Checking Ports
Checking Ports Maintenance-Busy Status See “Checking Ports” below for information on maintenance-busy status. Checking Ports You perform the following procedures from the maintenance terminal. By selecting from the Maintenance screen, you can check the maintenance- Port busy status and other information for individual trunks and extensions. Once you determine the maintenance-busy status, you might also be interested in the other features on the Port menu, which include the following: Resetting EIA-232 ports and modems...
Page 478 Checking Ports Additional Information Console Display/Instructions the Port option. 1 From the Maintenance menu, select Maintendnce Make a selection System Slot Port (F3) Exit 2 Select the Line/Trunk Option. Port: Make a Selection Line/Trunk Modem B-Channel Station RS232 Port1 RS232 Port2 Enter Exit (F1)
Page 479 Checking Ports Console Display/Instructions Additional Information 4 Select trunk Status. Line/Trunk xxx: xxx = line number entered in Step 3 Make a selection Status Busy out Restore Exit (F1) The maintenance-busy status for the trunk you selected is displayed as a or a in that field (line 6) on the screen below.
Page 480 Checking Ports Additional Information Console Display/Instructions 1 From the Maintenance menu, select the Port option. Maintenance Make a selection System Slot Port (F3) Exit 2 Select the Station (extension) option. Port: Make a Selection Modem Line/Trunk B-Channel Station RS232 Port1 RS232 Port2 Exit Enter...
Page 481 Checking Ports The maintenance-busy status for the extension selected is displayed as a or a in the field (line 6) on the screen below. Additional Information Console Display/Instructions Station: xxxx Dial Plan: xxxx SlotPort: sspp LogicId: xxx Profile: xxxxxxxxxx Maintenance Busy: Select to see the status of the Next...
Page 482 Checking Ports Additional Information Console Display/Instructions 2 Select the Line/Trunk option. Port: Make a Selection Modem Line/Trunk Station B-Channel RS232 Port1 RS232 Port2 (F1) Exit Enter 3 Specify the dial plan number (line) for the trunk (nnn = 801 to 880). Line/Trunk: Dial or type [ nnn ], then select Enter.
Page 483 Checking Ports Console Display/Instructions Additional Information Line/Trunk xxx: xxx = line number entered in Step 3 Busy-Out Successfully Completed Exit The screen below appears when Busy-Out fails. If this occurs, exit and again. Line/Trunk xxx: xxx = line number entered in Step 3 Busy-Out FAILED Exit Busying-Out an Extension...
Page 484 Checking Ports Additional Information Console Display/Instructions 1 From the Maintenance menu, select the Port option. Maintenance Make a selection System Slot Port (F3) Exit 2 Select the Station (extension) option. Port: Make a Selection Modem Line/Trunk B-Channel Station RS232 Port1 RS232 Port2 Enter (F2)
Page 485 Checking Ports Console Display/Instructions Additional Information 4 Select Busy-out. Station xxxx: entered xxxx = extension number Make a Selection in Step 3 Status Busy out Restore (F2) Exit The screen below is shown until Busy-Out finishes or fails. Station xxxx: xxxx = extension number entered in Step 3 Busy-Out in Progress...
Page 486 Checking Ports Restoring a Trunk Summary Menu Maintenance Port Line/Trunk Console Procedure Enter Restore Dial the dial plan no. PC Procedure (F6) (F3) (F1) Type the dial plan no. (F10) (F3) To restore a trunk, follow the steps below. Additional Information Console Display/Instructions 1 From the Maintenance menu, select the Port option.
Page 487 Checking Ports Console Display/Instructions Additional Information 4 Select Restore. Line/Trunk xxx: xxx= line number entered in Step 3 Make a Selection Status Busy Out Restore Exit (F3) The screen below is shown until Restore finishes or fails. line number entered in Step 3 Restore LIne/Trunk xxx: Restore in Progress...
Page 488 Checking Ports Restoring an Extension Summary Menu Maintenance Port Station Dial Procedure Enter Restore the dial plan no. PC Procedure (F6) (F3) (F2) Type the dial plan no. (F10) (F3) To restore an extension, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Port option.
Page 489 Checking Ports Console Display/Instructions Additional Information Specify the dial plan extension number (nnnn = 1- to 4-digit number). Station: Dial or type [ nnnn ], then select Enter. Enter station number nnnn Backspace Exit Enter Select Restore. Station: xxxx xxxx = extension number entered Make a Selection in Step 3 Status...
Page 490 Checking Ports The screen below appears when Restore fails. If this occurs, exit and try again. Additional Information Console Display/Instructions entered xxxx = extension number Restore Station: xxxx in Step 3 Restore FAILED Exit Resetting an RS-232 Port N (SPM) port is RS-232 Port 1, and the SMDR port is RS-232 Port 2. The ADMI Summary Maintenance...
Page 491 Checking Ports Console Display/Instructions Additional Information 2 Specify the RS-232 port. Port: Make a Selection Line/Trunk Modem Station B-Channel RS232 Portl (F3) RS232 Port2 Select RS232 Port1 (F4) Exit Enter RS232 Port2. 3 Select Reset. RS232 Port x: x = port selected in Step 2 Make a selection Reset (F1)
Page 492 Checking Ports The screen below appears when Reset is completed successfully. Additional Information Console Display/Instructions x = port selected in Step 2 RS232 Port x Reset: Reset Successfully Completed Exit If this occurs, exit and try again. The screen below appears when Reset fails. RS232 Port x Reset: Reset FAILED Exit...
Page 493 Checking Ports To reset the processor’s internal modem, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Port option. Maintenance Make a selection System Slot Port Exit (F3) 2 Select the Modem option. Port: Make a Selection Modem Line/Trunk...
Page 494 Checking Ports Additional Information Console Display/Instructions Select Yes. Modem Port Reset: Do you want to continue? Cancel (F2) Exit The screen below is shown until Reset fininshes or fails. Modem Port Reset: Reset in Progress Exit The screen below appears when Reset is completed successfully. Modem Port Reset: Reset Successfully Completed...
Page 495 Checking Ports Auditing DS1 PRI B-Channels The Auditing Lines and Auditing Calls procedures initiate an audit. Once an audit is initiated, you need to wait for the far end to send a message, which usually takes about four minutes. After waiting four minutes, check the error logs to see if any new PRI errors have occurred.
Page 496 Checking Ports To audit lines, follow the steps below. Console Display/Instructions Additional Information 1 From the Maintenance menu, select the Port option. Maintenance Make a selection System Slot Port Exit (F3) 2 Select the B-Channel option. Port: Make a Selection Line/Trunk Modem Station...
Page 497 Checking Ports Console Display/Instructions Additional Information 4 Select Audit Line. B-Channel xxxx: xxxx = slot and port number entered Make a selection Step 3. Audit Line Call Audit Exit (F1) The screen below appears only if the audit message is successfully created and sent.
Page 498 Checking Ports This indicates that the problem may beat the central office (CO) end. First, make sure the correct B-channel is selected. If the correct B-channel is selected, the customer or AT&T representative acting as the customer’s agent should ask the CO to clear the problem from that end. If the problem is not at the CO end, select the correct B-channel and repeat the Audit Lines procedure.
Page 499 Checking Ports Console Display/Instructions Additional Information 2 Select the B-Channel option. Port: Make a Selection Line/Trunk Modem Station B-Channel RS232 Port1 RS232 Port2 Exit Enter (F7) Specify the slot and port number (ss= 2-digit slot number; pp= 2-digit port number). B-Channel Dial or type [ sspp ] and select Enter.
Page 500: Conclusion Of Hardware Maintenance
Conclusion of Hardware Maintenance After about four minutes, check the error logs. If new PRI errors occur, contact your technical support organization for help on interpreting the results and your action. If no new PRI messages appear, the ends are most likely in agreement.
Page 501 Conclusion of Hardware Maintenance 2 Hold the top cover with the hooks facing you. 3 Engage the tabs at the rear of the top cover with the carrier. 4 Lower the top cover, so that the legs lock into the vents on the module. Installing the Front Cover To install the front cover, see Figure 5-2 and follow these steps.
Page 502: Installing The Control Unit Top Cover
Conclusion of Hardware Maintenance Top Cover Empty module Figure 5–1. Installing the Control Unit Top Cover (Release 2.1 and Later) 5–32 Central Office Problems...
Page 503 Conclusion of Hardware Maintenance Front cover Figure 5-2. Installing the Control Unit Front Cover (Release 2.1 and Later) Central Office Problems 5–33...
Page 504 Conclusion of Hardware Maintenance Installing the Control Unit Housing (Release 2.0 or Earlier) After you have completed maintenance and troubleshooting, follow the steps below to reinstall the Release 2.0 or earlier control unit housing. 1 Assemble the control unit housing. See Figure 5-3. If the housing is already assembled, go to Step 2.
Page 505 Conclusion of Hardware Maintenance Right Hand Front Panel Side Panel Line Up With the Semicircle on Inside of Front Panel Slide Tongues in and Push Front Panel Up Figure 5–3. Assembling the Control Unit Housing (Release 2.0 and Earlier) Central Office Problems 5-35...
Page 506 Conclusion of Hardware Maintenance Slide housing cover forward into clips Figure 5-4. Installing the Control Unit Housing (Release 2.0 and Earlier) Line up the wire clips attached to the carrier with the recesses on the outside of the side panels. See Figure 5-4. If the wire clips are not attached to the control unit, see “Installing the Housing Clips”...
Page 507: Support Telephone Number
Customer Support Information Support Telephone Number In the U.S.A. only, AT&T provides a toll-tree customer Helpline (1-800-628-2888) 24 hours a day. If you need assistance when installing, programming, or using your system, call the Helpline, or your AT&T representative. Outside the U.S.A., if you need assistance when installing, programming, or using your system, contact your AT&T representative.
Page 508: Interference Information
Customer Support Information Federal Communications Commission (FCC) Electromagnetic Interference Information This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 509 Customer Support Information FCC Notification and Repair Information This equipment is registered with the FCC in accordance with Part 68 of its rules. In compliance with those rules, you are advised of the following: Means of Connection. Connection of this equipment to the telephone network shall be through a standard network interface jack, USOC RJ11C, RJ14C, RJ21X.
Page 510 Customer Support Information If there are no directly terminated trunks, or if the only directly terminated facilities are personal lines, report the number AS5USA-65646-PF-E. The REN (Ringer Equivalency Number) for all three systems is 1.5A. — For tie line connection, the facility interface code (FIC) is TL31M and the service order code (SOC) is 9.0F.
Page 511 Customer Support Information Installation and Operational Procedures The manuals for your system contain information about installation and operational procedures. Repair Instructions. If you experience trouble because your equipment is malfunctioning, the FCC requires that the equipment not be used and that it be disconnected from the network until the problem has been corrected.
Page 512: Doc Notification And Repair Information
Customer Support Information — Perform such activities in off-peak hours, such as early morning or late evening. Direct Inward Dialing (DID). This equipment returns answer supervision signals to the Public Switched Telephone Network when: — Answered by the called station —...
Page 513 Customer Support Information Before installing this equipment, users should ensure that it is permissible to connect it to the facilities of the local telecommunications company. The equipment must also be installed using an acceptable method of connection. In some cases, the company’s inside wiring for single-line individual service may be extended by means of a certified connector assembly (telephone extension cord).
Page 514 Customer Support Information Renseignements sur la notification du ministère des Communications du Canada et la reparation AVIS: L’étiquette du ministère des Communications du Canada identifie Ie materiel homologué. Cette étiquette certifie que Ie matériel est conforme à certaines normes de protection, d’exploitation et de sécurité des réseaux de telecommunications.
Page 515 Customer Support Information AVERTISSEMENT: L’utilisateur ne doit pas tenter de faire ces raccordements lui-même; il doit avoir recours à un service d’inspection des installations électriques, ou à un electrician, selon Ie cas. L’indite de charge (IC) assigné à chaque dispositif terminal indique, pour éviter toute surcharge, Ie pourcentage de la charge totale qui peut être raccordée à...
Page 516 Customer Support Information MERLIN LEGEND D.O.C. Ministère des Communications du Canada Location Label Placement emplacement de I'étiquette A–10 Maintenance and Troubleshooting...
Page 517: Security Of Your System
Customer Support Information Security of Your System: Preventing Toll Fraud As a customer of a new telephone system, you should be aware that there is an increasing problem of telephone toll fraud. Telephone toll fraud can occur in many forms, despite the numerous efforts of telephone companies and telephone equipment manufacturers to control it.
Page 518 Customer Support Information The Remote Access feature, as designed, helps the customer, through proper administration, to minimize the ability of unauthorized persons to gain access to the network. Most commonly, phone numbers and codes are compromised when overheard in a public location, through theft of a wallet or purse containing access information, or through carelessness (for example, writing codes on a piece of paper and improperly discarding it).
Page 519: Limited Warranty And Limitation Of Liability
Customer Support Information When possible, restrict the off-network capability of off-premises callers, using calling restrictions, Facility Restriction Levels, and Disallowed List capabilities. When possible, block out-of-hours calling. Frequently monitor system call detail reports for quicker detection of any unauthorized or abnormal calling patterns. Limit Remote Call Forwarding to persons on a need-to-have basis.
Page 520 Customer Support Information The following will not be deemed to impair the good working order of the system, and AT&T will not be responsible under the limited warranty for damages resulting from: or maintenance Failure to follow AT&T’s installation, operation, instructions or alteration Unauthorized system modification, movement,...
Page 521: Limitation Of Liability
Customer Support Information Limitation of Liability EXCEPT FOR PERSONAL INJURY, DIRECT DAMAGES TO TANGIBLE PERSONAL PROPERTY PROXIMATELY CAUSED BY AT&T, AND LIABILITY OTHERWISE EXPRESSLY ASSUMED IN A WRITTEN AGREEMENT SIGNED BY AT&T, THE LIABILITY OF AT&T, ITS AFFILIATES, SUPPLIERS, AND AUTHORIZED RESELLERS FOR ANY CLAIMS, LOSSES, DAMAGES, OR EXPENSES FROM ANY CAUSE WHATSOEVER (INCLUDING ACTS OR OMISSIONS OF THIRD PARTIES), REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT,...
Page 522 Customer Support Information properly, evaluate and administer the various restriction levels, protect and carefully distribute access codes. Under applicable tariffs, you will be responsible for payment of toll charges. AT&T cannot be responsible for such charges and will not make any allowance or give any credit resulting from unauthorized access.
Page 523: Remote Administration And Maintenance
Customer Support Information — Assign toll restriction levels to all AUDIX Voice Power ports or other voice mail ports. — If you do not need to use the Outcalling feature, completely restrict the outward calling capability of the AUDIX Voice Power ports.
Page 524 Customer Support Information To reduce the risk of unauthorized access through Remote Administration and Maintenance, please observe the following procedures: The System Administration and Maintenance capability of a Hybrid/PBX or Key system is protected by a password. — Change the default password immediately. Continue to change the password regularly.
Page 525 System Numbering Forms When you change any existing trunk or extension wiring, record information about the wiring on the appropriate system numbering form. This appendix includes examples of all of the system numbering forms, and instructions for completing Form 2a, “System Numbering: Extension Jacks.
Page 526 System Numbering Forms Form 2a, System Numbering: Extension Jacks Renumber System* Selected Extension Numbers 3-Digit Set Up Space 2-Digit 2-Dig 3-Dig. AUDIX Mod. Log. Jack Type Set Up Renumber Wire Person Voice Ext. Ext. Label Type ID I D D† Eqpt.
Page 527 System Numbering Forms The following explains how to complete Form 2a. The number in the logical ID column refers to the number of the extension jack in the control unit. 1. In the “Eqpt” (Equipment). column, enter the type of device (such as an MLX-20L console) that is connected to the extension jack.
Page 528 System Numbering Forms Form 2b, System Numbering: Digital Adjuncts Maximum: 127 Adjuncts M F M F a c t o r y - S e t Telephone Log. Person, Location Set Up Renumber to SAA T/R Ext. No. 7500B Function, and Equipment Type 2-digit 3-digit Source...
Page 529 System Numbering Forms Form 2c, System Numbering: Line/Trunk Jacks Music-on-Hold, Line/Trunk No. Source Maintenance Alarm, Line/Trunk No. Loop-Start Reliable Disconnect Loudspeaker Page, Line/Trunk No(s). Q C C Incoming Operator Line/Trunk Toll Type Queue Type (Main Telephone Module Jack Type Pool Ourmode Prefix Req’d Hold Disc.
Page 530: Special Renumbers
System Numbering Forms Form 2d, System Numbering: Special Renumbers Group Calling Pools* (Form 7d) Factory-Set Renumber Factory-Set Renumber (Form 2c) Number Description Label Group Paging Renumber Factory-Set (Form 7b) Number Group ID 7920 7921 Park Zone 7922 Factory-Set Renumber (Form 6a) 7923 Number Description...
Page 531 Unit Load Calculation Worksheet If you determine that you need to recalculate the unit load for any carrier, use the instructions on the following worksheet. NOTE: You should have a separate copy of the worksheet for each carrier. See “Unit Loads” in Chapter 1 for information on recalculating unit loads.
Page 532 Unit Load Calculation Worksheet Unit Load Worksheet 1. Number of modules in carrier (excluding power supply and processor: If fewer than five, auxiliary power is not required. If five or six, continue to Step 2. Square 2. Key or Behind Switch mode only: Modified Indicate configuration of lines;...
Page 533 Unit Load Calculation Worksheet 5. Calculate the estimated unit loads. Q t y x Unit = Total Module Load 12.0 13.5 008 MLX 008 OPT 1OOD 400 EM 400 GS/LS/TTR 12.0 408 GS/LS 12.0 13.5 408 GS/LS-MLX 800 GS/LS 800 GS/LS-lD 800 DID Total Estimated Unit Load If the total is...
Page 534 Unit Load Calculation Worksheet 6. Calculate the actual carrier unit load, = Total Unit Load Qty x Hybrid/PBX or Modified Square Equipment Network Access Lines* GS/LS Telephones MLX-10 MLX-10D MLX-28D MLX-20L BIS-10 BIS-22 BIS-22D BIS-34 BIS-34D MLC-5 MDC-9000 MDCW-9000 10-Button Basic 10-Button HFAI 34-Button Basic 34-Button DLX...
Page 535 Unit Load Calculation Worksheet Unit Load Qty x = Total Equipment Hybrid/PBX or Square Modiffied Optional Equipment* Direct Station Selector* General Purpose Adapter Hands-Free Unit Headset Adapter Total Actual Unit Load † The MFM has its own wall power unit located at the telephone and therefore is not added to the unit load calculation.
Page 536 Unit Load Calculation Worksheet 7. Try to exchange modules between carriers to reduce the unit loads to 54. (Remember that the 100D, 400, 400 GS/LS/TTR, 800 GS/LS-lD, 800, and 800 GS/LS modules have unit loads of 0.0. ) Repeat Steps 1 through 6 to recalculate unit loads for the new configuration.
Page 537 Unit Load Calculation Worksheet 8. Calculate the unit loads for slots 5 and 6 of the carrier. Unit Load = Total Qty x Hybrid/PBX or Equipment Modiffied Square Network Access Lines* GS/LS 0 . 0 Telephones MLX-10 MLX-10D MLX-28D MLX-20L BIS-10 BIS-22 BIS-22D...
Page 538 Unit Load Calculation Worksheet Unit Load = Total Qty x Equipment Hybrid/PBX or Square Modiffied Optional Equipment Direct Station Selector* General Purpose Adapter Hands-Free Unit Headset Adapter Total Unit Load for Slots 5 and 6 † The MFM has its own individual wall power unit located at the telephone and therefore is not added to the unit load calculation.
Page 539 Unit Load Calculation Worksheet 9. Try to exchange modules between carriers to reduce the unit loads for slots five and six through 27. (Remember that the 100D, 400, 400 GS/LS/TTR, 800 GS/LS-lD, 800, and 800 GS/LS modules have unit loads of 0.0, ) Repeat Steps 1 through 8 to recalculate unit loads for new configuration.
Page 540 Unit Load Calculation Worksheet C-10 Maintenance and Troubleshooting...
Page 541 Backing Up with a Memory Card A PCMCIA (Personal Computer Memory Card International Association) interface slot is present on the processor module. The slot is a standard interface through which information can be added to or obtained from the system using a memory card. The PCMCIA interface slot accepts one memory card at a time.
Page 542 Backing Up with a Memory Card Card Types The types of memory cards are described below. The card type is identified by a preprinted, color-coded label. Upgrade Card. This card is used for MERLIN LEGEND Communication System software upgrades. The upgrade can be performed by the system manager using the memory card and the option on the SPM Main Menu.
Page 543 Backing Up with a Memory Card INSERT AT&T PROPRIETARY THIS MEMORY CARD CONTAINS PROPRIETARY INFORMATION OF TO BE DISCLOSED OR USED EXCEPT AT&T THAT IS NOT IN ACCORDANCE WITH APPLICABLE AGREEMENTS. COPYRIGHT 1993 AT&T AU RIGHTS RESERVED Figure D-1. PCMCIA Transition Memory Card Maintenance and Troubleshooting D-3...
Page 544: Inserting The Card
Backing Up with a Memory Card Inserting the Card To insert the card, hold the card with the AT&T logo facing up and the arrow pointing toward the slot. See Figure D–2 for the proper way to insert the memory card into the slot on the processor module. PROCESSOR MODULE Code...
Page 545: Memory Card Formatting
Backing Up with a Memory Card Memory Card Formatting The memory card may have to be formatted before you begin any manual or automatic backup procedures. This section details the screens and messages that appear during the format procedure. CAUTION: Formatting overwrites previous data on the memory card.
Page 546 Backing Up with a Memory Card may need to be formatted if it is intended for use as a 3. A memory card translation card but is currently blank, or contains data other than backup files for the system. Format Warning Format Memory Card: All data on card will be DELETED.
Page 547 Backing Up with a Memory Card Backup Use this procedure to make a copy of your customized system data. You should create a backup at least three times during system installation (so that programmed information is not lost), and once after each system upgrade, service technician visit, or major system reconfiguration.
Page 548 Backing Up with a Memory Card Additional Information Console Display/Instructions 2 Select the System menu. System Programming: > Make a selection System Extensions SysRenumber Options Operator Tables LinesTrunks AuxEquip Exit NightSrvce (F1) Select Back/Restore. System: Make a selection Restart MaintenBusy Date SProg Port Time...
Page 549 Backing Up with a Memory Card Console Display/Instructions Additional Information PC 5 Select the backup filename. Memory Card Backup: If you select AUTO.BACK1 Make a selection go to Step 8. You AUTOBACK2 BACK1. ***** AUTO.BACK1 cannot rename either of these BACK2.
Page 550 Backing Up with a Memory Card Console Display/Instructions Additional Information PC 8 Respond to the prompt. Backup filename: filename = file selected in Step 5 or entered in Step 6 Do you want to continue? Select to abort the backup. (F2) Go to Step 11.
Page 551: Automatic Backup
Backing Up with a Memory Card Automatic Backup If an automatic backup fails for any reason, except when the failure results from the memory card being write-protected, the automatic backup feature is turned off. Follow the procedure below to reprogram automatic backup. Summary: Automatic Backup Programmable...
Page 552 Backing Up with a Memory Card Procedure: Automatic Backup Additional Information PC Console Display/Instructions Insert the memory card into the PCMCIA interface slot on the processor module. Select the System menu. System Programming: > Make a selection System Extensions SysRenumber Options Operator Tables LinesTrunks...
Page 553 Backing Up with a Memory Card Console Display/Instructions Additional Information PC 5 Make a selection. Auto MemCard Backup: Select one Daily Weekly Select Off, (F1) Daily, (F2) Weekly Exit Enter (F3) 6 Save your entry. Select Enter. (F10) If you selected you have finished this procedure.
Page 554 Backing Up with a Memory Card Daily Backup Procedure Additional Information Console Display/Instructions 1 Erase the current daily backup time (xxxx). Daily MemCard Backup: Enter hour (00-23) and minutes (CID-57) HHMM xxxx Backspace (Alt) + (P) Drop. Enter Press Exit Enter the time when you want the automatic backup to run everyday (hh= 00 to 23, mm= 00 to 59).
Page 555 Backing Up with a Memory Card Weekly Backup Procedure Additional Information PC Console Display/Instructions Erase the current weekly backup day and time (xxxxx). Weekly MemCard Backup: Enter day (O-6) hr (00-23) and min (00-59) DHHMM xxxxx Backspace (Alt) + (P) Drop.
Page 556 Backing Up with a Memory Card NOTE: The screens shown in this section are from the manual backup procedure; however, the screens that may appear in both the manual and automatic backup procedures are similar. The screens in both procedures differ only in the appearance of the first line.
Page 557 Backing Up with a Memory Card The memory card is not inserted or is inserted while a backup incorrectly is in progress. The backup file that was being created is deleted and the backup is aborted. You must reinsert the memory card and repeat the backup procedure.
Page 558 Backing Up with a Memory Card CAUTION: The memory card may be write-protected to avoid the accidental erasure of the backup files. Make certain this is not the case before you change the write-protect tab. Card Failure Memory Card Backup: Backup Failure Try a different file or a new Memory Card.
Page 559 Backing Up with a Memory Card The Inspect feature (Inspct or [PgDn]) is available to view the attributes of the backup files on the memory card prior to initiating the restore procedure. The attributes included on the Inspect screen are the filename, the time and day of the file backup/update, the location of the system programming port, and information about the system software release from which the backup was made.
Page 560 Backing Up with a Memory Card Procedure: Restore Console Display/Instructions Additional Information PC 1 Insert the memory card into the PCMCIA interface slot on the processor module. Select the System menu. System Programming: > Make a selection Extensions System SysRenumber Options Operator Tables LinesTrunks...
Page 561 Backing Up with a Memory Card Console Display/Instructions Additional Information PC 5 Select the restore file. Memory Card Restore: mmdd = month and day of backup Select one AUTO.BACK1 BACK1.mmdd BACK2. mmdd AUTO.BACK2 BACK3. mndd Press the button or function key Exit next to your selection.
Page 562: Restore Messages
Backing Up with a Memory Card Console Display/Instructions Additional Information PC 9 Observe the restore file validation screen. Restore n: n = filename selected in Step 5 Restore Successfully Completed. System is Restarting. The session is finished, and the Please Wait. system restarts.
Page 563 Backing Up with a Memory Card Card Removed after Confirmation Memory Card Restore RESTORE IS CANCELED. System is DOWN. The memory card was removed from the processor slot while the restore was in progress. The restore is aborted and the system performs a System Erase (frigid start).
Page 564 Backing Up with a Memory Card Release Mismatch Restore n: n = filename selected File is Not Compatible X.Y = release number for Release X.Y Restore Canceled. Conversion Required. Exit This screen only appears if you are upgrading from Release 3.0 or higher and the releases are not compatible.
Page 565 Backing Up with a Memory Card If the restore fails because the card is damaged, the system performs a System Erase (frigid start). Repeat the restore procedure using a different file and/or memory card. Wrong Type of Card Memory Card Restore: Inserted Memory Card is not the correct type.
Page 566 Backing Up with a Memory Card Strap in Place for Key Mode but Mode is Set to Hybrid n = filename selected Restore n: Restore Failure RESTORE IS CANCELED. Restore File Mode is Hybrid/PBX. Control Unit strap in place for KEY. Exit CAUTION: This procedure should be performed only by qualified service...
Page 567 Modifying a Release 2.1 or Earlier Processor for Key Mode Release 2.1 and Earlier CAUTION: This procedure must be performed for KF registration with the FCC. This procedure prevents the system from being programmed as a Hybrid-PBX system. Do this only if the system is programmed for Key mode and GS trunks are not indicated on Form 2c, System Numbering: Line/Trunk Jacks.
Page 568 Modifying a Release 2.1 or Earlier Processor for Key Mode HDR4 SHUNT HDR3 Do not touch HDR3 Figure E–1. Modifying the Processor for Key Mode CAUTION: processor board; the Do not touch the HDR3 header on the header is exposed when the feature module is not installed in the processor.
Page 569 Modifying a Release 2.1 or Earlier Processor for Key Mode On the exposed portion of the processor board, find the header marked HDR4; it is in the upper-left area. A shunt is attached to one of the pins on the HDR4 header. Remove the shunt from the single header pin;...
Page 570: Installing The Control Unit
Modifying a Release 2.1 or Earlier Processor for Key Mode Right Hand Front Panel Side Panel Line Up With Inside Semicircle on of Front PaneI Slide Tongues in and Push Front Panel Up Figure E-2. Installing the Control Unit Housing E-4 Maintenance and Troubleshooting...
Page 571 Glossary 7500B data module See lSDN 7500B Data Module. 7500B data station A type of data station that includes an ISDN 7500B Data Module as its DCE and connects to an MLX extension jack for digital transmission of data over a DS1 facility. It may also include an MLX telephone for simultaneous voice and data.
Page 572 Glossary (alternate mark inversion) Line coding format in which a binary one is represented by a positive or negative pulse, a binary zero is represented by no line signal, and subsequent binary ones must alternate in polarity; otherwise, a bipolar violation occurs. AMI is used in the DS1 interface.
Page 573 Glossary asynchronous data A method of transmitting a short bitstream of digital data, transmission such as printable characters represented by a 7- or 8- bit ASCII code. Each string of data bits is preceded by a start bit and followed by a stop bit, permitting data to be transmitted at irregular intervals.
Page 574 Glossary Tie trunk on which incoming calls are routed to an operator automatic-start tie trunk or other designated destination without a start signal, as soon as the trunk is seized; the destination is specified during programming. Also called “automatic ringdown” or “auto-in”...
Page 575 Glossary Bearer-channel See B-channel. Behind Switch mode One of three modes of system operation, in which the control unit is connected to (behind) another telephone switching system, such as Centrex or DEFINITY, which provides features and services to telephone users. See also Hybrid/PBX mode and Key mode.
Page 576 Glossary board assignment SPM procedure for assigning line/trunk and extension modules to slots on the control unit. System programming procedure for renumbering board renumbering line/trunk and extension modules that have already been assigned to specific slots on the control unit. Multiconductor electrical path used to transfer information over a common connection from any of several sources to any of several destinations.
Page 577 Glossary campus cable Cable that runs between buildings connected to the same communications system. (Call Accounting System) DOS- or UNIX System-based application that monitors and manages telecommunications costs. (Call Accounting Terminal) Stand-alone unit with a built-in microprocessor and data buffer that provides simple call accounting at a low cost.
Page 578 Glossary clock Operation of digital facilities from a common clock. synchronization (Call Management System) DOS-based application that simulates the actions of a system operator by answering and distributing calls. Also produces reports for call analysis. (central office) Location of telephone switching equipment that provides local telephone service and access to toll facilities for long-distance calling.
Page 579 Glossary CONVERSANT Voice response application that automatically answers and routes calls and executes telephone transactions. conversion resource See modem pool. (class of restriction) Various types of restrictions that can be assigned to remote access trunks or barrier codes. These restrictions consist of calling restrictions, ARS Facility Restriction Levels (FRLs), Allowed Lists, Disallowed Lists, and pool dial out restrictions.
Page 580 Glossary data module See ISDN 7500B Data Module. data rate See bps. data station Special type of extension where data communications take place; includes DTE and DCE; sometimes a telephone is also part of a data station. An input/output (I/O) device (often a personal computer) data terminal that can be connected to the control unit via an interface.
Page 581 Glossary Dialed Number See DNIS. identification Service dial-out code Digit (usually a or digits dialed by telephone users to get an outside line. Numbering scheme for system extensions, lines, and dial plan trunks. dial-repeating tie Tie trunk on which the originating end of the tie trunk trunk transmits an off-hook signal to the receiving end and waits for the receiving end to send an off-hook signal followed...
Page 582 Glossary Mode of transmission in which the information to be digital transmission transmitted is first converted to digital form and then transmitted as a serial stream of pulses. See also analog transmission. (dual in-line package) Switch on a 400EM module used to DIP switch select the signaling format for tie-line transmission.
Page 583 Glossary (Digital Signal Level 1) Bit -oriented signaling interface that multiplexes twenty-four 64-kbps channels into a single 1.544-Mbps stream. (Direct Station Selector) 60-button adjunct that enhances the call-handling capabilities of an MLX-20L or MLX-28D telephone used as an operator console. (data terminal equipment) Equipment that makes the endpoints in a connection over a data connection, for example, a data terminal, personal computer, host...
Page 584 Glossary (extended superframe format) Framing format consisting of individual frames of 24 eight- bit slots and one signal bit (193 bits) in a 24-frame extended superframe. See also D4 framing format. (Electronic Switching System) Class of central office (CO) switching systems developed by AT&T in which the control functions are performed principally by electronic data processors operating under the direction of a stored program.
Page 585 Glossary Facility Restriction See FRL. Level factory setting Default state of a device or feature when an optional setting is not programmed by the user or system manager. (facsimile) Scanning and transmission of a graphic image over a telecommunications facility, or the resulting reproduced image, or the machine that does the scanning and transmitting.
Page 586 Glossary One of several segments of an analog or digital signal that frame has a repetitive characteristic. For example, a DS1 frame consists of a framing bit and 24 bytes, which equals 193 bits. Pattern of frames used in transmissions. framing format See ring generator.
Page 587 Glossary Hands Free Answer on See HFAI. Intercom hands-free unit See HFU. headset Lightweight earpiece, microphone, and adapter used for hands-free telephone operation. HFAI (Hands Free Answer on Intercom) Feature that allows a user to answer a voice-announced call. (Hands-Free Unit) Unit for older analog multiline telephones that allows users to make and receive calls on the speakerphone without using the handset.
Page 588 Glossary immediate-start tie Tie trunk on which no start signal is necessary; dialing can trunk begin immediately after the trunk is seized. in-band signaling See robbed-bit signaling. inside dial tone A tone users hear when they are off-hook on an SA or ICOM button.
Page 589 Glossary ISDN (Integrated Services Digital Network) Public or private network that provides end-to-end digital connectivity for all services to which users have access by a limited set of standard multipurpose user and network interfaces; provides digital circuit-switched or packet-switched connections within the network and to other networks for national and international digital connectivity.
Page 590 Glossary (local area network) Arrangement of interconnected personal computers or terminals, sometimes accessing a host computer, sometimes sharing resources like files and printers. (Listed Directory Number) (light-emitting diode) Semiconductor device that produces light when voltage is applied; light on a telephone. Connection between extensions within the line communications system or loop-start communications...
Page 591 Glossary local host computer A method for connecting an extension jack to an on-site access computer for data-only calls through a modem or data module. local loop See access line. logical ID Unique numeric identifier for each extension and line/trunk jack in the system control unit.
Page 592 Glossary (Multi-Function Module) Adapter that has a tip/ring mode for answering machines, modems, fax machines, and tip/ring alerts, and an SAA mode for -48 VDC alerts. Installed inside an MLX telephone, and is used to connect optional equipment to the telephone. The optional equipment and the telephone operate simultaneously and independently.
Page 593 Glossary Pair, or group of pairs, of modems and data modules with modem pool interconnected RS-232 interfaces that converts digital signals to analog, or analog signals to digital, thereby allowing users with 7500B data stations to communicate with users who have analog modem data stations. module Circuit pack in the control unit that provides the physical jacks for connection of telephones and/or outside...
Page 594 Glossary network Configuration of communications devices and software connected for information interchange. network interface Hardware, software, or both that links two systems in an interconnected group of systems, for example, between the local telephone company and a PBX. Telephone is said to be off-hook when the user has lifted off-hook the handset, pressed the Speaker button to turn on the speakerphone, or used a headset to connect to the...
Page 595 Glossary out-of-band Signaling that uses the same path as voice-frequency signaling transmission and in which the signaling is outside the band used for voice frequencies. parity The addition of a bit to a bit string so that the total number of ones is odd or even, used to detect and correct transmission errors.
Page 596 Glossary (Power Failure Transfer) Feature that provides continuity of telephone service during a commercial power failure by switching some of the system’s trunk connections to telephones connected to specially designated extension jacks. pool In Hybrid/PBX mode, a group of outside trunks that users can access with a Pool button or by dialing an access code on an SA button.
Page 597 Glossary processor module Module in the second slot of the control unit (Slot 0, to the right of the power supply module). Includes the software and memory that runs the system. programming port Reassignment of the system programming jack position to reassignment any of the first five extension jacks on the first MLX module in the control unit.
Page 598 Glossary Remote Access System feature that allows an outside caller to gain access to the system, almost as if at a system extension. Procedure whereby saved and archived system restore programming is reinstated on the system, from a floppy disk or memory card. See also backup. ring generator Circuit pack added to the power supply that generates a high-voltage, 20–30 Hz signal to ring a telephone.
Page 599 Glossary simplex signaling Transmission of signals in one direction only across a telecommunications channel. signaling Sending of control and status information between devices to set up, maintain, or cease a connection such as a telephone call. Industry-standard touch-tone or rotary-dial telephone that single-line telephone handles only one call at a time and is connected to the system via an extension jack on a basic 012 or 008 OPT...
Page 600 Glossary See SAA. Supplemental Alert Adapter switchhook flash Momentary (320 ms to 1 second) on-hook signal used as a control signal. May be directed either to the control unit or to a host switch outside the system. Also called "Recall” or “timed flash.”...
Page 601 Glossary (time-division multiplex) Process where the transmission channel is divided into time slots. telephone power Equipment that provides power to an individual telephone. supply unit tie trunk Private trunk directly connecting two telephone switches. See also automatic-start tie trunk, delay-dial-start tie trunk, immediate-start tie trunk, and wink-start tie trunk.
Page 602 Glossary (uninterruptible power supply) Device that connects to the system to provide 117 VAC to the equipment when the commercial power source fails. Alternating-current voltage. Direct-current voltage. (voice messaging interface) An enhanced tip/ring port. voice-band channel A transmission channel. generally in the 300-3400-Hz frequency band.
Page 603 Index Auxiliary power unit, replacing, 4-8 - 4-9 012 module apparatus codes, 4-5 PEC codes, 4-5 B-channel Ioopback test 100D module error messages, table, 4-57 automatic tests, 4-80 - 4-81 procedure, 4-55 - 4-56 clock status results, 4-56 - 4-57 procedure, 4-84 - 4-85 summary, 4-54 summary, 4-83...
Page 604 Index Error messages Cold start, 1-21 board memory programming failure, Control unit 4-70 housing flash ROM won’t erase, 4-69 installing Release 2.0 or earlier, incorrect slot, 4-70 5-34 - 5-36 memory card, 4-66 - 4-69 installing Release 2.1 or later, memory erase, 4-69 5-30 - 5-33 Error threshholds, 2-2...
Page 605 Index Maintenance-busy causes, 5-6 overview, 5-4 - 5-5 Incoming trunk, 5-4 status Interlocking post, 4-3 - 4-4 extension, 5-9 - 5-11 Internal loopback test trunk, 5-7 - 5-9 errors, 4-49 Memory card interpreting results, 4-49 inserting, 4-20 - 4-21 procedure, 4-46 - 4-48 messages, 4-26 - 4-28 summary, 4-45 - 4-46 MLX telephone...
Page 606 Index summary, 4-20 Restart, 1-20 -1-22 Restore extension, 5-18 - 5-20 Outgoing trunk, 5-3 procedure, 4-43 - 4-45 summary, 4-43 trunk, 5-16 - 5-17 Ring failure, 3-8 PC (personal computer), setting up, 1-5 Ring generator, 4-4 - 4-7 PCMCIA interface slot, 4-62 RS-232 port, resetting, 5-20 - 5-22 PEC codes, 4-5 Peek, 4-12 - 4-14...
Page 607 Index Trunk busy-out, 5-11 - 5-13 incoming, 5-4 Telephone problems maintenance-busy status, 5-7 - 5-9 analog multiline, 3-4 manual correction of problems, 5-2 - Call Forwarding, 3-5 - 3-6 determining cause, 1-23 outgoing, 5-3 general, 3-1 - 3-4 restoring, 5-16 - 5-17 MLX, 3-6 - 3-8 symptom list, 5-2 single line, 3-5...
Page 608 Index IN-6 Maintenance and Troubleshooting...

AT&T MERLIN LEGEND Release 3.0 Installation Manual

Table of Contents

Introduction

Installing the Control Unit

Installing Telephones and Adjuncts

Connecting the Control Unit to the Network Interface

Installing the PC, CAT, or Printer

Connecting Data Equipment

Initializing and Testing the System

Installing Applications

Table of Contents

Central Office Problems

1 Introduction

2 Error Logs, Access Logs, and System Inventory

3 Telephone Problems

4 Control Unit Problems

Quick Links

Chapters

Related Manuals for AT&T MERLIN LEGEND Release 3.0

Summary of Contents for AT&T MERLIN LEGEND Release 3.0
