DS1 Facilities
Console Display/Instructions
Select Loop-Start/Ground-Start/DS1.
2
Lines and Trunks:
Make a selection
LS/GS/DS1
TIE Lines copy
RemoteAccss
TT/LS Disc
DID Pools
Toll Type
Exit
3 Enter the slot number
( = 1 to 17 ).
nn
Loop/Ground/DS1:
Enter slot number(l-17)
Backspace
Exit Enter
4
Save your entry.
Select Enter.
Select Channel Unit.
5
DS1 Slot xx:
Make a selection
Type Line Comp
FrameFormat Clock Sync
Suppression ChannelUnit
Signaling
Exit
6 Select the type of channel unit.
ChannelUnit DS1 Slot xx:
select one
–
Foreign Exchange
–
Special Access
Exit Enter
7 Save your entry.
Select Enter.
8 Returnt to the System Programming menu.
Select Exit two times.
4-76
Programming Procedures
Additional Information
the control unit that contains the 100D module
in
Dial or type [ nn ].
xx =slot number entered in Step 3
xx = slot number entered in Step 3
Select Foreign Exchanger
Special Access.
PC
[ F1 ]
←
[ F10 ]
[ F8 ]
[ F1 ]
[ F2 ]
[ F10 ]
[ F5 ] [ F5 ]
