AT&T MERLIN LEGEND Release 3.0 System Programming Manual page 645

Data Features
Procedure: Analog Multiline Telephones at Data
Stations
Console Display/Instructions
1 G to the second screen of the System Programming menu.
O
System Programming: >
Make a selection
system Extension
SysRenumber Options
Tables
Operator
LinesTrunks AuxEquip
NightSrvce
Exit
2 Select Data.
System Programming:
hake a selection
Labeling Language
Data
Print
Cntr-Prg
Exit
3 Select Voice/Data.
Data:
Make a selection
Voice/Data
4 Enter the voice (odd-numbered) extension number of the pair ( nnnn ).
Data VoicelData
Enter voice/data pair
Delete
Backspace
Exit Enter
Assign or remove the voice/data pair.
5
Select Enter or
Delete.
6 Return to the System Programming menu.
Select Exit.
Additional Information
Press More.
The system automatically assigns the
data (even-numbered) extension. Use the
Inspect feature (Inspct or [ PgDn ] to view the
pair.
SP: "Entering an Extension"
You may continue to assign or remove
additional voice/data pairs by repeating
Steps 4 and 5.
Programming Procedures
PC
[ PgUp ]
[ F2 ]
[ F1 ]
←
[ F10 ]
[ F8 ]
[ F5 ]
4–295
