Lines and Trunks
Console Display/Instructions
4
Select the outward trunk dial line(s).
OutTrunk Dial:
Enter Trunks w/TouchTone
Lines 01-20
Entry Mode
–
Lines 21-40
–
Lines 41-6O
–
Lines 61-80
–
Exit
Single Line Procedure
1
Specify entry mode.
Select Entry Mode.
2
Enter the number of the line/trunk with touch-tone dialing.
OutTrunk Dial:
Enter Trunks w/TouchTone
Delete
Backspace
Exit
Enter
3
Assign or remove touch tone signaling from the line/trunk.
Select Enter or
Delete.
4
Return to the System Programming menu.
Select Exit three times.
Block Procedure
1
Specify the block of 20 lines associated with 20 buttons on the system
programming console.
Select Lines 01-20
Lines 21-40
Lines 41-60
Lines 61-80.
Additional Information
For a single line, go to
Single Line Procedure.
–
For a block of lines, go to
Block Procedure.
You may continue to assign or remove
touch tone signaling from additional
lines/trunks by repeating Steps 2 and 3.
Programming Procedures
PC
[ F6 ]
←
[ F10 ]
[ F8 ]
[ F5 ] [ F5 ] [ F5 ]
[ F1 ]
[ F2 ]
[ F3 ]
[ F4 ]
4–29
