DID Trunks
Console Display/Instructions
9 Save your entry.
Select Enter.
10 Return to the System Programming menu.
Select Exit two times.
Signaling
Use this procedure to specify whether the type of dialing signal from the Iota
telephone company is touch-tone or rotary. Touch-tone dial mode cannot be
programmed for immediate-start DID trunks.
Touch-tone single-line telephone users cannot make calls by using individual
trunks programmed for rotary operation. The touch-tone signals generated from
the telephone while dialing are transmitted to the central office at the same time
the rotary signals are sent to the system. The central office receives both signals
and cannot process the call.
Summary: Signaling
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
Additional Information
System manager
Hybrid/PBX
Not Required
Form 3d, Incoming Trunks: DID
Rotary
Rotary, Touch-tone
No
No
LinesTrunks → DID → Signaling → Dial trunk block no. →
Enter → Rotary or TouchTone → Enter → Exit → Exit
[ F4 ] → [ F4 ] → [ F8 ] → Type trunk block no. → [ F10 ] → [ F1 ] or [ F2 ]
→ [ F10 ] → [ F5 ] → [ F5 ]
Programming Procedures
PC
[ F10 ]
[ F5 ] [ F5 ]
4–107
