6

Front Panel Operation

This Chapter provides an overview of front panel operation for the ADF Series® AC power
sources. For remote control operation, refer to Section 8 "Remote Control Programming" of
this manual for an overview of available programming commands.

6.1 Front Panel Layout

The front panel layout is shown in Figure 6-1 below. The number of buttons is kept to a
minimum to ensure simple front panel operation for casual and experienced users alike. The
shuttle knob is used to slew parameter values and move through menus to make selections.
A large backlit LCD display is located in the center. Most user controls are located directly to
the right of the display. The power ON/OFF circuit breaker is located in the lower left corner
of the front panel.

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Figure 6-1: ADF Series® Front Panel View
