4.13.2 Technical Specifications 400V Range

AC OUTPUT
Voltage
AC Only Range
Programming Resolution
Constant Power Range
External Voltage Sense
Frequency
Programming Resolution
Current 2
Current Overload
Note 1: FREQUENCY PROGRAM RESOLUTION FOR EXPORT MODELS (-4FE, -2FE):
Per U.S.A. Bureau of Industry and Security, ECCN 3A225, frequency control is limited to no better than 0.2% at
frequencies of 600 Hz. or more for unrestricted export products. To meet that requirement, frequency
programming in all ADF-xFE models has three resolution ranges, which round the frequency to the nearest
increment, as defined in the table below.
Frequency Resolution for Export Models
Range
15.00 - 99.99 Hz
100-599.9 Hz
600 - 999 Hz
1000 - 1200 Hz
Note 2: Refer to AC Mode Voltage / Current rating charts Figure 4-14 and Error! Reference source not found. on
following pages.
MODEL Phase
Mode
1150ADFT 1 Phase
3150ADFT 3 Phase
1300ADFT 1 Phase
3300ADFT
3 Phase
1450ADFT 1 Phase
3450ADFT 3 Phase
3600ADFT
3 Phase

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Accuracy
Range
1
Accuracy
Range Available RMS Current per phase is scaled by transformer ratio. E.g. for
3150ADF, max current at 400Vac L-N is (41.7 * ¾) = 31.27Arms in 3 Phase mode
Available 30% Current overload for up to 2.0 seconds when enabled.
Resolution
0.01 Hz
0.1 Hz
2.0 Hz
5.0 Hz
Rated Power T Voltage Range
Vac L-N
15 kVA
15 kVA
30 kVA
30 kVA
0-400 V
45 kVA
45 kVA
60 kVA
ADF SERIES® OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
0 - 400 V L-N rms / 0 - 692V L-L rms
0.01 V
± (0.25% + 0.25* f (kHz)) F.S.
From 40% to 100% of Voltage Range:
160Vac L-N to 400Vac L-N
Automatically scaled for 400Vac Range
45.00 – 1000.0 Hz
For models with –F Option:
• Linear voltage derating from 45Hz to 15Hz
• Linear current derating from 1000Hz to 1200Hz.
0.01 Hz
± 0.01%
Max. AC Current Max. AC Current
3 Phase Mode 1 Phase Mode
n/a 93.8 Arms
31.3 Arms
n/a 187.6 Arms
62.5 Arms
n/a
93.8 Arms
125.0 Arms
Form Factor
2x 4U Chassis,
Rackmount
n/a
Fully wired 28U
n/a
Cabinet power
281 Arms
system
n/a
n/a Fully wired 36U
Cabinet power
system
