6.8.11 FIRMWARE UPDATE Screen

Firmware updates may be distributed via different media such as SD-Card, USB memory
stick or on-line through Pacific's FTP site. The FIRMWARE UPDATE screen provides the
means for the end user to perform a firmware update.
The following soft keys are available from the FIRMWARE UPDATE screen:
SOFT KEY
Mount Drive (SK1)
-
-
From FTP (SK4)
Cancel (SK5)

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Figure 6-27: FIRMWARE UPDATE Screen
Description
Mount media that contains new firmware revision.
Install latest firmware from Pacific Power Sources' FTP server.
Exit firmware update screen

Table 6-24: Available FIRMWARE UPDATE screen soft keys
