4.3 AC Output Mode

AC OUTPUT
Voltage
Extended Voltage Range
Programming Resolution
Harmonic Distortion
(Full, Resistive Load)
Output Noise (DC – 300 kHz)
Load Regulation
Line Regulation
External Voltage Sense
Voltage Slew Rate
Frequency
Extended Frequency Range
Programming Resolution
Current Limit
Current Overload
Programming Resolution
Phase Angles (3 Phase Models)
Phase Offsets
Note 1: Extended operation to 333V L-N / 576V L-L supported in Three and Split Phase mode up to 3.3kVA per phase
for frequency range 45Hz ~ 800Hz with Option F. Some specifications exceptions apply. Requires Option V.
Note 2: Refer to Figure 4-1, "Output Voltage distortion into full R Load as a function of Frequency" on next page.

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
AC Range
1
(Option V)
Accuracy
Waveform
DC Offset
2 (Vthd) < 0.5% 15Hz – 400Hz, < 1.0% 400Hz-1000Hz, < 1.5% > 1000Hz
Isolation
Range
(Option F)
3
Accuracy
Range 4 See model tables, Figure 4-3 and Figure 4-4. Values shown are supported for
Available 30% Current overload for up to 2.0 seconds when enabled. See
Crest Factor
Accuracy
Modes
5
Accuracy
ADF SERIES® OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
0 - 300 V L-N rms / 0 - 520V L-L rms
0 - 333 V L-N rms / 0 – 576 V L-L rms, see Note 1
0.01 V
± 0.25% F.S.
Sine wave
< 20 mV
See V THD Chart at bottom of page
< 150 mV rms
± 0.02% (CSC Mode on)
± 0.1% for 10% Line Change
External Sense, max. voltage drop 5% FS.
At least 1.0 V/us
550 Vac
45.00 – 500.0 Hz
15.00 – 1200.0 Hz
0.01 Hz
± 0.01%
any period of time.
Figure 4-2.
2.5:1 @ 41.67 to 6.3:1 @ 16.67
(104Apk / phase for 3150ADF, 312Apk for 1150ADF)
0.01 A rms
± 0.5% F.S.
Constant Current Mode or Output Trip
A = 0°, B = 240°, C = 120
± 0.35°
Page 25 of 349
