6.8.5.2 LOCAL INTERFACE 2 OF 2
Several aspects of front panel operation can be configured by the user from this screen.
These setting relate primarily to visual and audible user interface aspects:
1. LCD brightness
2. Keyboard Backlight
3. Sound Levels
Parameters available to set are as follows:
LCD brightness
Keypad Backlight brightness
Sound Volume
Enable keypad sound
The following soft keys are available from the LOCAL INTERFACE setup screen:
SOFT KEY
Local Inter. Page 1.
(SK1)
-
-
-
Back (SK5)

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Adjusts the LCD display backlight brightness.
Range is 0-9.
Adjusts the keyboard backlight brightness.
Range is 0-9.
Adjusts the loudness of the keyboard and
message beeps.
Enables or Disables audible beeps when
operating the keyboard.
Description
Toggle to LOCAL INTERFACE 1 OF 2 screen
Returns to previous screen

Table 6-15: Available USER INTERFACE screen soft keys
