7.3.4

I/O Signal Table by Function

Pin assignments in order of pin number are shown in the table below.
Pin # Name
10
AI1
11 AI2
12 AI3
13 AI4
22
AO1
23 AO2
24
AO3
25 AO4
3
DI1
4 DI2
5 DI3
20 DO1
21 DO2
18 FS
16 DO3
/RC1
17 DO4
/RC2
6
RI
8 Sync In
19 Sync Out
7 TT
15 12V
2 GND
9 GND
1
RxD
14
TxD

Table 7-2: Auxiliary I/O DB25 Connector Pin numbers and Signals by Signal Name


Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Primary Function
Analog Input – Volt RMS Phase A
Analog Input – Volt RMS Phase B
Analog Input – Volt RMS Phase C
Analog Input – Current Limit RMS all
phases
Analog output #1 – Volt RMS
Measurements Phase A
Analog output #2 – Volt RMS
Measurements Phase B
Analog output #3 – Volt RMS
Measurements Phase C
Analog output #4 – Total Power (all
phases combined)
General Purpose Digital Input #1
General Purpose Digital Input #2
General Purpose Digital Input #3
General Purpose Digital Output #1
General Purpose Digital Output #2
Trigger Output / Function Strobe
Relay Control #1 – FORM
Relay Control #2 - TRANSFORMER
Remote Inhibit
Phase Sync Input
Phase Sync Output
Transient Trigger Input
Output, 12Vdc
Chassis Ground
Chassis Ground
RS232 Receive Data (Rx)
RS232 Transmit Data (Tx)
ADF SERIES™ OPERATION MANUAL
Rear Panel, Connectors and Protection
SECTION 7:
Alternate Use / Comment
Any set point
Any set point
Any set point
Any set point
Any other measurement
Any other measurement
Any other measurement
Any other measurement
Programmable
Programmable
Programmable
Programmable
Programmable
Programmable, Open
Collector, Current protected
Programmable, Open
Collector, Current protected
0.5 A max, current protected
Type Direction
Analog Input
Analog Input
Analog Input
Analog Input
Analog Output
Analog Output
Analog Output
Analog Output
Digital Input
Digital Input
Digital Input
Digital Output
Digital Output
Digital Output
Digital Output
Digital Output
Digital Input
Digital Input
Digital Output
Digital Input
Power Output
Ground n/a
Ground n/a
RS232
Input
RS232
Output
