4.4 DC Output Mode (Requires Option D)

DC OUTPUT
Voltage
Programming Resolution
Noise & Ripple
Load Regulation
Line Regulation
External Voltage Sense
Voltage Slew Rate
Current Limit
Programming Resolution
MODEL Phase
Mode
1150ADF-xGD 1 Phase
3150ADF- xGD 3 Phase
1300ADF- xGD
1 Phase
3300ADF- xGD 3 Phase
1450ADF- xGD 1 Phase
3450ADF- xGD 3 Phase
3600ADF- xGD 3 Phase

4.5 Protection Modes

PROTECTION
Protection Modes
OVP Range
AC Input Voltage

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Range
Accuracy
Isolation
Accuracy
Modes
Rated Power DC Voltage
Range
15 kVA
15 kVA
30 kVA
30 kVA
0 ~ ±425 Vdc
45 kVA
45 kVA
60 kVA
ADF SERIES® OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
0 – 425 Vdc
0.01 V
± 0.25% F.S.
< 150 mV rms
± 0.02%
± 0.1% for 10% Line Change
External Sense, max. voltage drop 5% FS.
At least 3.0 V/us (DC Mode)
750 Vdc
0.01 Adc
± 0.5 Adc
Constant Current Mode or Output Trip
Max. DC Current Max. DC Current
3 Phase Mode 1 Phase Mode
n/a 62.5 Adc
21.0 Adc
n/a 125.0 Adc
41.7 Adc
n/a 187.5 Adc
62.5 Adc
83.5 Adc
Over Current fold-back or trip
Progr. Peak Current Limit
Power fold-back or trip
Apparent Power fold-back or trip
Over Voltage trip
Over Temperature
0 - 105% Vmax
Over and Under Voltage
Form Factor
2x 4U Chassis,
Rackmount
n/a
Fully wired 28U
n/a
Cabinet power
system
n/a
n/a Fully wired 36U
Cabinet power
system
