Command Syntax
Description
Parameters
Steady State list
Parameter Format
Example
Query Format
Description
Returned Data Format
Query Example
Example Program String:
FORM,3,COUPL,DIRECT,VOLT:MODE,0,CONFIG,1,RANG,1,FREQ,395.000,VOLT1,115.000,VOLT2,115.000,VOL
T3,115.000,VOLT:ALC:STAT,1,CURR:OV,0,CURR:LIM1,41.670,CURR:LIM2,41.670,CURR:LIM3,41.670,IPROT:ST
AT,0,CURR:PROT:LEV,40.000,IPEAK:LIM,104.000,PHAS2,120.000,PHAS3,240.000,WAVEFORM1,1,WAVEFOR
M2,1,WAVEFORM3,1,VOLT:DC1,0.000,VOLT:DC2,0.000,VOLT:DC3,0.000,POW:LIM1,5.000,POW:LIM2,5.000,
POW:LIM3,5.000,KVA:LIM1,5.000,KVA:LIM2,5.000,KVA:LIM3,5.000,PPROT:STAT,0,POW:PROT:LEV,5.000,KV
A:PROT:LEV,5.000,PROT:TDELAY,1,FREQ:SLEW,5.000,VOLT:SLEW,10.000,VOLT:DC:SLEW,10.000,UPDATEPH,
0.000,RAMP,1.0000,VPEAK:MARG,100.000,EVENTS,0,AUTORMS,1,NSEGS,3,SEG,3,FSEG,395.00,VSEG1,115.0
0,VSEG2,115.00,VSEG3,115.00,VDCSEG1,0.00,VDCSEG2,0.00,VDCSEG3,0.00,PSEG2,120.00,PSEG3,240.00,WF
SEG1,1,WFSEG2,1,WFSEG3,1,TSEG,2.0000,LAST

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
PROGram[:SELected]:DEFine [<nr1>,] [<cr>,] <cr>
This command programs all values stored in the selected program
number. Both steady-state and transient segment parameter names
and values may be sent. Program parameters are defined in the
following sections.
NOTE: Only commas may separate the values, NO Carriage Returns or
Line Feeds may separate the values within a single command message.
Option: PROGRAM, NUMBER [,<cr>} or [,<nr1>]
Option: MEMORY [,<cr>] – Available are: INTERNAL | RAM | USB
Parameter list define string <cr>,<cr>,....,<cr>
FORM,<n>,
COUPLing,<s>,
XFMRRATIO,<n.nn>,
FREQuency,<n>,
VOLTage,<n>,
VOLTage1,<n>,
VOLTage2,<n>,
VOLTage3,<n>,
CURRent:LIMit,<n>,
CURRent:PROTect:LEVel,<n>
CURRent:PROTect:TOUT,<n>
PHASe2,<n>,
PHASe3,<n>,
WAVEFORM,<n>,
WAVEFORM1,<n>,
WAVEFORM2,<n>,
WAVEFORM3,<n>,
EVENTS,<n>,
AUTORMS,<n>
NSEGS, <n>
<cr>,<cr>,....,<cr>,<cr>
PROGram[:SELected]:DEFine? [<nr1>,] [<cr>,]
The Query format returns steady-state values of selected program and
segment values of most recently selected segment or multiple
segments if specified by a previous NSEGS parameter. "LAST" is
returned with segment data if the segment is the last segment in the
program.
Refer to parameter lists shown above
PROG:DEF? 6
<nr1>, <cr>,....,<cr>
ADF SERIES™ OPERATION MANUAL
Remote Control Programming
SECTION 8:
see Convention #13.
see Convention #13.
