Show Measurements in Immediate Mode When checked, entering immediate mode will
Enable variable speed shuttle knob
Set step with numeric keypad
The following soft keys are available from the LOCAL INTERFACE setup screen:
SOFT KEY
Local Inter. Page 2.
(SK1)
-
-
-
Back (SK5)

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Description
Toggle to LOCAL INTERFACE 2 OF 2 screen
Returns to previous screen

Table 6-14: Available USER INTERFACE screen soft keys

ADF SERIES™ OPERATION MANUAL
SECTION 6:
result in the Measurement screen being display
with the changing parameter showing in the
title bar. This allows monitoring of all output
measurements while slewing voltage, current of
frequency.
When selected, the speed of rotating the
shuttle knob will increase the step size of the
parameter being changed. If unchecked,
changes occur at a fixed step size (resolution).
When set, the numeric keypad can be used to
increment or decrement the step size of the
shuttle knob. Digits 9 to 1 our use to change
from largest step size (9) to smallest step size
(1) and any step size in between.
