7.4 System Interface Bus Connectors

SHOCK HAZARD: DO NOT remove safety covers from the two System Interface DVI Connectors.
RISQUE DE CHOC: NE PAS retirer les capots de sécurité des deux connecteurs d´interface DVI
The system interface bus is not user-accessible. It consists of two Digital Visual Interface
(DVI-I dual link) connectors that are covered by a protective cover. There are no user
accessible signals on the system interface bus. It is used for system configuration cabinet
systems only.

