Table 8-3: Status Byte Register (Stb) - Pacific Power Source ADF Series Operation Manual

BIT NAME
7 SOS
6 MSS/RQS
5 ESB
4 MAV
3 SQS
2 EEQ
1 BUSY
0 FAULT
Note: Setting a SERVICE REQUEST ENABLE (SRE) bit true unmasks the STATUS bit in the
STB. Bit 6 of the SRE is not applicable as the MASTER SUMMARY bit of the STB
cannot be masked. The STB, SRE, ESR and ESE registers are 8 bits each.

