4.3.2

AC Voltage and Current Output Charts

AC VOLTAGE RANGES

Figure 4-4: AC Mode Voltage/Current range, 3150ADF Model per Phase


Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual

Figure 4-3: AC Mode Voltage/Current range, 1150ADF Model

ADF SERIES® OPERATION MANUAL
SECTION 4: TECHNICAL SPECIFICATIONS
Page 28 of 349
