8.6.1.1 Steady State Output Parameter List Table
The following table details the available parameters for the steady state program
definitions.
Parameter
FORM,<n>
COUPLing,<s>
XFMRRATIO,<n.nn>
FREQuency,<n>
VOLTage,<n>
VOLTage1,<n>
VOLTage2,<n>
VOLTage3,<n>
CURRent:LIMit,<n>
CURRent:PROTect:LEVel,<n>
CURRent:PROTect:TOUT,<n>
PHASe2,120
PHASe3,240
WAVEFORM,1
WAVEFORM1,1
WAVEFORM2,1
WAVEFORM3,1
AUTORMS,<n>

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
SECTION 8:
Description
sets Output Power Form of selected program
n = <1>Single Ф, <2>Split Ф, or <3>Three Ф
sets Output coupling of selected program
s = <DIRECT> <0> or <XFMR> <1>
sets Output XFMR ratio (n.nn:1) of selected program
n.nn = <0.0100> to <5.1111>
sets Output Frequency of selected program
n = <:SOUR:FREQ:LIM:MIN> to <:SOUR:FREQ:LIM:MAX> Hz
sets Output VOLTAGE ФA,B,C of selected program
n = <0> to <300 x XFMRRATIO> Volts
sets Output VOLTAGE ФA of selected program
n = <0> to <300 x XFMRRATIO> Volts
sets Output VOLTAGE ФB of selected program
n = <0> to <300 x XFMRRATIO> Volts
sets Output VOLTAGE ФC of selected program
n = <0> to <300 x XFMRRATIO> Volts
sets Output Current Limit of selected program
n = <0> to <AMPS meter range> Amps
sets Output Current level that triggers Current Protect mode
n = <0> to <AMPS meter range> Amps
sets time that the Output Current must exceed the Current Protect
level before Current Protect disables the power source output.
n = <1> to <65535>, 1 = 100mSec.
sets Output Phase Angle B of selected program
n = 120 degrees
sets Output Phase Angle C of selected program
n = 240 degrees
sets Output Waveform ФA, ФB, ФC of selected program
n = 1
sets Output Waveform ФA of selected program
n = 1
sets Output Waveform ФB of selected program
n = 1
sets Output Waveform ФC of selected program
n = 1
program Transient Waveform Auto RMS mode (4.5.2) n = 0, use
program steady-state waveform RMS factor n = 1, calculate RMS
factor based on transient waveform
