Error Source Code
Front panel 64
Error
Front panel 65
Error
Front panel 66
Error
Front panel 67
Error
Front panel 68
Error
Front panel 69
Error
Front panel 70
Error
Front panel 71
Error
Front panel 72
Error
Front panel 73
Error
Front panel 74
Error
Front panel 75
Error
Front panel 76
Error
Front panel 77
Error
Front panel 78
Error
Front panel 79
Error
Front panel 80
Error
Front panel 84
Error
Front panel 85
Error

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
ADF Series Power Source Operation Manual
Category Error Message
Error Unexpected reset.
Error Front panel is in passive
mode.
Error Invalid host name.
Error DC voltage set point
cannot change due to
waveform saturation.
Error AC voltage set point
cannot change due to
waveform saturation.
Error Maximum user limit is
lower than set point.
Error Minimum user limit is
higher than set point.
Error Set point reduced due to
low range.
Error Minimum limit is higher
than maximum.
Error Maximum limit is lower
than minimum.
Error Waveform description is
not available.
Error IP address conflict. May
be duplicated.
Error Invalid filename.
Error External memory storage
is not available.
Error Data logger rate not
allowed.
Event Data logger is running
Error Data logger execution
error.
Event Unable to change form
while output is enabled.
Error Unable to clear one or
more fault.
ADF SERIES™ OPERATION MANUAL
Service and Maintenance
SECTION 13:
Possible Cause
Inverter controllers were
reset
Passive Mode. Front
panel is most likely an
auxiliary unit
Host name requested is
invalid
Setting conflict.
Waveform data and DC
setting or in conflict
Setting conflict.
Waveform data and AC
setting or in conflict
Setting conflict. Set point
exceeds upper user limit
Setting conflict. Set point
is below lower user limit
Setting conflict. Set point
exceeds low voltage
range setting
Setting conflict. Max.
User Limit must be higher
than Min. User Limit
Setting conflict. Max.
User Limit must be higher
than Min. User Limit
No Waveform Alias name
provided
Duplicate IP detected
File name invalid
Can't find external
memory device selected.
External storage device
selected may have been
removed
Data logging rate set is
invalid
Trying to change
configuration settings
while data logging is in
progress. Stop data
logger function before
changing configuration
Error during data logging
Trying to change phase
mode while output is ON.
Phase mode (FORM)
cannot be changed while
output is ON
Could not clear one or
more faults when
requested
Resolution
Try recycling power. If
error persists, contact
customer service
Check parallel
configuration
Try recycling power. If
error persists, contact
customer service
Adjust DC setting or
waveform to resolve
conflict
Adjust AC setting or
waveform to resolve
conflict
Adjust setting or user
limit
Adjust setting or user
limit
Select High Range or
lower set point
Adjust User Limits
Adjust User Limits
Assign Alias name to
waveform
Check IP or renew lease
Check file name
Re-insert external
memory device or select
different memory type
Adjust logging rate
setting
Stop data logger function
before changing
configuration
Stop data logger function
Turn output OFF first,
then change FORM
Try recycling power. If
error persists, contact
customer service
