Task
7. Set the upstream channel
8. Set the mini-slot size for the
9. Set the receive power level.
10.Set the upstream channel
11.Specify the modulation
12. Verify the upstream
Cuda 12000 IP Access Switch CLI-based Administration Guide
frequency. Valid range: 5.0
– 42.0 MHz.
downstream channel.
Acceptable range: -160 –
260 TenthdBmV.
width.
profile. Acceptable profile
numbers:1 – 2.
configuration for the
selected channel.
Configuring Upstream Channels
Command
upstream <port number> frequency
<frequency>
upstream <port number> minislot-size
{2 | 4 | 8 | 16 | 32 | 64 | 128}
upstream <port number> power-level <value>
upstream <port number> channel-width
{200 | 400 | 800 | 1600 | 3200}
upstream <port number> modulation-profile
<profile-number>
show interface cable <c/s/i> upstream [<port
number>]
399
