ADC CUDA 3 Administration Manual page 295

Cuda 12000 IP Access Switch CLI-based Administration Guide
You configure RIP on an IP interface by performing the following tasks:
Task
1. Enter configuration mode for the
interface on which you want to
enable RIP.
2. Enter the IP address of this
interface.
3. Enable RIP on the current
interface.
4. Enter the protocol for outgoing
packets that the router will send
on this interface. When RIP is
enabled for the first time on the
interface, the send version defaults
to 1 (RIPv1).
5. Enter the protocol that the
interface uses to learn RIP routes.
When RIP is enabled for the first
time on the interface, the receive
version defaults to 1 2 (RIPv1 or
RIPv2).
6. Enter the cost or metric of the
current interface. When RIP is
enabled for the first time on the
interface, the cost defaults
to 1.
7. Configure the interface to accept
host routes advertised by neighbor
routers. When RIP is enabled for
the first time on the interface, the
interface accepts host routes by
default.
8. Configure the interface to accept
default routes advertised by
neighbor routers. When RIP is
enabled for the first time on the
interface, the interface accepts
default routes.
Configuring RIP
Command
interface <c/s/i>
ip address <ip-address> <mask>
ip rip enable
ip rip send-version {1 | 2 |1 2| none}
ip rip receive-version {1|2|1 2| none}
ip rip cost <number>
ip rip accept host-route
ip rip accept default-route
293
