ADC CUDA 3 Administration Manual page 306

304 C 14: C
HAPTER ONFIGURING
IP
Task
4. Configure the default cost only if
this is an ABR connected to a stub
area. The default cost is the metric
assigned to the summary default
route injected into the area by this
router.
5. If you want to summarize routes
injected into the area, use this
command to define the area
range.
6. Configure authentication for this
area.
7. Enable or disable this OSPF area.
8. Display the OSPF area to verify
configuration.
For more information on these commands, refer to the Cuda 12000 IP
Access Switch CLI Reference Guide.
The no forms of the ospf command enable you to perform the following
tasks from within router ospf mode:
Task
1. Remove an OSPF area.
2. Remove a summary range.
3. Disable authentication for the
area.
Command
ospf area <area-id> default-cost
<cost value>
ospf area <area-id> range
<ip address> <mask>
[advertise-matching]
ospf area <area-id> authentication
{md5 | password}
Specify "md5" to configure MD5
password authentication; "password"
to configure simple password
authentication.
ospf area <area-id> {enable | disable}
show ospf area <area-id>
Command
Refer to "Removing OSPF Areas" on
page 305.
no ospf area <area-id> range
<ip address> <mask>
[advertise-matching]
no ospf area <area-id>
authentication
