Viewing Alarm Signals Out the DB-15 Connector

cli:192.168.208.3:root# aux-device db15 alarm blue
cli:192.168.208.3:root# show aux-device db15
Temp Alarm
Sys Alarm
Red Alarm
Blue Alarm
Yellow Alarm
Power Alarm
A C M
LARM ONTROLLER ANAGEMENT
You may display the current configuration of the alarm signals over the
DB-15 connector. To do this, perform the following tasks:
Task
1. Enter root mode.
2. Display current configuration of the
alarm signals out the DB-15 connector.
Example
In the following example:
A Temp Alarm, Sys Alarm, Red Alarm, Yellow Alarm and Power Alarm
signal have been configured in the past to be sent out the DB-15
connector for all associated faults.
The administrator configures a Blue Alarm signal to not be sent out the
DB-15 connector for all associated faults.
backplane-temp-fault
processor-temp-fault
ps-temp-fault
fan-temp-fault
backplane-system-fault
backplane-temp-fault
backplane-power-fault
local-pwr-a-fault
local-pwr-b-fault
red-alarm-fault
ps-temp-fault
ps-ac-fault
ps-dc-fault
fan-temp-fault
fan-rotation-fault
bits-a-fault
bits-b-fault
red-alarm-fault
blue-alarm-fault
yellow-alarm-fault
local-pwr-a-fault
Command
root
show aux-device db15
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
disabled
enabled
enabled
