Source Routing Configuration Example

cli:172.16.19.10:root# interface 1/1/1
mode: interface:cable:csi(1/1/1)
cli:172.16.19.10:interface:cable:csi(1/1/1)# ip source-route 172.16.19.2
255.255.255.255 209.16.19.2
cli:172.16.19.10:interface:cable:csi(1/1/1)# ip source-route 172.16.19.5
255.255.255.255 172.16.20.4
cli:172.16.19.10:interface:cable:csi(1/1/1)# ip source-route 172.16.19.9
255.255.255.255 172.19.34.5
cli:172.16.19.10:interface:cable:csi(1/1/1)# show ip interface source-route
Address
---------------- ---------------- ----------------
172.16.19.2
172.16.19.5
172.16.19.9
row count: 3
cli:172.16.19.10:interface:cable:csi(1/1/1)#
Cuda 12000 IP Access Switch CLI-based Administration Guide
For example, if 3 users are connected to a single DOCSIS module on
interface 1/1/1; each user would belong to a different internet service
provider, ISP-1, ISP-2, ISP-3, as described in the following table:
Customer Host
172.16.19.2
172.16.19.5
172.16.19.9
To configure each customer to use a default route that points to their ISP's
router, you would configure the following source routing entries:
Mask
255.255.255.255
255.255.255.255
255.255.255.255
Configuring IP Source Routing
ISP
ISP-1
ISP-2
ISP-3
NextHop
209.16.19.2
172.16.20.4
172.19.34.5
325
ISP's Router
209.16.19.2
172.16.20.4
172.19.34.5
